Summary of Contents for ELTEX WOP-12ac
- Page 1 Wireless access point WOP-12ac User manual Firmware version 1.18.1 IP address: 192.168.1.10 Username: admin Password: password...
-
Page 2: Table Of Contents
WOP-12ac. User manual Contents Introduction ............................3 Annotation ............................3 Symbols ............................... 3 Device description ..........................4 Purpose ............................... 4 Device specification..........................4 The device technical parameters....................... 5 Design ..............................7 The device schematic structure......................9 Reset to the default settings ......................9 Delivery package ..........................10... -
Page 3: Introduction
WOP-12ac device is a Wi-Fi access point of Enterprise class. The device enclosed into hermetic case which allows to use the access point outdoor in different climatic conditions – at temperatures from –40 to +65 °С. -
Page 4: Device Description
2 Device description 2.1 Purpose WOP-12ac wireless access point (hereinafter the device) is designed for provision of users' access to high-speed safe network. The device provides high-speed and safe wireless network combining a lot of opportunities and services that are necessary for comfortable users' access to operator services. -
Page 5: The Device Technical Parameters
• support for WIDS/WIPS. 2.3 The device technical parameters Table 1 – The device main technical parameters WAN interface parameters Number of ports 2 (3 for WOP-12ac-LR ER SFP and WOP-12ac-LR ER GPON) Connector , RJ-45, 10/100/1000, auto-negotiation, BASE-T Wireless interface parameters Standards 802.11a/b/g/n/ac... - Page 6 • 4 GHz up to 19 dBm maximum value of EIRP for WOP-12ac ER, WOP-12ac • 5 GHz up to 19 dBm ER SFP and WOP-12ac ER GPON in both frequency ranges • 4 GHz up to -98 дБм Receiver sensitivity •...
-
Page 7: Design
Weight 2.3 kg 2.4 Design WOP-12ac has an industrial design and metal case. Figure 1 shows the device side panel layout. Figure 1 – WOP-12ac side panel layout Connectors and controls located on the device panels are listed in Table 2.4. Table 2 – Description of ports and controls... - Page 8 Port 0 (PoE) 10/100/1000 Base-T port (RJ-45 with PoE+ support Port 1 10/100/1000 Base-T port (RJ-45 connector) Optical connector SC/UPC (only for WOP-12ac ER SFP) or SC/APC (only for WOP-12ac ER GPON) Console Connector for console cable connection (RJ-45 connector)
-
Page 9: The Device Schematic Structure
2.5 The device schematic structure Figure 2 shows WOP-12ac schematic structure. Figure 2 – WOP-12ac schematic structure • A1-A6– connectors for antennas; • Radio 1– radio interface that performs reception and transmission of data in wireless networks in the range of 2.4 GHz;... -
Page 10: Delivery Package
WOP-12ac. User manual 2.7 Delivery package The delivery package includes: • WOP-12ac wireless access point; • 3 connectors for RJ-45; • 1 connector for power supply; • Grounding kit; • Mounting kit; • Operating manual (supplied on a CD);... -
Page 11: Installation Order
WOP-12ac. User manual 3 Installation order This section defines safety rules, installation recommendations, setup procedure and the device starting procedure. 3.1 Safety rules 1. Do not open the device case. There are no user serviceable parts inside. 2. It is required to cover unused antenna connectors by safety cover included in the device delivery package. -
Page 12: Channel Selection For Neighboring Access Points
WOP-12ac. User manual Material Change of signal level, dB 2.4 GHz 5 GHz Plaster slab -0,5 -0,8 Wood laminated plastic -1,6 -1,9 Plywood -1,9 -1,8 Plaster with wirecloth -14,8 -13,2 Breezeblock Metal lattice (mesh 13*6 mm, metal 2mm) 3.4 Channel selection for neighboring access points It is recommended to set nonoverlapping channels to avoid interchannel interference among neighboring access points. -
Page 13: The Device Installation
WOP-12ac. User manual When width of used channel is 40 MHz there is no non-overlapping channels in frequency range of 2.4 GHz. In such cases, you should select channels maximally separated from each other. Figure 6 – Channels used in range of 5 GHz when channel width is 20, 40 or 80 MHz 3.5 The device installation... - Page 14 WOP-12ac. User manual Figure 7 – Mounting brackets to the device a) Figure 7 shows the required position of brackets. b) Align four boltholes on brackets with the same boltholes on the device. Attach brackets with screws to the device by using screw-driver.
-
Page 15: Algorithm Of Device Mounting To A Mast/Pole
WOP-12ac. User manual 3.5.2 Algorithm of device mounting to a mast/pole 1. Mount the bracket for attaching to a mast/pole: Figure 8 – Bracket for attaching to mast/pole a) Connect bracket, that will be attached to a mast/pole, to bracket, that will be attached to the device, as shown in Figure 8. -
Page 16: Order For Wall-Mounting Brackets
WOP-12ac. User manual 3. Attach the device to a mast/pole: Figure 10 – Mounting the device on a mast/pole a) Install the device on the top untwisted screws of a bracket attached to a mast/pole, see Figure 10. b) Install screws to the bottom bolthole, see Figure 10. - Page 17 WOP-12ac. User manual a) Figure 11 shows bracket allocation on the wall. Figure 12 shows distance between the boltholes. b) Align together four boltholes on bracket and boltholes on the device surface. Screw the brackets to the device surface by using screwdrive. c) Install DIN7985 M6 screws in the top holes. Do not screw them fully. Leave at least 3 mm gap, see Figure 11.
-
Page 18: Grounding Scheme Of The Device
WOP-12ac. User manual 3.5.4 Grounding scheme of the device After device installation, you must ground it by using 2.5 mm2 vinyl-insulated wire. Figure 14 shows grounding scheme of the device. Figure 14 – The device grounding scheme... -
Page 19: Application. Power Connector Pin Array
WOP-12ac. User manual 4 Application. Power connector pin array Power connector pin array Figure 15 – 48 V power supply connector pin array RJ-45 connector pin array The next scheme is used for twisted-pair wiring. Side А: 1. white orange;... -
Page 20: List Of Changes
WOP-12ac. User manual 5 List of changes Document version Issue date Revisions Version 1.18 01.10.2019 Synchronization with firmware version 1.18.1 Version 1.17 05.06.2019 Synchronization with firmware version 1.17.0 Version 1.16 12.02.2019 Synchronization with firmware version 1.16.0 Version 1.15 30.11.2018 Synchronization with firmware version 1.15.0... - Page 21 +7(383) 274-47-87 +7(383) 272-83-31 E-mail: techsupp@eltex-co.ru You are welcome to visit Eltex official website to get the relevant technical documentation and software, to use our knowledge base or consult a Service Centre Specialist in our technical forum. http://www.eltex-co.ru/en/ http://www.eltex-co.ru/en/support/downloads/...
