Source Four jr / jr Zoom

Replacing the HPL lamp

A lamp must be installed before you use the fixture.
Note: Verify that the HPL lamp you intend to install is suitable
WARNING:
1: Disconnect power to the fixture before installing the lamp.
2: Loosen the knurled bolt on the back of the lamp housing and pull the
3: Holding by the base, remove the HPL lamp from its box.
.
CAUTION: Use caution when installing or replacing any lamp.
Note: To avoid premature lamp failure, do not touch the lamp
Source Four jr / jr Zoom
for your facility's voltage; 115-, 120-, 230-, and 240-volt
HPL lamps are available. See
Operating HPL lamps above their rated voltage reduces
lamp life and can cause premature lamp failure.
Let the lamp cool before replacing.
housing out.
When installing/replacing lamp, be sure to point the
lamp away from your face and away from others before
inserting it firmly into the assembly.
This may prevent injuries if the lamp should break.
INCORRECT
glass. If you do, clean it carefully with isopropyl alcohol
and a clean lint-free cloth. Allow to dry before
operation.
Page 4 of 12
on
HPL lamp table
CORRECT
page 2.
