ETC Source Four jr Assembly Manual

ETC Source Four jr Assembly Manual

Hide thumbs Also See for Source Four jr:

Advertisement

Quick Links

Download this manual See also: User Manual
TM
Zoom
TM
CE Assembly Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Source Four jr and is the answer not in the manual?

Questions and answers

Related Manuals for ETC Source Four jr

Summary of Contents for ETC Source Four jr

  • Page 1 Zoom CE Assembly Guide...
  • Page 2 Electronic Theatre Controls, Inc.

  • Page 3: Table Of Contents

    Zoom CE Assembly Guide Contents Lamp socket assembly ..............5 Lens holder assembly ..............9 Maintenance ................. 11 Shutter assembly ................13 Final assembly ................15 CE Source Four jr / jr Zoom Assembly Guide...
  • Page 4 14 5 Lamp socket assembly Reference Part Description Quantity number number required 7060A3055 Housing, socket, casting, painted 7060A3057 Socket, light baffle casting, painted 7060A4007 Knob, X-Y, lamp set 7060A4008-02 Knob, Z, lamp set w/female insert 7060A4011 Bushing, cup 7060A3011 Hub, index, casting 7060A3012 Spring, lamp retainer HW748...

  • Page 5: Lamp Socket Assembly

    (16) on the bolt and secure with the 9/ 16 hex nut (15). Hand tighten the X-Y knob (3). Note: Install the wave washer with the upward curve toward the hex nut. CE Source Four jr / jr Zoom Assembly Guide...
  • Page 6 9. Insert the knurled head screw (13) through the housing socket casting (1) as shown in figure 4. Figure 4 10. Install the ground spring (23) onto the screw and secure it with the Southco flat retaining ring (14). Install the Southco ring with its prongs away from the casting.
  • Page 7 7. 18. Place the Tinnerman clip (26) over the retainer clip crossbar between the two hooks and press it down firmly until it snaps into place. Figure 7 CE Source Four jr / jr Zoom Assembly Guide...
  • Page 8 Lens holder assembly Reference Part Description Quantity number number required 7062A3005 Lens holder, 26° 7062A3017 Lens holder, 36° 7062A3018 Lens holder, 50° 7062A3019 Lens holder, Zoom, forward 7062A3020 Lens holder, Zoom, rear 7062A4001 Lens, 26°, “black dot” 7062A4002 Lens, 36°, “white dot” 7062A4003 Lens, 50°, “yellow dot”...

  • Page 9: Lens Holder Assembly

    4. Check lens and make sure the clips hold it securely. 5. Position safety screen as shown below, and secure with clips. Fixed field angle lens assembly Figure 8 1, 2, 3 Important: Lens paint dot this side 6, 7, 8 CE Source Four jr / jr Zoom Assembly Guide...
  • Page 10 Zoom Front Lens Assembly 1. Position the lens (9) between the lens holder (4) and the lens cover (11) so that the convex side of the lens faces the lens holder, as shown in Figure 9. 2. Align the holes in the lens cover with the holes in the lens holder as shown below.

  • Page 11: Maintenance

    Remove dust with a blast or oil-free air or wipe with a clean lint-free cloth using alcohol or distilled water (alcohol is recommended). Warning : Do not use glass and window cleaners on the reflector. Chemicals in these cleaners wills tain the reflector. CE Source Four jr / jr Zoom Assembly Guide...
  • Page 12 Shutter assembly Reference Part Description Quantity number number required 7062A2002 Shutter blade assembly 7062A3016 Plate, divider 7062A3010 Plate, gate (middle) 7062A3030 Plate, divider with dimples 7062A3031 Plate, support, spring (see figure 12) HW754 Spring, shutter (see figure 12) Electronic Theatre Controls, Inc.

  • Page 13: Shutter Assembly

    6. Install the four springs (6) onto the nips on the spring plate support (5). 7. Place the dimples of the plate divider (4) onto the open ends of the springs. Figure 12 CE Source Four jr / jr Zoom Assembly Guide...
  • Page 14 Final assembly Reference Part Description Quantity number number required 7062A3002 Barrel, left casting 7062A3004 Barrel, right casting See page 4 Lamp burner assembly HW8201 Knob, 10-32 x .50 LG male stud, black 1 or 2 7061A3005 Clip, gel retainer 7062A4010 Reflector, jr, glass 7062A3007 Spring, round, reflector...

  • Page 15: Final Assembly

    13. Attach yoke (10) to barrel assembly with bolts (12) and washers (14). Attach yoke knob (11) with bolt (13) and washer (14). Tighten bolts (12) to secure yoke to fixture. CE Source Four jr / jr Zoom Assembly Guide...
  • Page 16 This document is the confidental property of ETC and is loaned subject to return upon demand. Title to this document is never sold or transferred for any reason. This document is to be used only pursuant to written license or...
