Source Four jr / jr Zoom

Color frame holder

The color frame holder is
equipped with a spring-loaded
retaining clip that prevents
color frames and accessories
from falling out.
WARNING:
1: Release the retaining clip by pushing it sideways while gently pulling
backwards.
2: Insert the color frame.
3: Lock the retaining clip by pushing sideways while gently pushing
forward.
Note: The performance of saturated colors may be less than
Source Four jr / jr Zoom
Make sure all color frame accessories are locked in
position with the retaining clip before hanging the
Source Four.
desirable in any theatrical lighting fixture. For best
results, always use high-quality color media rated for
high-temperature use.
ETC's optional Conical Gel Extender (part number
7060A1048) will provide maximum color media life. Gel
Extenders are not recommended for 70° and 90° lens
tubes due to the extremely wide-angle beam.
A variety of heat shield products is also available from
many color media manufacturers. Follow the
manufacturer's instructions for the use of these
products.
Page 3 of 12
Retaining
clip
