Proline Promag 10D
Reference operating
conditions

Maximum measured error

Repeatability

Endress+Hauser

Performance characteristics

• Error limits following DIN EN 29104, future ISO 20456
• Water, typically +4 to +35°C (+39 to +95 °F); 2 to 6 bar (29 to 87 psi)
• Specification as per calibration protocol ± 5°C (± 41 °F) and ± 2 bar (± 29 psi)
• Data on the measured error based on accredited calibration rigs traced back to ISO 17025
• Current output: also typically ±5 μA
• Pulse output: ±0.5% o.r. ± 2 mm/s (±0.5% o.r. ± 0.08 in/s) (o.r. = of reading)
Fluctuations in the supply voltage do not have any effect within the specified range.
[%]
2.5
2.0
1.5
1.0
0.5
0
0 1 2
0 5
Max. measured error in % of reading
Max. ±0.2% o.r. ± 2 mm/s (±0.2% o.r. ± 0.08 in/s) (o.r. = of reading)
0.5 %
4 6
10 15 20
8 10 [m/s]
v
25 30 32 [ft/s]
A0003200
9
