Proline Promag 10D

Load

Low flow cut off

Galvanic isolation

Terminal assignment

Supply voltage

Power consumption

Power supply failure

Endress+Hauser
Pulse output
Failsafe mode can be selected
Status output
"Not conductive" in the event of fault or power supply failure
See "Output signal"
Low flow cut off, switch-on point can be selected as required
All circuits for inputs, outputs and power supply are galvanically isolated from each other

Power supply

Order characteristic
for "inputs/outputs"
24 (+)
A Pulse/status output
Functional values
• 85 to 250 V AC, 45 to 65 Hz
• 20 to 28 V AC, 45 to 65 Hz
• 11 to 40 V DC
Power consumption
• 85 to 250 V AC: < 12 VA (incl. sensor)
• 20 to 28 V AC: < 8 VA (incl. sensor)
• 11 to 40 V DC: < 6 W (incl. sensor)
Switch-on current
• Max. 16 A (< 5 ms) for 250 V AC
• Max. 5.5 A (< 5 ms) for 28 V AC
• Max. 3.3 A (< 5 ms) for 24 V DC
Lasting min. ½ cycle frequency: EEPROM saves measuring system data
Terminal No.
25 (–) 26 (+) 27 (–)
HART current output
See "Output signal"
1 (L1/L+) 2 (N/L–)
Power supply
See "Supply voltage"
5
