Proline Promag 10D
Process connections
Local operation
Remote operation
CE approval
C-tick symbol
Ex approval
Drinking water approval
Other standards and
guidelines
Endress+Hauser
Promag D as wafer version
The wafer version is compatible with the following process connections:
• EN 1092-1 (DIN 2501)
• ASME B16.5
• JIS B2220
Promag D with threaded connection
• DIN ISO 228, G" external thread
• ANSI/ASME B1.20, NPT" external thread
Operability
Display elements
• Liquid crystal display: unilluminated, two-line, 16 characters per line
• Display (operating mode) preconfigured: volume flow and totalizer status
• 1 totalizer
Operating elements
Local operation via three keys
Operation via HART protocol and FieldCare
Certificates and approvals
The measuring system is in conformity with the statutory requirements of the EC Directives.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
The measuring system meets the EMC requirements of the "Australian Communications and Media
Authority (ACMA)".
Information about currently available Ex versions (ATEX, FM, CSA, IECEx, NEPSI etc.) can be supplied
by your Endress+Hauser Sales Center on request. All explosion protection data are given in a separate
documentation which is available upon request.
• WRAS BS 6920
• ACS
• NSF 61
• KTW/W270
• EN 60529
Degrees of protection by housing (IP code)
• EN 61010-1
Safety requirements for electrical equipment for measurement, control and laboratory use
• IEC/EN 61326
"Emission in accordance with requirements for Class A".
Electromagnetic compatibility (EMC requirements)
• ANSI/ISA-S82.01
Safety Standard for Electrical and Electronic Test, Measuring, Controlling and related Equipment -
General Requirements. Pollution degree 2, Installation Category II.
• CAN/CSA-C22.2 No. 1010.1-92
Safety requirements for Electrical Equipment for Measurement and Control and Laboratory Use.
Pollution degree 2, Installation Category II
25
