9.2

Using the HARDWARE Command

The HARDWARE serial command can be used to verify that installed option cards are recognized by the system.
The HARDWARE command returns a three-digit card code, representing the card installed:
If an installed card is not recognized (HARDWARE command returns code of 0), ensure that the card is seated
properly. Reinstall the card, if necessary, then cycle the power to read the configuration again. If the card is still not
recognized, you may need to try a different option card.
9.3

ERROR Commands Output

The XE and XEH commands return a representation of any existing error conditions as described in the following
table. If more than one error condition exists, the number returned is the sum of the values representing the error
conditions. The XE command returns the value as a decimal representation and the XEH command returns the
value as a hexadecimal representation.
XE Error Code
0
1
2
4
8
16
32
64
32768
65536
131072
262144
524288
1048576
2097152
4194304
8388608
16777216
80 880 Installation Manual
Code
000
085
153
170
Table 9-2. HARDWARE Command Option Card Type Codes
(decimal)
no errors
VIRGERR
PARMCHKERR
LOADCHKERR
PRINTCHKERR
ENVRAMERR
ENVCRCERR
BATTERYERR
GRAVERR
ADPHYSICALERR
TAREERR
EACCOVER
STRINGERR
RESERVED_PF
RTCERR
MISSINGHWERR
CFGCONFLICTERR
UNRECOVERABLEERR
Table 9-3. Error Commands Output
Card Type
No card installed
Relay Card
Analog Output Card
CompactCom Card
Description
0x00000000
0x00000001
0x00000002
0x00000004
0x00000008
0x00000010
0x00000020
0x00000040
0x00008000
0x00010000
0x00020000
0x00040000
0x00080000
0x00100000
0x00200000
0x00400000
0x00800000
0x01000000
XEH Error Code
(hexadecimal)
