6.1.2

Reporting Commands

Reporting commands (see Table 6-2) send specific information to the EDP port. These commands can be used in
both setup mode and normal mode.
Command
AUDITJUMPER
DUMPALL
DUMPAUDIT
DUMPCONFIG
DUMPETH
DUMPSP
HARDWARE
VERSION
DISPLAYVERSION
P
ZZ
6.1.3

The RESETCONFIGURATION Command

The RESETCONFIGURATION command can be used in setup mode to restore all configuration parameters to
their default values.
This command is equivalent to using the DEFALT function in CONFIG mode.
Note
All load cell calibration settings are lost when the RESETCONFIGURATION command is run.
6.1.4

Parameter Setting Commands

Parameter setting commands allow you to display or change the current value for a particular configuration
parameter (Tables 6-3 through 6-22).
Current configuration parameter settings can be displayed in either setup mode or normal mode using the following
syntax:
command<CR>
Most parameter values can be changed in setup mode only; setpoint parameters listed in Table 6-15 can be changed
when in normal weighing mode.
Use the following command syntax when changing parameter values:
command=value<CR>
where is either a number or a parameter value. Use no spaces before or after the equal (=) sign. If you type an
value
incorrect command, the response will be
For example, to set the motion band parameter to 5, type the following:
SC.MOTBAND#1=5D<CR>
For parameters with selectable values, enter the command and equal sign followed by a question mark:
command=?<CR>
to see a list of those values. The indicator must be in setup mode to use this function.
Reports the state of the audit jumper. A response of "OK" indicates the jumper is in the ON position.
A response of "??" indicates the jumper is in the OFF position.
List all parameter values
List audit trail information
List all parameter values except for setpoint data
List all Ethernet parameter values
List all setpoint parameter values
Returns a value that indicates which option card is installed in the option slot.
Possible values:
000=none, 085=relay card, 153=analog output card, 170=CompactCom card
Example response with a relay card installed:
HARDWARE=085
Return the 880 software version
Return the display module software version
Return the current displayed weight with units identifier, see Section 9.4
Return the current weight and annunciator status, see Section 9.4
Table 6-2. EDP Reporting Commands
.
??
Function
EDP Commands 59
