3.2.13 Analog Output Menu

The ALGOUT menu is used only if the analog output option is installed. If the analog output option is installed,
configure all other indicator functions and calibrate the indicator before configuring the analog output. See
Section 9.11 on page 92 for analog output calibration procedures.
....
SETUP
....
ALGOUT
MODE
GROSS
NET
ALG OUT Menu
Parameter Choices
Level 2 submenus
MODE GROSS
NET
OUTPUT 0-10V
0-20MA
4-20MA
ERRACT FULLSC
HOLD
ZEROSC
MIN 0.000000
number
MIN NEG OFF
ON
MAX 10000.00
number
MAX NEG OFF
ON
TWZERO 000000
number
TWSPAN 000000
number
48 880 Installation Manual
....
....
OUTPUT ERRACT MIN
0-10V FULLSC 0
number
0-20MA HOLD
4-20MA
ZEROSC
Figure 3-21. Analog Output Menu
Defines if the output follows the GROSS or NET weight.
Zero offset. Selects whether the analog output supplies voltage (0–10 V) or current (4–20 mA)
output. Select 0% for 0–10 V output; select 20% for 4–20 mA output.
Error action. Specifies how the analog output responds to system error conditions.
Possible values are:
FULLSC: Set to full value (10 V or 20 mA)
HOLD: Hold current value
ZEROSC: Set to zero value (0 V or 4 mA)
Specifies the minimum weight value tracked by the analog output. Specify a value in the range
0–999999.
Set to ON if the MIN value is negative.
Specifies the maximum weight value tracked by the analog output. Specify a value in the range
0–999999.
Set to ON if the MAX value is negative.
Calibrate zero. Adjust the analog output zero calibration. See Section 9.11 on page 92.
Calibrate span. Adjust the analog output span calibration. See Section 9.11 on page 92
Table 3-14. Analog Output Menu Parameters
