Settings
Name
Setpoints > High Warn (Over-
Frequency Warning)
Setpoints > High Fail (Over-
Frequency Failure)

4.6.2.1 RPM / Frequency Select

The controller has the ability to change between Primary RPM / 60Hz and Secondary RPM / 50Hz through the use of a switched
input.
The following settings must be set in order for this feature to function:
· Switched I/O > Switched In A/B/C/D/E > Function > RPM Switch (Primary RPM / 60Hz - Secondary RPM / 50Hz Select).
The switched input is only monitored before a start signal has been received. Once a start signal has been received
changing the status of the switched input will have no effect.
· AC Monitor > Genset Freq. > Freq. Source > Auto Selection
· Sensors > Engine Speed > RPM Switch > Primary (Primary RPM / 60Hz)
· Sensors > Engine Speed > RPM Switch > Secondary (Secondary RPM / 50Hz)
The table below shows the correspondence between the switched input status and the RPM / Frequency.
Switched Input
Inactive
Active
NOTE: If enabled, the J1939 TSC1 PGN will be broadcasted according to the selected speed. Otherwise only the
warning and failure setpoints are affected by this function.
TOUGH Series Manual
Range Description
Disable, 101 ~ 150% Reading at which a warning occurs.
Disable, 101 ~ 150% Reading at which a failure occurs.
Speed / Frequency
Primary RPM / 60Hz
Secondary RPM / 50Hz
