Settings
Name
Fuel In Basin
Battle Mode
Start Inhibit
RPM Switch (Primary
RPM / 60Hz -
Secondary RPM / 50Hz
Select)
ECM Preheat (ECM
Preheat Signal)
Remote Reset
NOTE: More than one Active Mode can be selected.
The active modes is only configurable if the Function menu is set to one of the configurable switched input functions.
It is fixed for all other functions.
Switched I/O > Switched IN X > Trigger:
Name
Close +BAT
Close GND
Close +BAT/GND
Open
NOTE: When running wires over long distances (over 20ft / 6.1m), it is recommended to use +BATTERY as the trigger
method.
TOUGH Series Manual
Active Mode Description
active is the LED indicator will alternate between the green and red colors.
The LED goes back to it's original state when the switched input is no longer
active.
Global Controller displays 'Fuel In Basin' warning when active.
After Cranking Controller ignores all warnings and failures when active. Displays 'Battle
Running' when active. If a failure occurs during Battle Mode it is 'latched' and
the engine will shutdown on failure when the controller leaves Battle Mode.
Global Controller ignores all start commands and the engine cannot start when
active. Once Start Inhibit becomes inactive, starting is enabled again. If the
engine is running, activating this input will shut down the engine.
Auto Used for changing between Primary and Secondary RPM for an engine or
50Hz / 60Hz for a generator. See
information.
Cranking (during the Controls preheating using a switched input. See Switched Input in the
Preheat countdown Preheat Mode
only)
Global Allows the controller to be reset from a failure mode.
- Momentary action for 3 - 5s in FAILURE mode will place the controller in
OFF mode.
- Momentary action for 3 - 5s in OFF mode will place the controller in AUTO
mode.
- Momentary action for 3 - 5s in RUN mode will place the controller in AUTO
mode. Cool-down is skipped.
Description
Input is active when +Battery is present at the terminal.
Input is active when Ground is present at the terminal
Input is active when either +Battery or Ground is present at the terminal.
Input is active when neither +Battery or Ground is present at the terminal.
RPM / Frequency Select
section.
