  • Page 1 CC-65 AC/DC CURRENT CLAMP OPERATOR’S MANUAL...
  • Page 2 INTRODUCTION When measuring the AC/DC Current with the Current Clamp, a multimeter or scope can directly measure the current up to 65 A , with a frequency up to 20KHz. In this method, there is no need to break a circuit or to affect the isolation to measure the current. The Current Clamp is not only available for the detection or monitor of the possibly existing creepage, but for the measurement with little gap using its extended jaws.
  • Page 3 1. In the case of DC current, the output is positive when the current flows from the upside to the underside of the clamp. The red banana plug is positive. 2. In the case of DC current measurement, the current clamp can not possibly zero properly, due to the hysteresis effect.
  • Page 4 to 1mV/10mA and the output is 10mV. Assuming that the Precision is 1.5%, the output is10.15mV maximum and 9.85mV minimum. If the digital multimeter connected with current clamp is set to 200mV and the Precision 0.5%,,the readings is10.20mV maximum 9.8mV minimum.
