2.12 Operating status indicators
Operating status is indicated as follows: auto-leveling LED, battery status LED, shock warning LED and slope LED.
2.13 LED indicators
Auto-leveling LED (green)
Shock warning LED (orange)
Surveillance LED (orange)
Slope LED (orange)
Several LEDs light
All LEDs
2.14 Charge status of the Li‑ion battery during operation
LEDs light constantly
LED 1,2,3,4
LED 1,2,3
LED 1,2
LED 1
-
2.15 Charge status of the Li‑ion battery during charging while inserted in the tool
LEDs light constantly
LED 1, 2, 3, 4
LED 1, 2, 3
LED 1, 2
LED 1
-
2.16 Charge status of the Li‑ion battery during charging while not inserted in the tool
If the red LED lights constantly, the battery is being charged.
If the red LED doesn't light, the battery is fully charged.

3 Accessories

Designation
Remote control / laser receiver
Laser receiver
Target plate
Wall mount
Slope calculator
Slope adapter
The green LED blinks.
The green LED lights con-
stantly.
The orange LED lights con-
stantly.
The LED lights orange.
The orange LED blinks.
The orange LED lights con-
stantly.
2 LEDs blink orange.
All LEDs blink
LEDs blink
-
-
-
-
LED 1
LEDs blink
-
LED 4
LED 3
LED 2
LED 1
Description
PRA 35
PRA 38, PRA 30/31
PRA 50/51
PRA 70/71
PRA 52
PRA 78
The tool is in the leveling phase.
The tool has leveled itself / is operating
normally.
Shock warning mode is deactivated.
The tool is in surveillance mode.
Alignment in the sloping plane.
Slope mode is active.
The tool is in axis alignment (slope)
mode.
The tool has been bumped, knocked off
level or is exhibiting some other error.
Charge status C
C ≧ 75 %
50 % ≦ C < 75 %
25 % ≦ C < 50 %
10 % ≦ C < 25 %
C < 10 %
Charge status C
C = 100 %
C ≧75%
50 % ≦ C < 75 %
25 % ≦ C < 50 %
C < 25 %
en
19
