1 General information

1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Symbols
Read the General
operating warning
instructions
before use.
For indoor Return waste
use only material for
recycling.

2 Description

2.1 Use of the product as directed
The tool is designed to be used to determine, transfer and check levels, verticals, slopes and right angles. Examples of
its uses are: transferring datums and height marks, determining right angles for walls, vertical alignment on reference
points and setting out slopes.
Use of tools or AC adapters which show visible signs of damage is not permissible. Operation outdoors or in damp
conditions in "Charging during operation mode" is not permissible.
To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
Take the influences of the surrounding area into account. Do not use the appliance where there is a risk of fire or
explosion.
Modification of the tool is not permissible.
2.2 PR 35 rotating laser
The Hilti PR 35 is a rotating laser tool with a visible rotating laser beam and a reference beam set at 90° to the main
beam. The PR 35 can be used for alignment in the vertical, horizontal and inclined planes.
Warning: Warning:
caustic electricity
substances
>1/4s
Do not look
into the
beam.
Type identification plate
PR 35
Po = average radiant power of a pulsating laser, laser
wave length 620-690nm, modulation frequency 1MHz,
pulse cycle 50%, diameter of bundled laser beam at the
pentaprism 5mm, speed of rotation 300 U/Min. Under
the conditions listed above, the average output power is
<4.85 mW.
Location of identification data on the tool
The type designation and serial number can be found on
the type identification plate on the tool. Make a note of
this data in your operating instructions and always refer
to it when making an enquiry to your Hilti representative
or service department.
Type:
Generation: 01
Serial no.:
