2.3 Status Messages

2 2
When the adjustable frequency drive is in status mode,
status messages are generated automatically and appear in
the bottom line of the display (see Figure 2.13).
Figure 2.13 Status Display
1 Operation Mode (see Table 2.2)
2 Reference Site (see Table 2.3)
3 Operation Status (see Table 2.4)
Table 2.1 Legend to Figure 2.13

2.4 Status Message Definitions

Table 2.2 to Table 2.4 define the meaning of the displayed
status messages.
Off
Auto On
Table 2.2 Operation Mode
Remote
Local
Table 2.3 Reference Site
26
Service Manual
Status
799RPM 7.83A
0.000
53.2%
Auto Remote
Ramping
Local
Hand Stop
O Running
Jogging
.
.
.
Stand by
1 2 3
The adjustable frequency drive does not react
to any control signal until [Auto On] or [Hand
On] is pressed.
The adjustable frequency drive is controlled
from the control terminals and/or the serial
communication.
The adjustable frequency drive can be
controlled by the navigation keys on the LCP.
Stop commands, reset, reversing, DC brake,
and other signals applied to the control
terminals can override local control.
The speed reference is given from external
signals, serial communication, or internal
preset references.
The adjustable frequency drive uses [Hand On]
control or reference values from the LCP.
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
AC Brake
AMA finish OK
AMA ready
AMA running
1(1)
Braking
36.4kW
Braking max.
Coast
Ctrl. Ramp-down Control Ramp-down was selected in
Current High
Current Low
DC Hold
DC Stop
Feedback high
AC Brake was selected in 2-10 Brake Function.
The AC brake overmagnetizes the motor to
achieve a controlled slow-down.
Automatic motor adaptation (AMA) was
carried out successfully.
AMA is ready to start. Press [Hand On] to start.
AMA process is in progress.
The brake chopper is in operation. Generative
energy is absorbed by the brake resistor.
The brake chopper is in operation. The power
limit for the brake resistor defined in
2-12 Brake Power Limit (kW) has been reached.
•
Coast inverse was selected as a function
for a digital input (parameter group 5-1*
Digital Inputs). The corresponding terminal
is not connected.
•
Coast activated by serial communication.
14-10 Mains Failure.
•
The AC line voltage is below the value set
in 14-11 Mains Voltage at Mains Fault at
line power fault.
•
The adjustable frequency drive ramps
down the motor using a controlled ramp-
down.
The adjustable frequency drive output current
is above the limit set in 4-51 Warning Current
High.
The adjustable frequency drive output current
is below the limit set in 4-52 Warning Speed
Low.
DC Hold is selected in 1-80 Function at Stop
and a stop command is active. The motor is
held by a DC current set in 2-00 DC Hold/
Preheat Current.
The motor is held with a DC current (2-01 DC
Brake Current) for a specified time (2-02 DC
Braking Time).
•
DC Brake is activated in 2-03 DC Brake Cut-
in Speed [RPM] and a Stop command is
active.
•
DC Brake (inverse) is selected as a function
for a digital input (parameter group 5-1*
Digital Inputs). The corresponding terminal
is not active.
•
The DC Brake is activated via serial
communication.
The sum of all active feedbacks is above the
feedback limit set in 4-57 Warning Feedback
High.
