Introduction
1 1
1
17
16
15
14
Figure 1.2 Exploded View D4h Frame Size (D2h Frame is similar)
1 Local control panel mounting bracket
2 Control card and mounting plate
3 Power card and mounting plate
4 Inrush card
5 Inrush card mounting bracket
6 Top fan (IP20 only)
7 DC inductor
8 SCR/Diode modules
9 IGBT modules
Table 1.10 Legend to Figure 1.2
12
Service Manual
2
3
13
12
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
6
4
5
7
11
10 Heatsink fan
11 Gate drive support bracket
12 Capacitor bank
13 Balance/High frequency card
14 Motor output terminals
15 Line power input terminals
16 Gate drive card
17 (optional) RFI filter
8
9
10
