Table of Contents 1 Read this First What you will Find in this Manual..........3 Safety Requirements..............5 2 Meet Your Mailing System System Layout.................13 Accessories ................15 Control Panel Features ............16 Connections ................19 Power Management ..............21 3 Processing Mail Choosing a Type of Stamp............25 Preparing and Starting your Work Session ......27 Processing [Standard] Mail .............33 Printing [PPI] Mail (if available on the model) ......43...
Page 5
7 Online Services Online Services Overview............. 117 Connecting to Online Services ..........118 Uploading Statistics .............. 121 System Online Services............122 8 Configuring your Mailing System Settings Overview ..............125 Logging in / out as the Supervisor ........126 Changing the Display Language .......... 127 Enabling/Disabling Sounds...........
Read this First 1 Read this First This section contains important information about safety precautions and environ- mental recommendations to operate your equipment in the best possible conditions. What you will Find in this Manual..........3 Safety Requirements ..............5 How to Disconnect your Mailing System................9...
What you will Find in this Manual What you will Find in this Manual Section 1: Read this First Make sure your have read and fully understood the safety requirements in this section. This section also includes a list of acronyms and symbols used in the manual.
Page 9
Symbols This manual uses the symbols listed below. This symbol... Indicates... WARNING: indicates a human safety hazard. ATTENTION: brings to your attention a risk for equipment or mail that could result from an action you may perform. NOTE: remark that explains different scenarios or situations. TIP: advice to help save you time when processing your mail.
Safety Requirements Safety Requirements Power Connection Before connection, check whether the Mailing System is suitable for the local AC power voltage; refer to the type plates at the back of each system component. THIS SYSTEM MUST BE GROUNDED • Only connect the power plug to an outlet provided with a pro- tective ground contact.
Page 11
tection by consulting your retailer internet site, or by contacting him. He will inform you of the collection and treatment processes of these machines. CE compliance Products presented in this guide are conform to requirements of directives number 73/23/CEE and 89/336/CEE. This is a class A product.
Page 12
General Safety Before using your Mailing System, thoroughly read the operating instructions. • To reduce the risk of fire, electric shock and injury to persons, follow normal and • basic safety precautions for office equipment when using your Mailing System. To avoid damage, only use approved supplies (ink, tape, cleaners...).
Page 13
Telephone and LAN Connections Your Mailing System uses the telephone network to connect to the Postal Services and to your customer online services. You may also use a LAN (high speed internet connection) to connect to your customer Online Services and to a mail accounting software (MAS), located on a separate PC.
Disconnecting your Mailing System How to Disconnect your Mailing System How to Dis- How to First switch your Mailing System to mode (see Turn the Mailing System to OFF Mode p.22). connect your Mailing System Only unplug the power cord when the Mailing System is in mode or Sleep mode to avoid keeping the ink cartridge in an...
Meet Your Mailing System 2 Meet Your Mailing System Get to know your Mailing System in this section. System Layout ..............13 Accessories................15 Control Panel Features ............16 Connections................19 Power Management ............21 How to Turn the Mailing System to Sleep Mode............. 21 How to Turn the Mailing System to OFF Mode...............
System Layout System Layout System Components Weighing Platform Measures the weight of mail pieces. Automatic Label Dis- Contains labels to be printed. penser System Base Prints envelopes (or labels) and controls the Mailing System. Control Panel Allows you to control the Mailing System. Label Storage Use this slot to store extra labels horizontally.
Page 19
Rear guide-wall Guides envelopes into the feeder. Auto label dispenser Contains labels to be printed. Auto feeder Automatically feeds the system with envelopes (optional). Side guide Holds large envelopes in place for feeding. Inside the system base Sealer Bottle (if Automatically seals mail when the function is acti- installed) vated.
Accessories Accessories Report Printer (option) A USB printer can be directly connected to the mailing system for printing mailing- related reports. For more information about compatible printers that can connect to your mailing system, please contact technical support. Barcode Scanner (option) This scanner is used: to identify accounts through barcodes •...
Control Panel Features Control Panel Features See control panel and screen layout on the flap of the manual cover. Display Areas Account Displays account currently selected. Ad die Indicates that an ad die (slogan) will be printed. Date Displays the date that will be printed. Job memory Displays selected job memory when applicable.
Page 22
Funds Accesses funds management. Accesses preset stamp and account memories. These Job memories presets are managed by the supervisor. Print Labels Switches to label printing (instead of envelopes). Rate Selection Displays the rate selection screen. Stamp Configu- Accesses stamp selection and stamp set up screens. ration Weighing Mode Opens the weighing mode selection menu (Standard...
Connections Connections Connectors Your Mailing System has an Universal Serial Bus (USB) port that allows you to connect to a modem, printer or other USB memory key. Power Connector To wall socket COM4 Future use COM2/3 To Weighing Platform(s) COM1 Not used LAN Port To customer services and/or software applications on...
Page 25
Connection Diagram LAN Port To customer services and/or software applications on a PC (option) USB Modem To telephone network Telephone cable To wall socket (analog telephone line case) Wall Socket Power Source Connectors Nota: Power connectors are shown in section p.19.
Power Management Power Management The System can only use the LAN if the LAN cable is connected BEFORE the power chord is plugged in. Energy Star[reg ] Compliance Office equipment is generally powered on 24 hours a day, so power management features are important for saving energy and reducing air pollution.
How to Turn the Mailing System to OFF Mode How to Turn the Turn your system to 'Sleep' Mode (see How to Turn the Mailing System to Sleep Mode p.21) Mailing System to OFF Mode Be sure that the light located next to the key (at the top right corner of the control panel) is Amber meaning that the Sleep...
Processing Mail 3 Processing Mail This section describes how you can run mail: choose a type of stamp, select a rate and weighing method, activate sealing and so on, depending on the type of process you need to apply to your mail. Choosing a Type of Stamp...........25 Preparing and Starting your Work Session......27 How to Sort Mail ......................
Page 29
How to Move the Stamp (Print Offset)................70 How to Use an Imprint Memory ..................71 3.10 Advanced Operations............72 How to Enable an Emergency Stop.................72 How to Reset Batch Counters ..................72 How to Count Mail pieces by Weighing ................72 How to Fill the Automatic Label Dispenser..............74...
Choosing a Type of Stamp Choosing a Type of Stamp Customizing Your Stamp To process mail, you must first choose a 'Type of stamp' that corresponds to the type of process you want to apply to your mail: printing postage for different rates, using prepaid imprints, printing 'Received' and the date on incoming mail, etc.
Page 31
Type of Process and Type of Stamp The table below indicates the 'Type of stamp' to choose, depending on the type of process you want to apply to each set of mail. The column on the right indicates, for each Type of stamp, the options available for each type of Stamp.
Preparing and Starting your Work Session Preparing and Starting your Work Session In this section This section recommends a list of preparation steps you should perform to help you run your mail efficiently. Mail preparation involves: Sorting mail by type and task, to make processing faster (p.28) •...
Sorting Mail by Type and Task To save time, sort your mail in groups that have similar characteristics. This will prevent you having to change the stamp parameters too often and allow you to fully benefit from the automatic features of your Mailing System, particularly Differ- ential Weighing that allows you to process mail much quicker.
Turning On Your System and Starting a Work Session Turning the system on automatically starts a work session on the Mailing System. At start-up, depending on specific supervisor settings: The access to the system may be open • You may have to enter a PIN code •...
Page 35
You can also use a barcode scanner to select your account. To type letters instead of figures using the keypad, press the cor- responding key several times in a row like a cell phone. (Example : To have “N” press twice the key “6"). See also Changing To change allocating accounts when a session is already opened, see...
Selecting the Type of Stamp For each stack of mail you have sorted (see p.28), select the type of stamp you need to process your mail as follows. How to Change the Current 'Type of Stamp' How to Change Once you are logged in as user: the Current 'Type Either: of Stamp'...
Frequently Asked Questions System check list: Question... Answer Do I have enough postage? Press and enter to check your funds bal- ance. How to Add Funds to the PSD To add funds, see (Meter) p.79. Do I need to clear the Batch Clear batch counters if you intend to issue a report Batch Counter?
Processing [Standard] Mail Processing [Standard] Mail In this Section This section describes how to process [Standard] Mail: Applying postage using different rates • Re-dating mail (depending on your country) • Correcting the postage amount (depending on your country) • See also Choosing a Type of Stamp About the use of the Type of stamp, see p.25.
Page 39
The type of stamp is indicated on line 2 of the screen. To select an option in the screen: Highlight the option using the arrow keys Then always press to validate your selection. Type To change the type of stamp, select the line, press [OK] Type of stamp and then select [Standard] in the...
Page 40
Type a rate number to select a rate or display new rate options Rate wizard Press 8 to select the and choose rate options in lists. Selecting a Rate For more details, see p.60. You may also enter the postage amount manually: on the home screen, type directly the amount using the keypad.
To set the stamp quickly, consider using Imprint memories. The memories store stamp characteristics together with rates and, if Using Imprint Memories activated, charged account. See p.71. Running Mail The way you will handle mail mainly depends on the weighing method you have Weighing Type chosen.
Page 42
If a mail piece is bigger than mail path maximum thickness (see Mail Specifications p.191), press to print a label. The label is printed. The Mailing System prints postage and the mail piece (or label) is sent to the catch tray. If you want to print several identical labels: Press and enter the number of labels.
Page 43
The Mailing System applies postage and the mail piece (or label) is sent to the catch tray. Repeat the previous step for each piece of mail. To quit the process at any time, press When you remove the last object from the Weighing Platform, the Mailing System will ask if you want to print it.
Page 44
In other modes (Manual weight entry , no weight ...) From the [Standard] home screen: Press . System motors start running. Insert the mail piece into the mail path against the rear-guide wall, side to printed facing upwards. If you want to seal the envelope, first engage the flap into the moistener (if installed).
Correcting a Postage Amount (if available) Set-Up Requirements The procedure below outlines steps required to correct the postage amount on mail that has already been processed. [Date Correction] Mode (if available) The sequence is identical to (p.33), except for the following: Postage must be set to the desired additional amount, instead of •...
stamp screen as follows: Date Date Select and then select a date option in the advance Today's screen. Select for printing the current date. How to Change the Date For more details, see p.67. Press to return to the home screen. Set postage to the desired amount: - Type the postage amount on the home screen: this opens Manual amount...
Page 47
Otherwise, if you want to print several identical labels: Press and enter the number of labels. Make sure the labels are available in the Label Dispenser Filling the Label Dispenser (see p.74). Press to print labels. The Mailing System applies postage and the mail piece (or label) is sent to the catch tray.
Printing [PPI] Mail (if available on the model) Printing [PPI] Mail (if available on the model) In this Section This section describes the parameter settings and mail handling sequences for the mail processes that use the [PPI] type of stamp. See also Choosing a Type of To choose the type of stamp to use for each type of mail, see...
Select the PPI to use. Selecting a Pre-Paid Imprint (PPI) p.63. Select a weighing mode (if you did not enter any amount) To change the current weighing mode, press Weighing type select a weighing type in the screen. How to Change the Weighing Type For more details, see p.65.
Page 50
If the Smart Start function is activated, the motors start automati- cally when you withdraw the mail piece from the weighing plat- How to Activate / Deactivate form. To enable Smart Start, see Smart Start p.132. Withdraw the envelope from the WP and insert it into the mail path against the rear-guide wall, side printed...
Page 51
To print the stamp, insert the mail piece into the base against the rear- guide wall, side to be printed facing upwards. If you want to seal the envelope, first engage the flap into the moistener (option). Do not try to moisten self-adhesive envelopes. If mail piece is bigger than mail path maximum thickness (see Mail Specifications p.191), press...
Page 52
Repeat the previous step of each piece of mail. To quit the process at any time, press When you remove the last object from the WP, the Mailing Sys- tem asks if you want to print it. You can answer .
Page 53
In other modes (Manual weight entry , No weight source). From the [PPI] home screen, to print postage on mail pieces: Press . System motors start running. Insert the mail piece into the mail path against the rear-guide wall, side to printed facing upwards.
[Date Correction] Mode (if available) [Date Correction] Mode (if available) In this Section This section describes the settings and mail handling sequence for the mail process that require the Type of stamp [Date correction]. Use this Type of stamp to correct the postage date [mdash ] for example, to dispatch tomorrow a letter that has already been stamped today.
To select an option in the screen: – Highlight the option using the arrow keys – Then press to validate your selection. Select [Date correction] and press [OK] to validate Change the postage date. Today's date is printed by default. To change the date, press Imprint to access the screen, and then select >...
Page 56
Insert the mail piece into the mail path against the rear-guide wall, side to printed facing upwards. If mail piece is bigger than mail path maximum thickness (see Mail Specifications p.191), press before you press print a label. The label is printed. The Mailing System applies postage and the mail piece (or label) is sent to the catch tray.
[Amount Correction] Mode (if available) [Amount Correction] Mode (if available) In this Section This section describes the settings and mail handling sequence for the mail process that require the Type of stamp [Amount correction]. Use this type of stamp to correct the postage amount. Only additions are possible (to increase the postage amount).
To select an option in the screen: – Highlight the option using the arrow keys – Then press to validate your . Select [Amount correction] in the list and press [OK] to va- lidate. Enter the additional postage amount. From the Home screen: Amount - Begin to type in the amount (keys 1 to 9 or dot).
Page 59
Insert the mail piece into the mail path against the rear-guide wall, side to printed facing upwards. If mail piece is bigger than mail path maximum thickness (see Mail Specifications p.191), press before you press print a label. The label is printed. The Mailing System applies postage and the mail piece (or label) is sent to the catch tray.
Printing [Received] for Incoming Mail Printing [Received] for Incoming Mail In this Section This section describes how to use the [Received] type of stamp, to: Print the date on incoming mail, and/or • Print 'Received' on incoming mail. • See also Choosing a Type of Stamp About the use of the Type of stamp, see p.25).
To select an option on the screen: – Highlight the option using the arrow keys – Then always press to validate your selection. To change the type of stamp, select the Type line, press [OK] Type of stamp and then select [Received] from the screen and press [OK].
Running [No Printing] Mail Running [No Printing] Mail This section describes how to use the [] type of stamp, for: Conveying mail for sealing mail without printing. • Only conveying mail, for counting or testing purposes. • See also Choosing a Type of Stamp About the use of the Type of stamp, see p.25).
To change the type of stamp, select the Type line, press [OK] Type of stamp and then select [No printing] in the screen and press [OK]. Press to return to the home screen. You are now ready to process mail. Running Mail How to Process Mail without Printing (Running Mail) How to Process...
Settings Details Settings Details Changing the Current Account To process a batch of mail pieces using another account (on account-enabled con- figurations), change the account as follows. How to Change Accounts How to Change To change accounts: Accounts As a user: Press and type or select the path:...
Selecting a Rate Selecting a rate allows the Mailing System to calculate the postage amount when the mail piece weight is available, either from a weighing device or, for big parcels, How to Enter the Weight Manually entered manually (see p.66).
Page 66
through the rate selection process of all types of mail. To select an option on the screen: Highlight options using the arrow keys • Use the arrow keys to scroll from screen to screen • Then press to validate your selection. •...
Entering Postage Manually (if available) To enter the postage amount manually, follow the procedure below. How to Enter Postage Manually How to Enter On the home screen: Postage Type directly the first figure of the amount using the keypad. Manually Manual amount screen appears.
Selecting a Pre-Paid Imprint (PPI) You can select the PPI to use in a list. When selecting the PPI type of stamp, a default PPI is automati- cally selected. See also How to Change the Default PPI p.140. • Managing Prepaid Imprints (PPI) p.163.
Page 69
Choosing a Weighing Type Depending on the accessories and features on your Mailing System, several weighing methods are available. You can also enter the weight manually if you know it: see How to Enter the Weight Manually p.66. Choosing a Weighing Type Depending on the type of mail you want to process, choose a weighing method ac- cording to the recommendations in the table below.
You can leave all the mail pieces in a tray on the Weighing Platform: the Mailing System will ask you to confirm printing for the last item removed (from the tray). Differential Weighing Auto-Tape ( ) (optional) • Differential Weighing This mode is identical to except that the system automat- ically prints the postage on labels.
Entering Weight Manually You can enter the weight manually if a mail piece exceeds the weighing capacity of all your weighing platform. If this situation occurs, you will need to print the postage amount on a label to stick onto the mail piece. How to Enter the Weight Manually How to Enter the To enter the weight manually from the home screen, you must...
Configuring the Stamp Depending on the current Type of stamp, you can modify the elements printed on mail pieces as follows: Change printed date • Add a pre-loaded Ad die to the left of the stamp • Adding a custom text to the left of the stamp (if allowed). You must first create it in •...
icon indicates the current selection. Press [OK] to apply changes and return to the configuration menu. Adding Text and/or Ad Die to the Stamp You can add a text (if allowed) and/or an ad die to the stamp, as illustrated below. Elements of a stamp imprint See also Managing Custom Text Messages (if available)
See also Managing Custom Text Messages (if available) p.158 • How to Add (or Cancel) an Ad Die on the Stamp How to Add (or To add an ad die to the stamp or cancel the ad die: Cancel) an Ad Either: Die on the Stamp Press...
Page 75
1 -Imprint printing offset How to Move the Stamp (Print Offset) How to Move the To add an offset to the stamp position: Stamp (Print As a user: Offset) Press and type or select the path: > Job settings > Print position Print position setting screen is displayed.
Page 76
Using Imprint Memories Imprint Memories allow you to create a preset memory that can include the rate, custom text, ad die and date mode for the Type of stamp you would like to use. In account-activated configurations, Imprint Memories allow you assign postage costs to pre-selectedaccounts.
Advanced Operations 3.10 Advanced Operations Emergency Stop If you want to stop the system in the event of an emergency: How to Enable an Emergency Stop How to Enable To stop the run process immediately: an Emergency Press Stop Using Batch Counters Batch counters allow you to track and report pieces (items) and postage (value) since the last counter reset.
Page 78
press [OK]. The total number of items is displayed. You must first weigh 10 (ten) items in order to get the count of the total number of items.
Filling the Label Dispenser How to Fill the Automatic Label Dispenser How to Fill the To fill the Label Dispenser: Automatic Label Stack the labels and insert them in the dispenser, face to print on the right-hand side and peel-off tab on the top. Dispenser Push the block of labels down until you feel the label “click”...
Money Operations 4 Money Operations This section describes how you can load and manage money in your Mailing System to allow postage operations. Overview ................77 Managing Funds ..............78 How to Check the PSD (Meter) Funds................78 How to Add Funds to the PSD (Meter) ................79 Unlocking the PSD (Postal Inspection) .........
Overview Overview The Postal Security Device (PSD) [mdash ] Postage Meter The PSD, located in the base, handles the funds (or money) in your Mailing System. The PSD performs all necessary operations to comply with the postal standards. To do so, regular connections to the Postal Services are necessary. Check that your Mailing System is connected to a telephone line Connections or network (see...
Managing Funds Managing Funds Checking Funds You can check the total postage used and the remaining funds in the PSD at any time. To check that the funds are available to complete your current task. Use the following steps to display your available postage funds. How to Check the PSD (Meter) Funds How to Check To check available funds:...
Adding Funds You can add funds to your Mailing System at any time by complete the steps listed below. The Mailing System then connects to the Postal Server and validates the operation. How to Add Funds to the PSD (Meter) How to Add To add funds to the PSD: Funds to the PSD...
Page 85
In the case of a communication error, the amount previously entered cannot be changed. Check connection settings (see p.148). Funds Used / Funds Available You can open the screen to check your account balance once the transaction is complete How to Check the PSD (Meter) Funds (see p.78).
Unlocking the PSD (Postal Inspection) Unlocking the PSD (Postal Inspection) Manual Call The postal service requires your postage meter (PSD) to periodically connect for postal security regulation. If you have not connected your system after a period your system will automatically be deactivated. If your system is deactivated, you have to perform a connection to the Postal Services to unlock the PSD.
Page 87
The date of the next call is displayed on the screen.
Managing Accounts and Assigning Rights 5 Managing Accounts and Assigning Rights This section describes how you can manage accounts as the supervisor to track postage funds usage and/or set access rights to a variety of functions on your Mailing System. Accounting and Assigning Rights Overview ......85 Selecting an 'Account Mode' ..........86 Guidelines to Setup an Account...........87...
Accounting and Assigning Rights Overview Accounting and Assigning Rights Overview Postage Tracking and Access Control Your Mailing System allows you to track postage by account/department and to add security to prevent unauthorized use of a variety of functions. Track postage expenditures: the Accounts function •...
Selecting an 'Account Mode' Selecting an 'Account Mode' Introducing the 'Account Modes' The 'Account mode' allows you to set up both the Accounts and the Access Control Accounting and Assigning Rights Overview functions (see p.85). The table below lists the functional access control for each account mode. Access Control Function 'No account' 'No account with access...
Guidelines to Setup an Account Guidelines to Setup an Account See also Selecting an 'Account Mode' p.86. • Setting up 'No Account' The 'No Account' mode provides users with unlimited access to the system (self- service type). This is the default mode in your Mailing System. Implementing “No account”...
Setting up 'No Account with Access Control' If you want to prevent unauthorized use of the Mailing System and do not want to use accounts, use the “No Account with Access Control” mode. This provides a single PIN code for all authorized users. This is the default mode in your Mailing System.
Page 94
Setting up 'Accounts' In 'Accounts' Mode, users must select an account before they can process their mail. The user can change accounts at any time during mail processing. If only one account is available, the Mailing System automatically selects it at start up. Implementing the “Accounts Mode”...
Page 95
Setting up 'Remote Account Management' 'Remote Account Management', allows you to manage accounts and/or operator PINs from a PC-based software program (MAS). The PC application provides advanced postal and/or shipping expense management in order to monitor, track and control your mailing and shipping costs. You can allow the Mailing System to be used even when not connected to the PC.
Selecting an 'Account Mode' Selecting an 'Account Mode' See also Guidelines to Setup an Account p.87. • How to Display and Change the 'Account Mode' How to Display To display and change the 'Account mode': and Change the How to Log in as Supervisor As supervisor (see p.126): 'Account Mode'...
Managing Accounts Managing Accounts Selecting an Account Mode Accounts You can only manage accounts in the Mode. Setting up 'Accounts' Before creating accounts, see p.89. Account names must be unique within the system. Account Information The number of accounts you can create is set to 25 by default and can be increased to 100 if required.
Importing/Exporting You can also import a list of accounts. See Account Lists p.96. See also Account Information p.92. • Creating Accounts How to Create an Account How to Create How to To Create an account activate the mode “accounts”. See Display and Change the 'Account Mode' p.91 an Account...
Press [OK] to confirm the creation of the account. Editing Accounts Use the following steps to modify an account name or account status. The account number cannot be edited once it is created. How to View / Edit Account Information How to View / To view or edit an account: Edit Account In-...
status: active or inactive) and press [OK]. Account modifi- Accept the changes by pressing [OK] on the cation summary If an account is deactivated it is no longer visible to the operator. Deleting Accounts You may need to delete an account. How to Delete an Account How to Delete To delete an Account:...
Importing/Exporting Account Lists You can import an account list to or export an account list from your mailing machine as a CSV file using OLS or a USB memory key. Imported accounts are created and added to the existing account list as unformatted accounts.
To add accounts to your Mailing System, export the current account list and modify it before re-importing it into the Mailing System. See also Account Information Maximum number of accounts: p.92. • How to Import Accounts How to Import To import accounts from a CSV file: Accounts How to Log in as Supervisor As supervisor (see...
Reports 6 Reports This section explains how you can access and print reports for your Mailing System. Reports Overview ..............101 Generating a Report ............103 How to Generate a Report (as a User) ................. 103 How to Generate a Report (as Supervisor) ............
Reports Overview Reports Overview As a user or supervisor, you can get a range of reports to regularly view, print or store information regarding your Mailing System usage, funds usage, account expen- ditures, etc. Your Mailing System can also upload basic data that can be viewed online. Enhanced online postal expense management reporting can be added as an option.
Page 107
Report name Report description Output Page Devices Account List List of accounts in the system (supervi- p.110 sor only). Single Account Usage for a specific account selected p.111 in an account list, for a selected period. Multi-Accounts Usage on all accounts in a selected p.112 period.
Generating a Report Generating a Report To generate a report, select the desired report, and choose how you want to display or record the report: On screen • On an external printer (if any) • On a label • On a USB memory key •...
Counter Data Counter Data Batch Data Report This report displays the batch counter and the postage spent for outgoing mail (type of stamp [Standard]) since the last reset. Requirements To generate this report, you have to be logged in as a user. Output: Screen USB printer...
Page 110
Received Batch Data This report displays the batch counter for incoming mail ('Received on') since the last reset. Requirements To generate this report, you must be logged in as a user. You must be in [Received] stamp type to view incoming mail batch counter. Outputs Screen.
Postage Data Postage Data Daily Usage Report This report displays, for each day of the selected period, usage data such as total items and total postage value. Requirements This report is available as a user or supervisor. You have to specify the Begin date and the End date of the report. When you specify the Begin date, the End date field is filled with a proposed value: Begin date + 31 days.
Page 112
Monthly Usage Report This report displays, in a selected period and per month, the total items and total postage used. Requirements This report is available as user or supervisor. You have to specify the Begin date and an the End date of the report. Use the se- lection of month and year.
Funds Data Funds Data Funds Summary Report This report displays the information on funds usage since the installation of the system. The content is limited to the history available in the PSD. Requirements This report is available as user or supervisor. Output: On label Screen...
Page 114
Adding Postage Report This report displays the last postage refill operations performed on the machine in a selected period. Requirements For this report, you have to be logged in as a supervisor. Output: Screen USB printer USB memory key Fields Comments Period Default period:...
Account Data Account Data Account List Report This report displays the list of accounts in the system. Requirements To generate this report: You have to be logged in as a supervisor • The current 'Account mode' has to be Account •...
Single Account Report This report displays postal expenditures for one account over a selected time period. You can select any account from the list. Requirements This report is available as a user or a supervisor. The current account mode has to be 'Accounts' or 'Accounts with access control'. You have to select an account in the list of accounts, then the Begin date and the End date of the report.
Page 117
Multi Account Report This report displays postal expenditures for all the accounts over a selected time period, sorted by ascending account number. The report displays all the accounts in 'active' status, and accounts 'inactive' or 'deleted' with a postage value. Requirements This report is available as a user or a supervisor.
System Data System Data Machine Configuration Report This report displays all supervisor settings. Requirements To generate this report, you have to be logged in as a supervisor. Outputs: Screen USB printer USB memory key Fields Imprint default settings (Default Text, Default Ad die, Default Rate) Date advance parameters Funds settings (High value, Low Funds) Connections settings (phone numbers)
Online Services 7 Online Services Online Services for your Mailing System allow you to very easily achieve tasks such as updating postal rates, system software or optional features, and using services such as mail follow-up online. Online Services Overview............ 117 Connecting to Online Services ..........
Online Services Overview Online Services Overview The Online Services simplify the use and the update of your Mailing System. Online Services features and capabilities include: Online reporting: the usage of your machine is available from your personal, • secure web account, simplifying tracking and reporting of your postage expenses. Rate Updates: maintain current postal rates with automatic, electronic, convenient •...
Connecting to Online Services Connecting to Online Services Automatic calls Automatic calls To fully benefit from the convenience and power of Online Services, your Mailing System should permanently be connected to a live analog telephone line or network connection so that it can link to the Online Server automatically whenever required. For the usage of some services, some automatic calls are scheduled to upload cor- responding data.
How to Call Online Services Manually (as a User) How to Call To trigger a generic call Online Services As a user: Manually (as a Press and type or select the path: User) > Online services > Generic call The Mailing System connects to the server and downloads the available elements (rates, ad dies, etc.).
Testing the Connection to Online Services You may test the connection to the Online Services server via the commands in the Online Services menu: Ping server • Establishes a connection and checks whether the server answers to a 'ping' command. This test: Connection Settings Validates connection parameters (see p.148)
Uploading Statistics Uploading Statistics This manual call uploads report data to the Online Services server, so that you can display reports that integrate the latest figures on your Online Services web page. Otherwise, automatic calls upload report data to the Online Services server at the end of each month.
System Online Services System Online Services Ink Management Service The Ink Management service sends an electronic message to the Online Services server when the mailing machine’s ink supply is running low. An e-mail message then informs you of that condition so that the ink cartridge can be replaced in time.
Configuring your Mailing System 8 Configuring your Mailing System This section describes the general settings you can apply to your Mailing System. Some of them can be managed directly by all users whereas most of them require access as supervisor . Settings Overview...............
Page 129
Postage Imprint Default Settings........140 How to Change the Default Rate .................140 How to Change the Default PPI ................140 How to Change the Default Text ................141 How to Change the Default Ad Die ..............141 How to Set the Automatic Date Advance Time ............143 How to Set the Default Printing Offset ..............144...
Settings Overview Settings Overview This section describes two types of settings that are available on your system: User settings, that only last as long as the user who applies them is logged in • Supervisor settings, sets the default or permanent settings of your Mailing System. •...
Logging in / out as the Supervisor Logging in / out as the Supervisor You need to be logged in as supervisor to configure the Mailing System and perform functions such as managing accounts and access rights, generating certain reports, etc.
Changing the Display Language Changing the Display Language You can choose a language among those available in the Mailing System for your mailing session (3 languages maximum). How to Change the Display Language How to Change To change the current display language: the Display As a user: Language...
Enabling/Disabling Sounds Enabling/Disabling Sounds You can enable or disable the system beeps separately: Beeps on keys • Beeps on warnings and errors. • How to Enable / Disable the Beeps How to Enable / To enable or disable the beeps: Disable the As a user: Beeps...
Display Settings Display Settings You can adjust the contrast of the display for bright or dark working environments. How to Adjust the Display Contrast How to Adjust To adjust the display contrast: the Display As a user: Contrast Press and type 11.3 or select the path: >...
System Time-outs and Settings System Time-outs and Settings System settings include: System motor time-outs • Sleep mode time-out • Smart Start: function that automatically starts the system motors when you • Choosing a Weighing withdraw the mail piece from the weighing platform (see Type p.64).
This is a user setting that only lasts as long as you are logged in. Setting Default Time-Outs How to Change System Time-Outs How to Change To change the system time-Outs: System Time- How to Log in as Supervisor As Supervisor (see p.126) Outs Press...
Smart Start The Smart Start function detects when you are removing a mail piece from the weighing platform and automatically starts the system motors without you having to press the key. How to Activate / Deactivate Smart Start How to Activate To activate / deactivate the Smart Start function: / Deactivate How to Log in as Supervisor...
High Value, Low Funds Warnings and PIN Codes (if present) High Value, Low Funds Warnings and PIN Codes (if present) Warnings Your Mailing System can warn you that the postage amount that you have typed is higher than a preset value. This high-amount warning prevents you from accidentally printing high postage amounts.
Funding PIN Code You can create a funding PIN code to control access to only those who are authorized Money Operations to add postage. (see p.75). How to Set/Cancel a Funding PIN Code How to Set/ To set a funding PIN code: Cancel a How to Log in as Supervisor As supervisor (see...
Weighing Settings Weighing Settings The weighing settings include: Setting a default weighing type used for mailing • Activating/ De-activating the WP Automatic Selection functionality. • Zeroing the weigh platform • Setting the GEO code that corresponds to the geographical location of the Mailing •...
Weighing Platform Automatic Selection This functionality shall be implemented for improving the user productivity and the ease of use of the mailing system. The user is able to change the weighing type to the WP standard weighing by putting a mail piece onto the WP. The WP standard weighing is automatically selected when a weight increase is detected on the WP.
Zeroing the Weighing Platform You can reset the Weighing Platform in the following ways: Set to zero: resets the weight to zero • Tare: sets the weight to zero with an additional tray on the Weighing Platform • Rezero: physically adjusts the Weighing Platform to zero. •...
How to Tare the Weighing Platform How to Tare the To tare the Weighing Platform: Weighing How to Log in as Supervisor As supervisor (see p.126): Platform Press and type 6.1.1 or select the path: > System settings > Weighing functions > Weigh Platform Tare Press [OK] to tare the Weighing Platform.
GEO Code The Weighing Platform calculates mail piece weights that have to be corrected ac- cording to the geographical location of the Mailing System, as weights can change with the altitude and latitude. The correcting geodesic code may be entered: Automatically with Online Services •...
Postage Imprint Default Settings Postage Imprint Default Settings The settings of the postage imprint 'by default' include: Stamp default settings: sets the default rate, text and ad die for mailing operations • Automatic Date Advance: enables early date change to continue printing postage •...
Press and type 3.3.4 or select the path: > Default user settings > Default imprint parameters > PPI Select the default PPI in the list. Press [OK] to validate. See also How to Select a PPI To change the current PPI, see p.63.
Page 147
Press and type 3.3.2 or select the path: > Default User Settings > Default Imprint Parameters > Ad Select the default ad die from the list, or None for no ad die. Press [OK] to validate.
Automatic Date Advance The Automatic Date Advance function automatically changes the date printed on mail pieces at a preset time to the next 'working day' date. Example: You can set the system to change dates at 17:00 hours and set Saturdays and Sundays to be non-working days.
Printing Offset The printing offset is the distance between the right edge of the envelope and the imprint. You can increase the distance by about 5 mm or 10 mm. How to Set the Default Printing Offset How to Set the To change the default printing offset: Default Printing How to Log in as Supervisor...
Imprint Memories 8.10 Imprint Memories The Imprint Memories are presets for your stamp types. As a user, you can quickly recall a saved setting to simplify operation and save time Using Imprint Memories (see p.71). As supervisor, you can create, edit/modify or delete an Imprint Memory. Each Imprint Memory is identified by a name and a number.
Managing Imprint Memories How to Create an Imprint Memory How to Create To create an imprint memory: an Imprint As supervisor (see How to Log in as Supervisor p.126): Memory Press and type or select the path: > Predefined imprint management Imprint The current list of imprint memories is displayed in the memories...
How to Delete an Imprint Memory How to Delete To delete an imprint memory: an Imprint How to Log in as Supervisor As supervisor (see p.126): Memory Press and type or select the path: > Predefined imprint management Select an imprint memory from the list of saved imprint me- mories.
Connection Settings 8.11 Connection Settings Connection to the Postal Services or Online Services To add funds or access Online Services, the Mailing System can use the following networks: An analog / fax telephone line through an analog modem • An Internet access through a high speed LAN (Local Area Network). •...
Analog Telephone Line and Modem Settings These settings include the modem parameters and the telephone number that the Money Op- Mailing System calls to fund the meter or connect to Online Services (see erations p.75). How to Set the Make sure the telephone line is selected: see Postal/Online Services Connection p.148.
Time and Date Management 8.12 Time and Date Management Daylight Savings Time Transitions Your Mailing System normally auto-adjusts to Daylight Savings Time. However, if a manual adjustment is necessary, you can use either of the following procedures to correct the Mailing System time: How to Unlock the PSD As a user: p.81...
Options and Updates 9 Options and Updates This section describes how you can upgrade your system by adding optional functions and elements of stamp such as latest postal rates, additional texts or ad dies. Options and Updates Process..........153 How to Access the Options and Updates Menu ..........
Options and Updates Process Options and Updates Process You can update your Mailing System by: Adding new options, such as Differential Weighing or increasing the maximum • number of accounts Update postal Rates and Prepaid Postal Imprints (PPI) • Creating additional Texts for the stamp •...
Using the Mailbox Using the Mailbox The mailbox allows you to receive messages from the Mailing System or from customer service via the server. On the home screen, an icon indicates that the mailbox contains unread messages. Mailbox list screen indicates unread messages and allows you to delete read messages.
Delete message Select to erase the message. How to Delete Messages How to Delete How to Log in as Supervisor As supervisor (see p.126): Messages Press and type or select the path: > Mailbox Mailbox screen is displayed. Select the message to be deleted and press [OK]. Delete message Select to erase the message.
Managing Options Managing Options Consulting the Option List The option list includes the options actually loaded into your Mailing System and in- dicates the options that are activated. You can also display details for each option. For more information about the options you can add to your Mail- ing System, please contact customer service.
Activating New Options Process for Activating Options You can activate new options by connecting the Mailing System to Online Services server. New available options are automatically downloaded into your Mailing System and activated. Contact customer service to have new options ready for down- loading on the Online Services server.
Managing Custom Text Messages (if available) Managing Custom Text Messages (if available) You can enhance your mail and increase the “openability” of your mail by adding custom text messages to the left of the stamp. As supervisor, you can: Add custom text messages (and create a name for menu selection) •...
Enter the name to be displayed on the menu for users, then press [OK]. How to Modify or Delete a Text Message How to Modify To modify or delete text: or Delete a Text How to Display the List of Text Display the list of text.
Managing Ad Die Managing Ad Die The Ad dies are graphical slogans you can add on the left hand side of the stamp printed on mail pieces. As supervisor, you can: Display the list of ad dies • In the list, rename or delete ad dies ...
To change the name of the ad die: Edit Select Change the ad die name using the keypad and press [OK]. The system updates the ad die list. To delete the ad die: Delete Select The system asks for a confirmation. Press [OK] to confirm deletion.
Managing Postal Rates Managing Postal Rates Your Mailing System uses rate tables to calculate postage amounts. As supervisor, you can: Display the list of rate tables and see which table the system is currently using • Download new postal rate tables. •...
Managing Prepaid Imprints (PPI) Managing Prepaid Imprints (PPI) As supervisor, you can: Display the list of PPIs in the machine • Add new PPIs using an USB memory key • Delete PPIs • How to Change the Default PPI Set the default PPI (see p.140).
Page 169
Confirm deletion, otherwise press The system updates the PPI list.
Updating System Software Updating System Software Occasionally it will be requested that you download new software for your Mailing System. The software package may include feature enhancements or updates. Also, if you purchase an additional service, you may be required to download the software to support this new service.
Page 171
After downloading The Mailing System indicates it has to be re-started. Disconnect and reconnect the Mailing System power cord Connection Diagram (see p.20. After restarting, the Mailing System calls the server to confirm installation. The Mailing System is ready for use with the new software. No information is lost during the updating process: your data and settings remain unchanged.
Maintaining your Mailing System 10 Maintaining your Mailing System This section contains important information about the maintenance of your Mailing System in order to keep it in good condition. 10.1 Maintaining the Ink Cartridge ..........169 How to Display Ink Level and Cartridge Data ............... 170 How to Display Ink Level and Cartridge Data .............
Maintaining the Ink Cartridge 10.1 Maintaining the Ink Cartridge About the Ink Cartridge The ink cartridge for printing is located in the Mailing System and contains ink that has been tested and approved by the postal service. The ink cartridge uses ink jet technology. It requires the print head nozzles to be cleaned regularly to provide a good printing quality.
Displaying Ink Level and Cartridge Data You can display the ink level and other cartridge data, such as: Ink consumed in percent • Ink color • Cartridge status (present or not present) • First used date • Best before Also check the date on the cartridge box.
Setting the Headset Alignment Aligning the print heads is required if there is an between the top and the bottom of the imprints. Your Mailing System requires the heads to be aligned after each cartridge change. How to Align the Print Heads How to Align the To align the print heads: Print Heads...
Cleaning the Print Heads If the printing on envelopes or labels looks unclear or dirty in some way, clean the headset to restore the print quality. If the headset has to be cleaned too often, change the automatic cleaning interval as indicated.
Changing the Ink Cartridge The Power cord must be plugged in to move the cartridge into the 'replacement' position. How to Change the Ink Cartridge How to Change Open the cover: the ink cartridge moves to the the Ink Cartridge replacement position.
Page 180
Insert the new ink car- tridge, and then push it forward until you hear the click. Close the cover. The alignment process of the printing heads starts automatically.
Filling the Moistener (if available) 10.2 Filling the Moistener (if available) The hand-feed table uses water for sealing envelopes if a moistener is installed. When the system is out of water, the mailing process can continue but the envelopes are not sealed properly. How to Fill the Moistener How to Fill the To add water to the moistener.
Cleaning the Mail Path 10.3 Cleaning the Mail Path Cleaning the mail path includes: Cleaning moistener brushes and sponge (if installed). • Cleaning the Mailing System sensors on the mail path. •...
Running the Installation Wizard You may wish to run the installation wizard after a system update. How to Run the Installation Wizard How to Run the To run the installation wizard: Installation How to Log in as Supervisor As supervisor (see p.126): Wizard Press...
Performing the Update Registration Procedure to Change your Address This procedure is to be used if you have changed address. First contact your Customer Service to update your details, then you will be instructed to perform the update registration procedure. Updating Registration Check that your Mailing System is connected to the network before starting.
Troubleshooting 11 Troubleshooting This section helps you solve problems you may encounter while using your Mailing System. 11.1 Paper Jamming ..............183 How to Clear Mail Jammed in the Base................ 183 11.2 Label Jamming..............184 How to Clear a Label Jammed in the Base..............184 11.3 Weighing Problems ............
Paper Jamming 11.1 Paper Jamming Base Jamming Envelopes are stopped in the transport mechanism of the Base. Possible causes Actions Mailpiece is too thick. 1 Clear the Base as indicated below. • Mail size is incorrect. • 2 Correct the cause indicated in the left column: Mail Specifi- Mail sizes: see...
Label Jamming 11.2 Label Jamming A Label is Jammed in the Base Possible causes Actions A label is blocked in the Automatic Clear the label as indicated below. Label-Dispenser or in the transport mechanism of the system base. How to Clear a Label Jammed in the Base How to Clear a To clear a label jammed in the Base: Label Jammed in...
Weighing Problems 11.3 Weighing Problems The Weighing Device does not Weigh Properly If the Base does not display a correct weight, complete the following actions to correct the problem. You have to check the weighing device as follows. Possible causes Actions The weighing device is not See the weighing type selection procedures in...
Diagnostics and System Data 11.4 Diagnostics and System Data Diagnostics allow you to find the root cause of a an issue or a breakdown that may occur during the life of your Mailing System. The system performs tests automatically to diagnose the problem and generate cor- responding reports.
How to Access Diagnostic Data How to Access To gain access to a diagnostic data: Diagnostic Data How to Log in as Supervisor As supervisor (see p.126): Press and type or select the path: > Maintenance > Diagnostics The system requires you press [OK] to start the diagnostic tests, then displays the list of the tests.
How to Display the Event Lists How to Display To display the event lists: the Event Lists How to Log in as Supervisor As supervisor (see p.126): Press and type 7.1.3 or select the path: > Maintenance > System info > Event list Select the >...
Specifications 12 Specifications This sections contains the main specifications of your Mailing System. 12.1 Mail Specifications .............. 191 12.2 Recommended Operating Conditions ....... 192 12.3 General Specifications ............193 12.4 Operating Specifications ............ 194...
Mail Specifications 12.1 Mail Specifications Envelope Specifications Envelope Dimensions (note: Your Mailing System can handle the envelope & flap sizes as illustrated below the illustration is not on scale) Envelope Weight 2.83 g 750 g Envelope Thickness 0.2 mm 10 mm...
Recommended Operating Conditions 12.2 Recommended Operating Conditions Temperature and Relative Humidity Your Mailing System should only be operated in the following conditions: Temperature range Ambient temperature: 50°F - 104°F. Relative humidity 80% max. without condensation. Weighing accuracy To obtain the best weighing results, use a solid and steady table: Away from any doors •...
General Specifications 12.3 General Specifications Dimensions (mm) (Width x Length x Height) Base: 283 x 378 x 300 • Weight Base: 10 kg • Auto Feeder: 6.5 kg • Catch tray: 60g •...
