- Page 1 IS-350 Self Installation Guide...
- Page 2 CONTENTS IS-350 Plain Feed Deck or PSD (Postage Meter) Ink Cartridge Power Cord Mailing System Feed Deck With Moistener (varies with models) Optional LAN Cable or Modem and Phone Cord Operator Manual Postage Meter Tapes...
- Page 3 STEP 1 INSTALL THE FEED DECK Feed Deck With Moistener Plain Feed Deck Remove the three pieces of (varies with models) shipping tape on each side Place the Feed Deck to the left of the Mailing System. of the Mailing System. Lift up and lockdown the slots of the Mailing System base over the tabs of the feed deck.
- Page 4 STEP 2 INSTALL POSTAGE METER Open the Mailing System Cover. Remove the PSD (Postage Meter) from the packaging. Open top cover by lifting at the open slot. Insert the Postage Meter into the Mailing System. 1. Open the Postage Meter Cover on the left side.
- Page 5 STEP 3 INSTALL INK CARTRIDGE Remove the Ink Cartridge from Close the Mailing System Cover. the packaging. Remove the film strips from the bottom of the Ink Cartridge. Insert the Ink Cartridge into the Mailing System. 1. Slide the Ink Cartridge into the slot located on the right, positioning the cartridge with the contacts facing the rear of the system.
-
Page 6: Configuration And Activation
STEP 4 CONFIGURATION AND ACTIVATION Set-up the connection to the server, contact the server, and activate the Mailing System. In order to load funds, download rates, and support your Mailing System, you must set-up a connection between the Mailing System and the server. This can be done in two different ways: 1. -
Page 7: Connecting The Lan Cable
STEP 4A CONNECTING THE LAN CABLE Connect to internet / LAN jack Connect the other end of the Connect the power. or router. LAN cable into the internet jack Using the Power Cord, plug the female or router on the left side of the 1. - Page 8 STEP 4A CONNECTING THE LAN CABLE CONTINUED Installation process Installation process Installation process 1. Modem Welcome, please press Press Next to select your 2. LAN "Ok" to begin the Connection Type. Installation Process Back Next MENU MENU MENU Press the “Down Arrow” button Press the “OK”...
- Page 9 STEP 4A CONNECTING THE LAN CABLE CONTINUED Installation process Your LAN connection is about to be checked. Please plug in the cable. Next MENU Select “Next” by pressing the “OK” button.
-
Page 10: Connecting The Modem
STEP 4B CONNECTING THE MODEM (OPTIONAL ACCESSORY REQUIRED) Select a location for the Connect the modem. Connect the power. Mailing System near an analog 1. Plug one end of the telephone cable into Using the Power Cord, plug the female telephone jack. - Page 11 STEP 4B CONNECTING THE MODEM CONTINUED (OPTIONAL ACCESSORY REQUIRED) Installation process Installation process Installation process Welcome, please press Press “Next” to select your 1. Modem 2. Lan “Ok” to begin the Connection Type. Installation Process. Back Next MENU MENU MENU Press the “OK”...
- Page 12 STEP 4B CONNECTING THE MODEM CONTINUED (OPTIONAL ACCESSORY REQUIRED) Installation process Do you need pre x for external calls? MENU Enter a prefix if needed. If your phone requires a number to reach an outside line (for example if you have to dial 9 first), select “Yes”...
- Page 13 STEP 5 ACTIVATE THE POSTAGE METER (PSD) Installation process Server call Installation process Do you want to check the Do you want to add Ping connection? Press postage? Server connection “Continue” to check it or completed. press “Quit” to skip this Quit Continue MENU...
- Page 14 STEP 5 ACTIVATE THE POSTAGE METER (PSD) CONTINUED Installation process Server MOD Server call Press “Next” to start the Initiate declaration succ... Declaration E-Services Declaration SLC205 Initiate Server Connection Process. Declaration succeeded! completed. You must connect to Next Complete declaration to MENU MENU MENU...
- Page 15 STEP 5 ACTIVATE THE POSTAGE METER (PSD) CONTINUED Installation Process Set headset alignment Do you want to do the Press OK to print test headset alignment? imprint. MENU MENU Select “Yes” by pressing the “OK” Insert a blank envelope into the Press the “OK”...
- Page 16 STEP 5 ACTIVATE THE POSTAGE METER (PSD) CONTINUED Set headset alignment Installation process Select letter with arrows Installation process is and press “Ok” nished. Press “Ok” to access to the homescreen. MENU MENU Choose which line on the imprint Using the up and down arrow Press the “OK”...
- Page 17 STEP 6 LOADING FUNDS (POSTAGE) INTO THE POSTAGE METER Funds Funds 1. Funds used / available Funds Available 2. Add funds $10.000 3. Postal inspection Amount to Add 0.000 MENU MENU Press the “Funds” button. Use the down arrow to select Enter the amount to add using “Funds”.
- Page 18 STEP 7 PROCESS MAIL Can Letter $00.00 Can Letter No Services $00.00 No Services 2011.08.19 2011.08.19 Mem: Mem: MENU MENU The Home screen will be Verify that the weighing method Place the envelope on the scale. displayed. icon is displayed on the home Can Letter The weight of the envelope will be $00.00...
- Page 19 STEP 7 PROCESS MAIL CONTINUED Can Letter $00.00 No services Mailing Shipping Marketing Services Wizard MENU Press the “stamp” button to Select the mail class or select Press the “print” button, then change the rate if not using option 8 “Wizard” to show all put the envelope on the feed 1st Letter/Flat rates.
- Page 20 ADDITIONAL INSTALLATION HELP For more information on installing your IS-350 Mailing System please refer to your IS-350 Operator Manual or contact our Customer Care Centre at 1-800-661-0200 1-800-661-0200 www.neopost.ca Neopost and the Neopost logo are registered trademarks of Neopost Canada. All other company and product ®...
