Matrox RAD Series User Manual page 10

Note:
monitor that uses digital input, usually a
flat panel monitor) to your Matrox
product, your monitor must have a DVI
connector.
If you have an analog monitor (a monitor
that uses analog input) with a DVI
connector and you want to connect it to
an HD-15 connector, you'll need a separate adapter. If this adapter isn't included with your
monitor, contact your monitor vendor.
Some monitors with DVI connectors support both digital and analog input. If you're using
one of these monitors with your Matrox product, make sure it's configured to use the
correct type of input. For more information, see your monitor documentation.
Connect the second monitor
2
If your second monitor has a DVI connector,
connect it directly to the secondary
connector (
If your monitor has an HD-15 connector,
use a DVI-to-HD15 adapter to connect your
monitor to the main connector. If you need
a second DVI-to-HD15 adapter, contact
your computer vendor.
Note:
on. Otherwise, the software may not be able to properly detect your monitors.
Note:
and, through Matrox PowerDesk software, you can re-order your displays to match your
Windows desktop. For more information, see Matrox PowerDesk help.
Your Matrox card is now installed. Restart your computer and install your Matrox software
"Software setup", page
10 Matrox RAD Series – User Guide
To connect a digital monitor (a
) of your card.
B
Whenever you restart your computer, make sure your monitors are already turned
The left-to-right order of your displays isn't dependent on your connection setup
12).
HD-15 connector (analog)
DVI connector DVI connector
(digital) (analog/digital)
Monitor connector (DVI)
Monitor connector
(HD-15)
(see
