Master Codes; Sub-Master Codes - CODELOCKS CL2000 Programming And Operating Instructions

ONE TIME USER CODE - PROGRAM 07
#Master Code • 07 • One time code ID (eg 81)
Code (eg 4321) ••
Result: Code 4321 in position 81 will work once and then
be removed from memory
Note: ID Positions 81 to 90 are reserved for this
program function, allowing up to 10 One-Time
User Codes to be entered.
SET CODE FREE MODE - PROGRAM 08
#Master Code • 08 ••
Result: Lock will be continuously unlocked
CANCEL CODE FREE MODE - PROGRAM 09
#Master Code • 09 ••
Result: Lock will revert to normal operation
*
CHANGE MASTER CODE - PROGRAM 10
#Master Code • 10 • enter length of Master Code followed by
new Master Code (eg 6, 123456)
Code followed by new Master Code (eg 6, 123456)
Result: Master Code now changed to #123456
Note: If the length of the Master Code is changed
then all previous User Codes will be deleted
• One time
• confirm length of Master
••
•
Code accepted
•
Code rejected
• •
Code(s) valid
but suspended
7
CANCEL EMERGENCY OPEN MODE - PROGRAM 11
#Master Code • 11 ••
Result: The emergency unlocked condition via REM 2 will
be cancelled and the lock will revert to normal operation
DELETE ALL USER CODES - PROGRAM 12
#Master Code • 12 • 12 •• (7 secs)
Result: All User Codes will be cleared from the memory
ADD/CHANGE SUB-MASTER CODE - PROGRAM 13
#Master Code • 13 • Sub-Master Code (eg 2468)
Result: A Sub-Master Code #2468 has been entered
DELETE SUB-MASTER CODE - PROGRAM 14
#Master Code • 14 • 14 ••
Result: Sub-Master Code has been deleted
LOCKED/UNLOCKED STATUS - PROGRAM 15
1. #Master Code • 15 • 1 •• = Locked, No LED flashing
(this is the default setting)
2. #Master Code • 15 • 2 •• = Locked-Red
3. #Master Code •15 • 3 •• = Unlocked-Blue
Result: If activated LED's will flash continuously
every 5 seconds
Note: LED's will not indicate unlocked mode by key
••
• LED flashing
• LED flashing
