- Page 1 PROGRAMMING & OPERATING INSTRUCTIONS CL5000 AUDIT TRAIL...
-
Page 2: Program
CODES AND OPERATION CODES OPERATING INSTRUCTIONS • The factory set Master Code is #1234. The CL5000AT lock has a 12 button keypad including This should be changed immediately after installation (see ✱ and # buttons. Program 10). AUDIT TRAIL FUNCTION • The Master Code and optional Sub-Master Code always start The CL5000AT has the ability to provide audit with the # prefix. This puts the lock into Programming Mode. information of lock activity; time lock opened, User Code • When the Master or Sub-Master Code is entered 3 times used etc. Once activated (Program 16) the same software consecutively without performing a programming function, allows for easy programming of locks via a USB Stick a penalty time of 10 seconds is activated. from a PC to the lock and from the lock back to the PC. • The length of the Master Code determines the length of the Multiple locks can be programmed in this way if required. User Codes and the Sub-Master Code. • If the Master Code is changed to another of the same length UNLOCK TIME then the Sub-Master and all User Codes will be retained. The factory pre-set UNLOCK time is 4 seconds. This may • If the Master Code is changed to one of a different length be changed – (see Program 06). then the Sub-Master and all User Codes will be deleted. • Codes may be 4, 5 or 6 digits long. The lock memory will PENALTY TIME store 989 different User Codes, each identified by a User Entering 3 incorrect codes will cause the lock to suspend... -
Page 3: Program
REMOTE RELEASE OPTION Program 11 can be used to revert the lock to normal before the The lock has 2 sets of terminals for remote release, labelled 30 minute period has finished. REM 1 and REM 2 on the printed circuit board in the front housing. Cables are provided with the lock for these connections. LOCKED/UNLOCKED STATUS INDICATION Using Program 15 the Blue and Red LEDs can be programmed to indicate locked and unlocked status. 1. Battery BATTERY POWER 2. Remote 1 The CL5000 Electronic should provide in excess of 200,000 3. Remote 2 openings from the 4 x AA cells rated at 2,900 mAh. 4. Clutch / Actuator 5. Data Cable Connector LOW BATTERY When the battery power is low the Red LED will flash 5 times before the Blue LED flashes to signal acceptance of the code. REM 1 is intended for use when there is a need to allow a Batteries should be changed as soon as this happens. visitor to open the door after having been identified by intercom or by sight from within. REM 1 would be connected to a push button on a reception desk, or to the appropriate button on an intercom. Pushing the button would cause the Blue LED to light... - Page 4 REMOVAL OF FRONT-LOAD CYLINDERS TO CHANGE KEY BYPASS FUNCTION, TO REPIN CYLINDERS, OR TO REPLACE WITH CYLINDERS BY A DIFFERENT MANUFACTURER* 1. Remove handle and cylinder cover. 2. Turn key 90º clockwise and remove cylinder from boss. *If intending to use a cylinder by a different manufacturer it is advisable to confirm beforehand that the new cylinder will fit the boss. Note that the CL5000 uses a 6 pin screw- cap cylinder. CHANGING KEY BYPASS FUNCTIONS A - Storeroom function Tailpiece allows key to turn 90º clockwise to enable handle to retract the latch - this is the factory fitted function.
- Page 5 3. Remove key from cylinder. Hold down the control pin in the end of the cylinder and unscrew the cap. 4. Replace the tailpiece, hold down the control pin and screw CAUTION! DO NOT INSERT THE KEY IN THE CYLINDER the cap fully on without tightening. Ensure control pin ONCE YOU HAVE REMOVED THE SCREW-CAP projects to lock the cap. 5. Test the key operation. If the key is difficult to insert or tight when turning, then the cap maybe too tight. Loosen the cap one notch at a time and try the key again. If the key inserts and turns OK, but is difficult to remove, then the cap may be too loose. Tighten up the cap one notch at a time. Adjust the cap until the key inserts, turns and removes easily. 6. With key turned 90º clockwise replace cylinder, cylinder cover and handle.
-
Page 6: Table Of Contents
PROGRAMMING * First change the factory Master Code #1234 – see Program 10. Note: The Master Code and Sub-Master Code MUST always start with #. All codes must be the same length as the Master Code. • • in the Key Sequence below indicates LED illumination. To use Audit Trail Function and programming via PC Program 16 must be active. IF ENTERED, A SUB-MASTER CODE CAN BE USED INSTEAD OF THE MASTER CODE FOR ALL PROGRAMS EXCEPT PROGRAMS 10,12,14,16,17,18 AND 19. PROGRAM 01 PROGRAM 05 ENTER NEW USER CODE RESTORE ALL USER CODES... -
Page 7: Master Code
PROGRAM 08 PROGRAM 12 SET CODE FREE MODE DELETE ALL USER CODES • •• • • •• #Master Code #Master Code 12 12 (7 secs) Result: Lock will be continuously unlocked. Result: All User Codes will be cleared from the memory. PROGRAM 09 PROGRAM 13 CANCEL CODE FREE MODE ADD/CHANGE SUB-MASTER CODE • •• • • #Master Code #Master Code 13 Sub-Master Code... -
Page 8: Program
PROGRAMMING ACTIVATE AUDIT TRAIL FUNCTION 1. Set date, time, daylight saving and Door ID on lock. See Note 1: Audit information and program settings can be Program 16, page 9. uploaded/downloaded to and from the PC and lock via the activated USB Stick using Program 19. 2. Insert Codelocks USB Stick into PC. Following prompts, install data management software (DMS). • Note 2: When Program 16 is active, the Audit Trail Activate Codelocks USB Stick by clicking on the “Tools”menu Function is automatically enabled for all previously installed and select “Activate USB” • and new User Codes. Close down DMS and remove USB Stick from PC 3. Insert USB Stick into lock USB port. Note 3: Programs 17, 18 and 19 will not work until • • •• • 4. Enter: #Master Code 19 followed by Program 16 is active. -
Page 9: Program
PROGRAM 16 PROGRAM 17 SET A VALID CODE ACTIVE PERIOD SET DATE AND TIME, DAYLIGHT SAVING & DOOR ID • • • • • • • #Master Code 16 date, month, year #Master Code 17 User ID days (Mon to Sun) • •• • • • • hours, minutes (from) hour, minutes (to) date, month, year day... - Page 10 (flash for 35 seconds). Audible BEEP will signify process completed. • • •• #Master Code 18 18 Result: Audit Trail and settings data will be downloaded to USB Stick Result: No User Codes will be able to open lock during from lock. weekend period. • To view data, insert USB Stick into PC with Codelocks DMS Note: Repeating the sequence will remove the weekend lock out for installed. all User Codes with previous weekend access. • • •• UPLOAD OF NEW/CHANGED SETTINGS: USB Stick to Lock #Master Code 18 18 Result: All User Codes will be able to open lock during • Insert USB Stick into PC with Codelocks DMS installed. weekend period.
- Page 11 ick...
- Page 12 AUDIT TRAIL CODELOCKS LTD UK Tel: +44 (0) 1635 239645 Fax: +44 (0) 1635 239644 sales@codelocks.co.uk Helpline, service & spares FREEPHONE 0800 393 405 CODELOCKS INC US Tel: +1 714 979 2900 Fax: +1 714 979 2902 sales@codelocks.us www.codelocks.com www.codelocks.com...
