Codelocks Support
CL460/465/470/475 - Code Change Guide

Many Codes to Choose From

The code chamber (models 0460 and 0470) consists of 13 buttons from which the code is selected, and a 'C'
button which is used to re-set the chamber after an incorrect entry, and which must always be used as the first
digit of a code. Buttons may only be used ONCE in a code. For example, 1212 is not possible.
A code, or combination, can be entered in any order or sequence; eg 1234 can be 4321 or 1342 or whatever
sequence is most convenient to remember.
With 13 buttons, a total of 8,191 different codes are available, any of which can be entered in any sequence.
The total is arrived at as follows:
Most people will set a code in the range of 4 to 7 digits, and the total number of codes in this range is 5434.
The lock is factory set with a randomly selected 5 digit code starting with the C button. The code is not recorded
by the factory. The code can be changed as often as required to any other 5 digit code. Every new code must start
with the C button. Using the spare tumblers, one red and one blue, the code length can be changed to 4 or 6 digits.
Shorter codes are possible, but 1 or 2 digit codes are not recommended.
