XtendLan DPM-473M User Manual

Video intercom system

Advertisement

Quick Links

Video Intercom System
DPM-473M
User Manual
Tue.
The design and specifi cations can be changed without notice to the user.
Right to interpret and copyright of this manual are preserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPM-473M and is the answer not in the manual?

Questions and answers

Summary of Contents for XtendLan DPM-473M

  • Page 1 Video Intercom System DPM-473M User Manual Tue. The design and specifi cations can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
  • Page 2 7. Precautions ● All parts should be protected from violence vibration. And not allow be impacting, knocking and dropping. ● For clean the Lens& Screen, using hands or wet cloth is forbidden. CONTENT: ● Please do the cleanness with soft cotton cloth, please do not use the organic or chemical clean impregnate.
  • Page 3: Parts And Functions

    1. Parts and Functions 6.6 Operation for Picture Memory 1. A picture will be recorded automatically by the exit LCD screen monitor every time after 2 seconds the visitor pressed the call button on the Outdoor station. monitor The image capacity is above 120 pcs, and the intercom oldest one will be replaced if the memory is full.
  • Page 4: Standard System Wiring

    3. Standard System Wiring 6.5 Basic Setup Instructions Terminal Discriptions: 1. In standby state, press ( ) Button will show the ● 1R Power positive. +12V present when Door Station calling or being monitored date/time page. The first line show the current ●...
  • Page 5 4. Extending Monitors or Auido Phones 6.3 Intercom function(available when Multi Monitors installed) 1. Intercom can be initiated by any Monitor. Press INTERCOM ( ) Button on one Monitor, the other Monitors will ring, and press INTERCOM JS/AP JS/VP CN101 ( ) Button again to redial.
  • Page 6: Basic Functions

    5. Extending 2 Outdoor Stations 6. Operation Instructions 6.1 Basic Functions 1. When visitor presses the Call Button on the Outdoor Station, the monitor rings, at the same IMG 16 JS/AP JS/VP CN101 JS-OS2 JS-OS1 time, the screen displays the visitor image, and the TALK LED will fl...
