Page 1: Door Station
DPC-518ID Door Station User Manual RF CARD Please read this manual carefully before using the product you purchase, and keep it well for future use.We reserve the right to modify the specification in this manual at any time without notice. -
Page 2: Table Of Contents
Contents 1. Parts and Functions ........1 2. Terminal Descriptions .......1 3. Door Station Mounting ......2 4. Basic System Connection ......3 5. Door Lock Connections ......4 6. Door Station Configurations ......6 7. Language and UI updating .......11 8. Specification ..........12... -
Page 3: Parts And Functions
1.Parts and Functions Camera Lens Night View LED Adjustable Camera Speaker LCD Screen Connectiong Port ID Card Window RF CARD Digital Keypad Microphone 128 mm With rainy cover 2. Terminal Descriptions SD Card Slot RS-485 CN-LK T/R - T/R+ JWB(OUT) J/KMB JP-LK •... -
Page 4: Door Station Mounting
3.Door Station Mounting Camera angle Drill a hole and attach the The view for rainy Adjust the camera angle and attach the rainy cover to it cover after mounted metal to the panel and wire correctly. Attach screws to fix the Attach the unit to the rainy Attach the baffle to protect metal box... -
Page 5: Basic System Connection
4. Basic System Connection The basic system consists of: Door station, Distributor, Monitor, Power supply and lock. Connect to next C5-F4 C5-F4 C5-F4 CN-LK RF CARD P+ P- T/R - T/R+ 12 V DC lock J/KMB JP-LK 85~260AC... -
Page 6: Door Lock Connections
5. Door Lock Connections 1. Internal Power Supply Mode Use the internal power to supply for the electronic lock, so that the lock can be connected to the door station directly. Note that the door station can only output 12Vdc power, Any high- power lock should use external power connection or it might cause damage to the door station. • The rated power of the lock must be less than 12Vdc 300mA when using internal power supply mode • The GND must connect to the negative of the lock, and the COM connect to the positive . • Jumper set to 1-2 position for Power-on-to-Unlock safety type(Normally open mode); set to 2-3 position for Power-off-to -Unlock type(Normally closed mode ). • If different unlocking time is needed to be configured, change the Unlock Timing on door station. A. Connection for Power-on-to-Unlock type: +12V LK - (GND) LK+(COM) set to Normally open on the N.O. - Page 7 2. External Power Supply Mode When the electronic lock is over 12 Vdc, additional power supply for the lock is needed. • The power supply for the lock must be less than 48Vdc 1.5A. • The Jumper must be removed when using external power supply. The default setting is Power-on-to-Unlock type(Normally open mode), if use Power-off-to-Unlock type, change the Unlock Relay mode to Normally closed mode . • If different unlocking time is needed to be configured, change the Unlock Timing on door station. C. Connection for Power-to-Unlock type: set to Normally Open on the +12V LK - (GND) Unlock Relay mode (default) LK+(COM) N.O.
-
Page 8: Door Station Configurations
6. Door Station Configurations About Debug State: The Debug State is your starting point for using all the applications. To open the debug state,please refer to the following steps: > > D e b u g S t a t e < < 0 - # R e d i a l RF CARD 1 - # To o l s [ 9 0 0 8 ] 2 - # E x i t s... - Page 9 Table 1:Menu overview Item Submenu 1. ID Code [0] 2. Unlock Timing [05] 3. Unlock Output [0] 4. Card Memory [0] 5. Doorplate Mode 1. Installer Setup 6. Audio Options ... 7. Parameters ... 8. Installer Code ... 9. Default ... 1. Language [1] 2. Tone Select [03] 3. Tone Volume [08] 4. Unlock Code [1111] 5. Display Mode 2. Setup 6. Clock ... 7. Setup Code ... 8. About ... 9. Default ... 1. Add Card ... 2. Delete By Card 3. Delete By M.code 3. Card Manage 4. Cards Information 5. Format To search the online monitors, input the starting number and ending number, the door station 4.
- Page 10 Basic Tools Detail: Table 2(Installer Setup): Factory Item Description 1.When there is only one door station and no C5-IPC, [0-11] set to 0. And set the type of distributor used with it. Standalone When C5-IPC is connected, must not be set to 0. ID Code Used with 2. When C5-MDS is connected, be set to from 1~8 C5-F4 according to which port it is connected on the C5-MDS 3. When used as common door station, set to 9 To set the time that how long the door keeps open [05] Unlock Timing when door is released. Range from 01 to 99 seconds. 5 seconds To set the unlock mode to match the corresponding lock.Range from 0 to 1. Unlock Output 0:Power-on-to-Unlock Mode(Normally Open Mode) 1:Power-off-to-Unlock Mode(Normally Closed Mode) To choose to use the memory of door station or that of C5-IPC when access cards are in use Card Memory 0-Use memory of DS for access 1-Use C5-IPC for access To choose the input mode when you call monitor. It 4 digits Doorplate Mode can be set to from 1 to 8 digits. totally 8 numbers or 8 letters or mixed are available To set the audio match if there is audio problem caused by bad match. Audio Options ...
- Page 11 Table 2.1(Parameters): Factory Item Description Monitor Timing To show the monitor time,Range from 6s to 600s Switch Timing Reserve To show the time during which the door station keeps Wait Timing calling, when door station is making a call, ranging from 10s to 600s To show time available for the conversation when door Talk Timing station is talking, ranging from 10s to 600s To enable Indoor Monitor under monitoring state can Monitor & Speak speak to Door Station at same time. If set to 1, talk enabled; set to 0, disabled. To enable Monitors under monitoring state can open the door at the same time.If set to 0, unlock function Monitor & Unlock is disabled; Set to 1, unlock is enable;Set to 2,unlock is enable and close at once;Set to 3,unlock is enable and close in 5s. To show ring times when door station calls monitor.4 Ring Numbers options for choice. If set to 0, ring once. If set to 1,ring twice. If set to 2, ring three times.If set to 3,cycle ring To show the namelist display mode.If set to 0,it's the Name List Mode ST-Config display mode.If set to 1,it's the Simulate display mode Working Mode Reserve Input Mode To show the input type when door station makes a call [****1111] this section is set on ST-Config software,for more detail informations,please refer to the Note: ST-Config software user instructions.
- Page 12 Table 3(Setup): Factory Item Description To change language.the code format is 4 digits.Please refer Language to section 7(Language and UI updateing) for more detail informations. Select the chime of Door Station in calling wait state, 12 Tone Select chord tunes are available, key in 01 to 12 to select. Adjust the tone volume for dooor station in calling.Range Tone Volume from 01~15 To change unlock code in Common Code Unlock mode, in Unlock Code [1111] 4-digits format. 1111 is the default unlock code. To select the Door Station screen menu .If set to 0,the Display Mode screen displays the visitor's image when talking.If set to 1,the screen displays icons when talking. To set date and time. Date format:if set to 0,date format is DD/MM/YY,if set to Clock ... 1,date format is MM/DD/YY. Time format: if set to 0,time format is 24 hour standard.If set to 1,time format is12 hour standard. Setup Code To change the Program Code. [88888888] 1. Hardware version---To show the Door Station(including ACS) hardware information 2. Software version ---To show the Door Station(including ACS) software information 3. Manufacture Date---To show the manufacturing date 4. Dialing Counts---To show the call operation counts 5. Calls Counts---To show the established calling counts 6. Unlock Counts---To show the unlock operation counts About ... 7. Standby Voltage---To show the voltage that the door station in standby.
-
Page 13: Language And Ui Updating
Table 4(Card Manage): Factory Item Description To add user cards, input the room code and then swipe Add Card ... the card to be added Delete By Card To swipe the card to be deleted To delete the card by room code. Input the room code, Delete By M.code and all the cards attached to it will be deleted To show the amount of cards added Cards Information To count how many times cards are swiped Format To delete all the cards and count information 7. Language and UI updating It's convenient for user to change the language and UI.Just put the config files to the SD card and insert the SD card into door station and by means of the digital keypad ,only 30 seconds is needed to update. Insert SD card SD Card Slot CN-LK T/R - T/R+ J/KMB JP-LK -11-... -
Page 14: Specification
Step 1: Insert the SD card which is contained config files into the SD card slot where is at the back of the door station.Refer to the right diagram. Step 2:If door station runs as Debug State, you can press “1#” to activate Tools Menu, select “2” to enter setup page,then select 1 item.If it runs as Normal State, follow these steps: 1 . L a n g u a g e [ 1 ] 1 . L a n g u a g e 2 . To n e S e l e c t [ 0 3 ] 3 .
