- Page 1 APARTMENT VIDEO INTERCOM SYSTEM DPM-571 USER’S MANUAL Features ■ 7 inch touch screen ■ Up to 120 pcs colour picture memory ■ 15 chord tunes selectable ■ Intercom function...
-
Page 2: Parts And Function
1. Parts and Function TOP View Right View UNLOCK INTERCOM MON / TALK IN USE Bottom View Bracket 1. TFT Touch Screen 6. TALK/MONITOR Button 2. Aluminum Panel 7. LED for Power, In-use 3. Microphone 8. Loudspeaker 4. UNLOCK Button 9. -
Page 3: Operation Instructions
2. OPERATION INSTRUCTIONS ■ Operation for Basic Video Doorphone 1. When visitor inputs room numbers in Door Station of the building or main entrance, the Monitor rings, at the same time, the screen displays the visitor image. 2. Then press icon(or MON/TALK Button), and you can talk with the visitor for 60 seconds. - Page 4 ■ Image and volume adjust operation 1. During the monitoring, press icon on the screen, the ADJUST MENU will be displayed. Press the item that you want to adjust, then the selected item will be displayed in red color. Press icon to decrease or increase the value of the current item.
- Page 5 2. AWAY SET Mode During standbby, touch anywhere on the screen to launch the MAIN MENU, then press icon,the SET UP menu will show as bellow. Press the AWAY SET item to turn it on, then the IN-USED LED will flashing in green;...
- Page 6 ■ Operation for Guard Unit related function If Guard Unit is installed in the system, you can contact it by the operation as below. When standby, press anywhere on the screen, then press icon(or press INTERCOM Button in standby), to activate the INTERCOM FUNCTION MENU as shown on the at right.
- Page 7 ■ Basic Setup instructions During standby state, press anywhere on the screen to display MAIN MENU, then press icon to enter SETUP MENU. The DOOR STATION and GUARD UNIT item are for chord ring selection. You can select different chord rings to identify different calling source, press icon to change the chord ring, and the change will be saved...
-
Page 8: Specifications
3. Mount Illustration Installation height of Monitor is usually from 145 to 160CM Fix bracket on 86 Installation Box or wall surface directly, then install the Monitor. 4. Specifications Power supply: DC 15~18V (by system Power Supply) Power consumption: <0.5W in standby, <15W in working Video signal: 1Vp-p, 75Ω, CCIR standard Resolutions:...
