  • Page 1 R26X Door Phone User Manual...

  • Page 2: Table Of Contents

    Content 1. Overview..................3 1.1. Product Description..................3 1.2. Features......................5 1.3. Panel Description....................7 1.4. Unpacking......................9 1.5. Installation......................10 2. Configuration................13 2.1. Basic Using......................13 2.1.1. Make a Call...................13 2.1.2. Receive a Call..................13 2.1.3. Unlock by RF Card.................13 2.2. Web login......................14 2.2.1. Obtaining IP address................14 2.2.2.

  • Page 4: Overview

    1.Overview...

  • Page 5: Product Description

    1.1. Product Description...
  • Page 9 Akuvox R26X is a SIP-compliant handfree one button video outdoor phone. It can be connected with your Akuvox IP Phone for remote unlock control and monitor. You can operate the indoor handset to communicate with visitors via voice and video, and unlock the door if you wish.

  • Page 10: Features

    operating can be well below the maximum value. Before a new product is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure limit established by the FCC, tests for each phone are performed in positions and locations as required by the FCC.
  • Page 11 Dimension: 190x110x35mm   SIP Endpoint SIP v1(RFC2543), SIP v2(RFC3261)  Audio codecs: G.711a, G.711μ, G.722, G.729  Video codecs: H263,H264  Speech Quality: 7kHz Audio  Echo Cancellation  Voice Activation Detection  Comfort Noise Generator  Video  Resolution: up to 1080p ...

  • Page 12: Panel Description

    1.3. Panel Description...

  • Page 13: Unpacking

    1.4. Unpacking Name Quantity R26C/P Back cover Wall bracket Cable buckle M4X20 screw ST4x20 screw Screw fixing seat M3X5 screw M3X10 screw 1.5. Installation With 86 embedded box:...
  • Page 14 Use 2 M4X20 screws Use the pen to mark wall the hole location on bracket and the wall bracket Take down the M4 Use 6mm hand drill to Embedded box. Insert screws and remove make the red hole you Use 4 St4 screws and screw fixing the wall bracket...
  • Page 15 Insert screws to fix screw fixing wall seat into the bracket hole Back cover installation:...
  • Page 16 For convenient wiring, Take down the back hang R26X cover ,cable buckle and bracket via using rope sealing ring Make cables go through all the components of the bottom hole Use 4 M3x5 screws to fix of the back cover , connect with...

  • Page 17: Configuration

    2.1.3. Unlock by RF Card Place the predefined RF card on the card sensor area. The door phone will announce “ the door is now opened”. R26X support 13.56MHz RF card. Please to chapter 2.2.12 about Card Setting.

  • Page 18: Web Login

    2.2. Web login 2.2.1. Obtaining IP address The Akuvox R26X uses DHCP IP address by default. If the IP address is unknown, after power on, when you see the LED light turns Blue, press the call button about 5s, the phone will announce its IP.

  • Page 19: Status-Basic

    2.2.3. Status-Basic Status, including product information, network information and Account information, can be viewed from Status -> Basic.
  • Page 20 Sections Description Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address), Firmware version and Hardware firmware. Network Information To display the device’s Networking status(LAN Port),such as Port Type(which could be DHCP/Static/PPPoE), Link Status, IP Address, Subnet Mask, Gateway, Primary DNS server, Secondary DNS server, Primary NTP server and Secondary NTP server(NTP server is used to synchronize time from...

  • Page 21: Intercom-Basic

    2.2.4. Intercom-Basic Go to the path: Intercom-Basic Sections Description Basic Select Account: R26 supports 2 accounts. You can choose  one account or Auto mode for the following Intercom...

  • Page 22: Intercom-Advanced

    basic settings. No Answer Call ： R26 will call to the No answer call  number in order when the ringtone is time out without Disable by default. answer of the push button number. Push Button Push Button: To configure the destination number or IP ...

  • Page 23: Intercom-Led Setting

    default value is 700. Increase the level, the echo control is better. Photoresistor Photosensitive is used to sense the light intensity that R26C will auto enable infrared LED. Users can adjust the photosensitive value by yourself. Tamper Enable the Tamper Alarm, if the gravity of R26 changes, the phone will alarm.

  • Page 24: Intercom- Relay&Input

    Color Off The default status is OFF. Color On It can support three color: Red, Green, Blue. Blink Mode To setup the different blink frequency. LED control Use Http URL to remote control the LED status. Http format: http://Phone IP/fcgi/do? action=LedAction&State=1&Color=1&Mode=2500 Status: 1=Idle ;2=OffLine ;...
  • Page 25 HTTP unlock. Null by default format:http://192.168.1.102/fcgi/do?action=OpenDoor& UserName=&Password=&DoorNum=1 Input There is a sensor that used to anti vandal in R26X. When R26X is broken by violent means. The sensor will be triggered, then management center will receive the alarm. Service: Enable by default ...

  • Page 26: Intercom-Live Stream

    form inside. Light Status: The status will change according to the sensor.  Once the sensor is triggered , the status will show Warning. Normal by default. 2.2.8. Intercom-Live Stream...
  • Page 27 Sections Description Live Stream To check the real-time video from R26X.

  • Page 28: Intercom-Rtsp

    2.2.9. Intercom-RTSP Sections Description RTSP Basic To active the RTSP function, then R26 can be monitored. RTSP Stream To enabled RTSP video and select the video codec. R26 supports H264,H263 video codec. H264 by default. H.264 Video Parameters H264: A video stream compression standard. Different from H263, it provides an approximately identical level of video stream quality but a half bit rate.

  • Page 29: Intercom-Onvif

    sometimes called MPEG-4 part 10. To modify the resolution,framerate and bitrate of H264 MPEG4 Video Parameters MPEG4: it is one of the network video image Compression standard. It supports the maximum Compression ratio 4000:1. It is an important and commom video function with great communication application integration ability and less core program space.

  • Page 30: Intercom-Card Setting(Optional)

    Sections Description Basic Setting To setup the Onvif function parameters. It is used to connect with the corresponding Onvif tool. Onvif Mode: Two modes - Discoverable and Non-  discoverable. Discoverable by default. Only Discoverable mode, then Onvif software can search R26. User Name: To modify the user name you need.

  • Page 31: Intercom-Action

    Card Issuing: Choose Card Issuing mode when writing  card Card Setting IC Key DoorNum: R26X can support to connect 2 doors.  Choose one and add the valid card for unlock. IC Key Name: To setup corresponding name for the card.

  • Page 32: Account-Basic

    address SMTP Server Address: Enter the SMTP server format  SMTP User name: Enter the SMTP  SMTP password: Enter the sender email password   Email Subject: Enter the subject name. Email content: Enter the content name.  Email test: click test to make sure the parameters ...
  • Page 33 Register Name: Allocated by SIP server provider, used for  authentication. User Name: Allocated by your SIP server provide, used  for authentication. Password: Used for authorization.  SIP Server 1 To display and configure Primary SIP server settings. Server IP: SIP server address, it could be an URL or IP ...

  • Page 34: Account-Advanced

    2.2.14. Account-Advanced...
  • Page 36 Sections Description SIP Account To display current Account settings or to select which account to display. Codecs To display and configure available/unavailable codecs list. Codec means coder-decoder which is used to transfer analog signal to digital signal or vice versa. Familiar codecs are PCMU(G711U), PCMA(G711A), G722 (wide-bandth codecs), G729 and so on.
  • Page 37 fetch for displaying on Phone UI. Auto Answer: If enabled, IP phone will be auto-answered  when there is an incoming call for designated account. Ringtones: Choose the ringtone for each account.  Provisioning Response ACK: 100% reliability for all ...

  • Page 38: Network-Basic

    NAT port alive. UDP Alive Msg Interval: Keepalive message interval.  Rport: Remote Port, if enabled, it will add Remote Port  into outgoing SIP message for designated account. User Agent One can customize User Agent field in the SIP message; If user agent is set to specific value, user could see the information from PCAP.

  • Page 39: Network-Advanced

    2.2.16. Network-Advanced Sections Description Local RTP To display and configure Local RTP settings. Max RTP Port: Determine the maximum port that RTP  stream can use.
  • Page 40 Starting RTP Port: Determine the minimum port that RTP  stream can use. SNMP To display and configure SNMP settings. Active: To enable or disable SNMP feature.  Port: To configure SNMP server’s port.  Trusted IP: To configure allowed SNMP server address, it ...

  • Page 42: Phone-Time/Language

    2.2.17. Phone-Time/Language Sections Description Web Language Choose the suitable web language you need. English by default. To configure NTP server related settings. Time Zone: To select local Time Zone for NTP server.  Primary Server: To configure primary NTP server ...

  • Page 43: Phone-Call Feature

    Note: NTP, Network Time Protocol is used to automatically synchronized local time with INTERNET time, since NTP server only response GMT time, so that you need to specify the Time Zone for IP phone to decide the local time. 2.2.18. Phone-Call Feature...

  • Page 44: Phone-Voice

    Sections Description Mode Mode: Select the desired mode.  Others Return Code When Refuse: Allows user to assign specific  code as return code to SIP server when an incoming call is rejected. Auto Answer Delay: To configure delay time before an ...

  • Page 45: Phone-Multicast

    Mic Volume To configure Microphone volume , from 1-15. 8 by default. Speaker Volume To configure Speaker Volume,from 1-15,8 by default. Open Door Warning To configure door opening voice. Disable it, you won’t hear the prompt voice when the door is opened. IP Announcement To setup the IP Announcement active time.

  • Page 46: Phone-Call Log

    Multicast Setting To display and configure the Multicast setting. Paging Barge: Choose the multicast  number ,the range is 1-10. Paging priority Active: Enable o disable  the multicast. Priority List To setup the multicast parameters. Listening Address: Enter the IP address ...
  • Page 47 Users can check the call history in detail. Tick the number to delete or delete all logs. R26 supports 100 call logs.

  • Page 48: Phone-Door Log

    2.2.22. Phone-Door Log Sections Description Door Log To display unlock history Users can check the unlock information in detail. User can delete one or all logs. The maximum door log is 500.

  • Page 50: Upgrade-Basic

    2.2.23. Upgrade-Basic Sections Description Upgrade To select upgrading zip file from local or a remote server automatically. Note: Please make sure it’s right file format for right model. Firmware version To display firmware version, firmware version starts with MODEL name. Hardware Version To display Hardware version.

  • Page 52: Upgrade-Advanced

    2.2.24. Upgrade-Advanced...
  • Page 53 Sections Description...
  • Page 54 PNP Option To display and configure PNP setting for Auto Provisioning. PNP: Plug and Play, once PNP is enabled, the phone will  send SIP subscription message to PNP server automatically to get Auto Provisioning server’s address. By default, this SIP message is sent to multicast address 224.0.1.75(PNP server address by standard).

  • Page 56: Security-Basic

    2.2.25. Security-Basic Sections Description Web Password Modify To modify user’s password. Current Password: The current password you used.  New Password: Input new password you intend to use.  Confirm Password: Repeat the new password.  Session Time Out Over the Time out value, users need to login again.
