COMMAND
SETIP <x.x.x.x><x.
x.x.x><x.x.x.x>
IPCONFIG
RSTIP
P0
P1
STOREN
SHOWN
PRESETN
NameN N1
ST
EMN
RS
USBISP
UARTSW?
UARTSWN
UARTBAUD?
UARTBAUDN N1
HELP(?)
@FADEFAULT
QUIT
Note: Any commands will not be executed unless followed by a
DESCRIPTION
Set IP, SubNet and Gateway
(Static IP)
Display the current IP
configuration
Set IP configuration to DHCP
Power off
Power on
Store current I/O to position N
Show current port N I/O
position
Preset the store I/O position N
Name port N as N1
Show unit firmware version
Setting EDID mode N
Routing reset to default
Update firmware via USB
Display the UART switching
state
Switch output's UART to port N
Display all output's UART baud None
Setting RS-232 routing port N
to Baud rate N1
Display all available
commands
Set to factory default
Quit Telnet
PARAMETER
X=0~255
NONE
None
None
None
N=1~8
N=1~8
N=1~8
N=1~8, N1=A~H (Max
Length=8)
None
N=0(STD)
1(TV)
2(USER)
None
None
None
N=0 (out console), 1~8
N=1~8, N1=1~6
(1=9600bps,
2=14400bps,
3=19200bps,
4=38400bps,
5=57600bps,
6=115200bps)
None
None
None
