  • Page 1: User Manual

    Digital Super Hybrid System KX-TD816CE KX-TD1232CE Added and Changed Features for User Manual In this manual, the last letter “CE” of each model number is omitted.
  • Page 2: Table Of Contents

    Table of Contents Added Features Section 2.2, Station Programming Charge Fee Reference......................4 Extension Charge Fee Reference..................5 CO Line Charge Fee Reference..................6 Total Extension Charge Fee Reference................7 Account Code Charge Fee Reference................8 New Rate Set ........................9 All Clear ...........................
  • Page 3: Added Features

    Added Features...
  • Page 4: Charge Fee Reference

    Programming Charge Fee Reference Allows you to view, print out and clear charges. Charges are displayed per extension, CO line, account code, or the total of each can be referred to. There are eight corresponding features as follows: [Program]—[99]—[8]—[ID Code] — [1] Extension Charge Fee Reference —...
  • Page 5: Extension Charge Fee Reference

    Programming Extension Charge Fee Reference Provides you with the display of each extension charge (telephone rate). You can refer and clear the displayed meter and charge. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 6: Co Line Charge Fee Reference

    Programming CO Line Charge Fee Reference Provides you with the display of each CO line charge (telephone rate). You can refer the displayed meter and charge. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 7: Total Extension Charge Fee Reference

    Programming Total Extension Charge Fee Reference Provides you with the display of the total extension charge (telephone rate). You can refer the displayed meter and charge. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 8: Account Code Charge Fee Reference

    Programming Account Code Charge Fee Reference Provides you with the display of each account code charge (telephone rate). You can refer and clear the displayed meter and charge. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 9: New Rate Set

    Programming New Rate Set Allows you to assign how many Charge are equal to a unit of Meter when calculating. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1. Dial 8. 2. Enter the ID code (4 digits). •...
  • Page 10: All Clear

    Programming All Clear Allows you to clear all recorded charge for CO line and account code, or extension, and set the new starting time for recording. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. To clear all CO line and all account code charge 1.
  • Page 11 Programming To clear all extension charge 1. Dial 8. 2. Enter the ID code (4 digits). • The display shows: Charge Meter ID code • To erase an incorrect entry, press the CLR (S2) button. 3. Dial 6. • The display shows: Meter Sum Clear? NEXT 4.
  • Page 12: Print The Charge Fee

    Programming Print the Charge Fee Allows you to print the charge of total telephone charge (total CO charge, each CO charge, each account code, ) all extension charge or each extension charge by SMDR. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 13: Account Code Set

    Programming Account Code Set Allows you to assign the account code. — Be sure that you are in Station Programming mode : Press [PROGRAM] [9] [9]. 1. Dial 8. 2. Enter the ID code (4 digits). • The display shows: Charge Meter •...
  • Page 14: Flexible Button Assignment

    Programming Flexible Button Assignment Alert Button (Assignment) Allows Operator 1 to assign a Flexible (CO) button as the Alert button. When the button turns red, the guest has not responded to the wake up call. — Be sure that you are in the Station Programming mode : Press [PROGRAM] [9] [9]. 1.
  • Page 15: Co Incoming Call Information Display

    DPT Features TD816 TD1232 CO Incoming Call Information Display DPT (72**) Provides you with the caller’s telephone number and name on the ISDN line provided with the CLIP feature. You can also record the information. Display Operation (— for KX-T7235) When you receive a CO incoming call, the display shows the caller’s 0111111111 telephone number and name.
  • Page 16 DPT Features Display Operation (— for KX-T7230) When you receive a CO incoming call, the display shows the caller’s 0111111111 telephone number and name. JOHN WHITE • If you are assigned as an operator, the display shows the CO line number / name, if assigned.
  • Page 17: Co Incoming Call Information Log

    DPT Features TD816 TD1232 CO Incoming Call Information Log DPT (72**) Allows you to confirm the CO incoming call information on the display which are the caller’s telephone number and the name on the ISDN line provides with the CLIP feature.* You can also call back the caller by selecting one of the memorized numbers.
  • Page 18 DPT Features 2. Confirm the information by pressing the NEXT (S3) or PREV (S3) 01:0111111111 INFO NEXT button. • Pressing the SHIFT button provides you with the PREV (S3) button on the display. • Pressing the INFO (S1) button provides you with further information about one party.
  • Page 19: Co Incoming Call Information Log Lock

    DPT Features TD816 TD1232 CO Incoming Call Information Log Lock DPT (72**) Allows you to lock the display of your extension so that CO incoming call information is not shown on the display. Locking 1. Lift the handset or press the SP-PHONE/MONITOR button. 2.
  • Page 20 DPT Features Conditions • The extension assigned as the operator can clear this function for another extension (CO Incoming Call Information Log Lock Clear). Programming References • System Programming — Installation Manual [100] Flexible Numbering, CO incoming call information log mode / CO incoming call information log lock [418] ISDN Line Number Assignment Feature References...
  • Page 21: Co Incoming Call Information Log Mode

    DPT Features CO Incoming Call Information Log Mode TD816 TD1232 Allows you to control the CO Incoming Call Information Log Mode at your DPT (72**) extension when the information area is full. If you set this mode, new CO incoming call information is retained but old data is discarded. If you cancel this mode, new CO incoming call information is not logged at your extension.
  • Page 22: Display Call Information

    DPT Features DPT Features Display Call Information TD816 TD1232 When you have a call with an outside party, you can see the duration of a DPT (72**) telephone call, the meter, the phone charge on the display by pressing the FWD/DND button alternately.
  • Page 23: User Programming Mode

    DPT Features DPT Features User Programming Mode TD816 TD1232 The following system programming can be programmed by any display DPT (72**) proprietary telephone user in the system. [000] Date and Time Set [001] System Speed Dialing Number Set [002] System Speed Dialing Name Set [003] Extension Number Set [004] Extension Name Set [005] Flexible CO Button Assignment...
  • Page 24 DPT Features DPT Features • The User Password is not shown on the display. The password can be changed by system programming. • During the programming mode, your extension is treated as a busy extension. • Only one DPT can be in programming mode at any one time. Programming References •...
  • Page 28: Section 3.3, Operator Service Features

    Operator Service Features Conditions • You must assign the Hotel Application feature through System Programming. • The LCD displays the telephone including the margin. You can enter the margin through System Programming. • The entered Minibar charge and other charges do not remain in the system after completing check-out.
  • Page 29 Operator Service Features 4. Enter the hour (01 through 12) and the minute (00 through 59). hour and minute 5. Dial 0 to enter AM, or 1 to enter PM. 6. Dial 0 for a one-time alarm setting* or 1 for a daily alarm setting* The alarm ringing will be heard at the preset time and then the setting is cleared.
  • Page 30 Operator Service Features Checking the setting time (with a display PT only) 1. Lift the handset or press the SP-PHONE/MONITOR button. 2. Dial the feature number (7 ) and 2. 3. Dial the desired extension number or DSS button on which has the Timed Reminder set.
  • Page 31 Operator Service Features Conditions • The system clock must be set beforehand. • The Alert button can be assigned to a flexible CO button on Operator 1’s extension only. • The alarm attempt times and the interval time are programmable by System Programming. The default is 3 attempts (1 attempt=ring for 30 seconds) in a 60 second interval.
  • Page 32: Changed Features

    Changed Features...
  • Page 33: System Speed Dialing

    ECTION OF EATURE ITLE EVISION ANUAL Background Music Section 3.2 This feature has been replaced with a new one. For (BGM) details, refer to page 36. Section 3.2 Direct Inward System Conditions Access (DISA) After the DISA outgoing message is sent Section 5.2 •...
  • Page 34 DPT Features Background Music (BGM) TD816 TD1232 You hear background music through the built-in speaker of the telephone. It DPT (72**) may be required to connect an external music source, such as a radio. One external music source can be connected to KX-TD816 and up to two sources can be connected to KX-TD1232.
  • Page 35: Remote Station Lock Control

    Operator Service Features Remote Station Lock Control TD816 TD1232 DPT (72**) The operator or the manager can remotely lock or unlock any extension. To lock an extension, you can select to lock CO calls or intercom calls. Programming 1. Press the PROGRAM button. PROGRAM 2.
  • Page 36: Section 5.2, Slt Features

    SLT Features Message Waiting Allows you to leave a message for another extension. If the destination extension is provided with a message waiting lamp, it will flash. Even if a lamp is not provided, the extension will be provided a special ringing and dial tone (dial tone 4*) to indicate that a message has been received.
  • Page 37 SLT Features 4. Hang up. Calling back the message sender 1. Lift the handset. • You hear dial tone 4 2. Dial the feature number (70) and 2. • If you have more than one message at your extension, the line is connected to the message sender which leave the message first.
  • Page 38 Matsushita Electric of Industrial Co., Ltd. Central P.O. Box 288, Osaka 530-91, Japan Printed in Japan PSQX1172ZA S0796MT0 (CE)
