Page 23: Overview
PART 1 Overview System Overview on page 3 Chassis Components and Descriptions on page 15 Cooling System and Airflow on page 23 Power Supplies on page 27 Viewing System Information on page 29 Copyright © 2017, Juniper Networks, Inc.
Page 25: System Overview
EX2300 Switches First View EX2300 switches are available in models with 12 or 24, or 48 built-in network ports that support RJ-45 cable connectors. The compact, fanless EX2300-C switches have 12 RJ-45 network ports. Copyright © 2017, Juniper Networks, Inc.
Page 26: Uplink Ports
10/100/1000 BASE-T connectors. Virtual Chassis capability—You can connect up to four EX2300 switches (including EX2300-C switches) to form one unit that you manage as a single chassis, called a Virtual Chassis. Power over Ethernet (PoE) or Power over Ethernet Plus (PoE+) on all RJ-45 network ports (in PoE-capable models).
Page 27: Security Slot
Ferrous Material” on page 149. Security Slot An EX2300-C switch has a security slot on the right panel of the chassis. You can use the security slot to lock and secure the chassis in the installation site with a standard cable lock. See “Mounting an EX2300 Switch on a Desk or Other Level Surface”...
Page 28: Figure 1: Front Panel Of An Ex2300-C Switch With 12 Gigabit Ethernet Ports With
Virtual Chassis. One electrostatic discharge (ESD) point Figure 1 on page 6 shows the front panel of an EX2300-C switch with 12 Gigabit Ethernet ports with PoE capability and Figure 2 on page 6 shows the front panel of an EX2300-C switch with 12 Gigabit Ethernet ports without PoE capability.
Page 29: Figure 3: Front Panel Of An Ex2300 Switch With 24 Gigabit Ethernet Ports With
Chapter 1: System Overview The front panel of EX2300 switches except the EX2300-C switch models consists of the following components: RJ-45 network ports—depending on the switch model, either of: 24 or 48 10/100/1000 BASE-T Gigabit Ethernet ports without PoE capability in the...
Page 30: Rear Panel Of An Ex2300 Switch
The PoE models have a heatsink installed in the rear panel to dissipate heat, while non-PoE models have no heatsink. Figure 5: Rear Panel of an EX2300-C Switch with 12 Gigabit Ethernet Ports with PoE Capability 1—...
Page 31: Figure 6: Rear Panel Of An Ex2300-C Switch With 12 Gigabit Ethernet Ports Without Poe Capability
Serial number ID label 4— AC power cord inlet The rear panel of the EX2300 switch except the EX2300-C switch consists of the following components: One management Ethernet port that supports an RJ-45 connector One console port that supports an RJ-45 connector...
Page 32: Figure 7: Rear Panel Of An Ac-Powered Ex2300 Switch With 24 Gigabit Ethernet Ports With Poe Capability
EX2300-C and EX2300 Switches Hardware Guide Figure 7: Rear Panel of an AC-Powered EX2300 Switch with 24 Gigabit Ethernet Ports with PoE Capability 1— USB port 6— Air exhaust openings 2— Management Ethernet port 7— Serial number ID label 3—...
Page 33: Ex2300 Switch Models
RJ-45 network ports (access ports), or no PoE capability. Table 3 on page 12 lists the EX2300 switch models. EX2300-C switches have two uplink ports and EX2300 switches except EX2300-C switches have four uplink ports. Uplink ports do not support PoE. Copyright © 2017, Juniper Networks, Inc.
Page 34: Ex2300 Switch Hardware And Cli Terminology Mapping
EX2300-C and EX2300 Switches Hardware Guide Table 3: EX2300 Switch Models Maximum System Ports in Which PoE Is Power Available for First Junos OS Model Access Ports Available PoE/PoE+ Release EX2300-C-12T 12 Gigabit Ethernet – – 15.1X53-D50 EX2300-C-12P 12 Gigabit Ethernet...
Page 35 73 transceiver is installed. Power Supply (n) Built-in power supply Value of n is AC power supply or “Power Supply in always 0. DC power supply EX2300 Switches” on page 27 Copyright © 2017, Juniper Networks, Inc.
Page 36 EX2300-C and EX2300 Switches Hardware Guide Table 4: CLI Equivalents of Terms Used in Documentation for EX2300 Switches (continued) Hardware Item (as Value (as Displayed in the Description (as Displayed in the Displayed in Item in Additional CLI) CLI) the CLI)
Page 37: Chassis Components And Descriptions
Models without PoE capability: 10.2 in. (25.9 cm) Models with PoE capability: 12.2 in. (30.98 cm) Weight EX2300-C-12T: 5.45 lb (2.48 kg) EX2300-24T: 7.25 lb (3.29 kg) EX2300-C-12P: 6.99 lb (3.17 kg) EX2300-24P: 9.89 lb (4.49 kg) EX2300-24T-DC: 7.83 lb (3.55 kg) EX2300-48T: 8.28 lb (3.76 kg)
Page 38: Chassis Status Leds In Ex2300 Switches
Figure 12 on page 16 Figure 13 on page Figure 12: Chassis Status LEDs in EX2300-C Switches 1— Chassis Status LEDs Figure 13: Chassis Status LEDs in EX2300 Switches Except the EX2300-C Switches 1— Chassis Status LEDs Table 6 on page 16 describes the chassis status LEDs in an EX2300 switch, their colors and states, and the status they indicate.
Page 39 A minor alarm (yellow) indicates a noncritical condition that requires monitoring or maintenance. A minor alarm that is left unchecked might cause interruption in service or performance degradation. All three LEDs can be lit simultaneously. Copyright © 2017, Juniper Networks, Inc.
Page 40: Management Port Leds In Ex2300 Switches
The management port on an EX2300 switch has two LEDs that indicate link/activity and port status. The EX2300 switches except the EX2300-C switch have the management port on the rear panel; the EX2300-C switches have the management port on the front panel. See...
Page 41: Rj-45 Network Port Leds And Uplink Port Leds In Ex2300 Switches
Figure 16: LEDs on RJ-45 Network Ports Link/ Status Activity Figure 17: LEDs on the Uplink Ports in EX2300-C Switches 1— LEDs on the uplink ports Figure 18: LEDs on the Uplink Ports in an EX2300 Switches Except the EX2300-C Switches 1—...
Page 42: Figure 19: Port Mode Leds On Ex2300 Switches
EX2300-C and EX2300 Switches Hardware Guide Table 9 on page 20 describes the Link/Activity LED. Table 9: Link/Activity LED on the RJ-45 Network Ports and the Uplink Ports in EX2300 Switches Color State and Description Link/Activity Green Blinking—The port and the link are active, and there is link activity.
Page 43: Table 11: Status Led On The Uplink Ports In Ex2300 Switches
You can tell which port parameter is indicated by the Status LED on RJ-45 network ports and uplink ports by issuing the operational mode command show chassis led Related EX2300 Switches Hardware Overview on page 3 Documentation Configuring Gigabit Ethernet Interfaces (CLI Procedure) Configuring Gigabit Ethernet Interfaces (J-Web Procedure) Copyright © 2017, Juniper Networks, Inc.
Page 45: Cooling System And Airflow
The cooling system in EX2300-C switches consists of the vents on the top of the chassis and the heatsinks installed in the rear panel in PoE models. Do not block the vents on the chassis;...
Page 46: Airflow Direction In Ex2300 Switches With 48 Ports With Poe Capability
EX2300-C and EX2300 Switches Hardware Guide Figure 20: Airflow Direction in EX2300 Switches with 24 Ports with PoE Capability Airflow Direction in EX2300 Switches with 48 Ports with PoE Capability Figure 21 on page 25 shows the airflow in EX2300 switches with 48 ports with PoE capability.
Page 47: Airflow Direction In Ex2300 Switches Without Poe Capability
Figure 21: Airflow Direction in EX2300 Switches with 48 Ports with PoE Capability Airflow Direction in EX2300 Switches without PoE Capability Figure 22 on page 26 shows the airflow in EX2300 switches without PoE capability. Copyright © 2017, Juniper Networks, Inc.
Page 48: Capability
EX2300-C and EX2300 Switches Hardware Guide Figure 22: Airflow Direction in EX2300 Switches with 24 Ports without PoE Capability Under normal operating conditions, the fans operate at a moderate speed to reduce noise. Temperature sensors in the chassis monitor the temperature within the chassis.
Page 49: Power Supplies
55 W – EX2300-24P 80 W (when no PoE power is 370 W drawn) EX2300-24T-DC – 55 W – EX2300-48T – 76 W – EX2300-48P 91 W (when no PoE power is 405 W drawn Copyright © 2017, Juniper Networks, Inc.
Page 50 EX2300-C and EX2300 Switches Hardware Guide Related AC Power Cord Specifications for EX2300 Switches on page 68 Documentation EX2300 Switches Hardware Overview on page 3 Power Specifications for EX2300 Switches on page 67 Connecting AC Power to an EX2300 Switch on page 161...
Page 51: Viewing System Information
NOTE: This topic applies only to the J-Web Application package. When you log in to the J-Web user interface, the dashboard for the Juniper Networks EX Series Ethernet Switches appears. Use the dashboard to view system information. The Update Available window appears if there is a latest update of the J-Web Application package available on the Juniper Networks server.
Page 52: Graphical Chassis Viewer
EX2300-C and EX2300 Switches Hardware Guide File System Usage on page 36 Chassis Viewer on page 36 Graphical Chassis Viewer The Dashboard panel displays a graphical view of the chassis of a switch. In a Virtual Chassis, it displays a graphical view of each member switch.
Page 53: System Information Panel
NOTE: In a Virtual Chassis setup for an EX6210, EX8208, or EX8216 switch, the Device model field displays details of the master Routing Engine. To view details of a member, select it. Copyright © 2017, Juniper Networks, Inc.
Page 54 Virtual Chassis, the value displayed in Inventory details field is always 1 FPC. FPC is a legacy term for a slot in a large Juniper Networks chassis; which simply refers to the standalone switch. For EX2200 and EX2200-C switches configured as a Virtual Chassis, the value displayed in the Inventory details field is 1–4 FPC, with the number corresponding to the number of...
Page 55: Health Status Panel
Indicates the average CPU usage over 15 minutes. In a Virtual Chassis configuration, on loading the master or backup switch, the CPU load for that switch's Routing Engine is displayed by default. To display the CPU load for a specific switch's Routing Engine, click the image of that switch. Copyright © 2017, Juniper Networks, Inc.
Page 56 EX2300-C and EX2300 Switches Hardware Guide Table 16: Health Status (continued) Field Description Fan status Indicates the status of the fans in the fan tray. The possible values are , and . In a Failed Absent Virtual Chassis configuration, the fan status of the master switch is displayed by default. To display the fan status for any switch , click the image of that switch.
Page 57: Capacity Utilization Panel
Alarms Panel Displays information about the last five alarms raised in the system. For example, if there are 5 major alarms, then details of all 5 major alarms are displayed. If there are 4 major Copyright © 2017, Juniper Networks, Inc.
Page 58: File System Usage
EX2300-C and EX2300 Switches Hardware Guide alarms and 3 minor alarms, then details of the 4 major alarms and 1 minor alarm are displayed. Major alarms are displayed in red and minor alarms are displayed in yellow. In an EX8200 Virtual Chassis, the top 5 alarms for the master external Routing Engine are displayed by default.
Page 59: Table 19: Chassis Viewer For Ex2200-C Switches
USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icon to display name, status, and description information.
Page 60 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icon to display name, status, and description information.
Page 61: Table 21: Chassis Viewer For Ex4300 Switches
Description USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management ( ) port The management port is used to connect the switch to a management device for out-of-band management.
Page 62: Table 22: Chassis Viewer For Ex4500 Switches
USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icons to display name, status, and description information.
Page 63: Table 23: Chassis Viewer For Ex4550 Switches
Use this port for initial switch configuration. USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4500 Switch Fan tray Mouse over the fan tray icon to display status of the fans and airflow direction information.
Page 64 (uplink or Virtual Chassis). USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4550 Switch Fan tray Mouse over the fan tray icon to display the status of the fans and airflow direction information.
Page 65: Table 24: Chassis Viewer For Ex4600 Switches
USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icons to display name, status, and description information.
Page 66: Table 26: Chassis Viewer For Ex8208 Switches
You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management ( ) port—The management port is used to connect the switch to a management...
Page 67 You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
Page 68: Table 27: Chassis Viewer For Ex8216 Switches
You can view status for the following ports on the RE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
Page 69 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. PIC1 slot You can install a Virtual Chassis module in the PIC1 slot. Mouse over the Virtual Chassis ports to display the port status details.
Page 70 EX2300-C and EX2300 Switches Hardware Guide Release History Table Release Description 14.1X53-D10 For Junos OS Release 14.1X53-D10 and later, EX3300 switches configured as a Virtual Chassis display the value 1–10 FPC in the Inventory details field. 14.1X53-A2 In J-Web Application package Release 14.1X53-A2, you can form a Virtual Chassis using EX4600 and EX4300 switches.
Page 71: Part 2 Site Planning, Preparation, And Specifications
Site Planning, Preparation, and Specifications Preparation Overview on page 51 Power Specifications and Requirements on page 67 Transceiver and Cable Specifications on page 73 Pinout Specifications on page 109 Planning the Virtual Chassis on page 119 Copyright © 2017, Juniper Networks, Inc.
Page 73: Preparation Overview
Power Measure the distance between external power sources and the switch installation site. Locate sites for connection of system grounding. Calculate the power consumption and “Power Specifications for EX2300 requirements. Switches” on page 67 Copyright © 2017, Juniper Networks, Inc.
Page 74 EX2300-C and EX2300 Switches Hardware Guide Table 29: Site Preparation Checklist (continued) Item or Task For More Information Performed by Date Hardware Configuration Choose the number and types of switches you “EX2300 Switches Hardware want to install. Overview” on page 3...
Page 75: Environmental Requirements And Specifications For Ex Series Switches
32° F (0° C) earthquake EX2300-C 13,000 feet 10% through 85% through 113° F (45° C) requirements as per switches) (3962.4 meters) at (noncondensing) GR-63, Issue 4. 104° F (40° C) as per GR-63 Copyright © 2017, Juniper Networks, Inc.
Page 76 EX2300-C and EX2300 Switches Hardware Guide Table 30: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX3200 No performance Normal operation ensured in Normal operation ensured in the Complies with Zone 4...
Page 77 10,000 feet 5% through 90% (0° C) through 104° F (40° C) requirements as per (3048 meters) (noncondensing) GR-63. Nonoperating storage temperature in shipping container: –40° F (–40° C) to 158° F (70° C) Copyright © 2017, Juniper Networks, Inc.
Page 78 EX2300-C and EX2300 Switches Hardware Guide Table 30: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX9214 No performance Normal operation ensured in Normal operation is ensured in Complies with Zone 4...
Page 79: General Site Guidelines
Improperly installed wires cause radio frequency interference (RFI). Damage from lightning strikes occurs when wires exceed recommended distances or pass between buildings. Electromagnetic pulses (EMPs) caused by lightning damage unshielded conductors and electronic devices. Copyright © 2017, Juniper Networks, Inc.
Page 80: Chassis Physical Specifications For Ex2300 Switches
EX2300-C and EX2300 Switches Hardware Guide Table 31: Site Electrical Wiring Guidelines (continued) Site Wiring Factor Guidelines Radio frequency interference To reduce or eliminate RFI from your site wiring, do the following: Use a twisted-pair cable with a good distribution of grounding conductors.
Page 81: Rack Requirements
Secure the rack to the building structure. If earthquakes are a possibility in your geographical area, secure the rack to the floor. Secure the rack to the ceiling brackets as well as wall or floor brackets for maximum stability. Copyright © 2017, Juniper Networks, Inc.
Page 82: Requirements For Mounting An Ex2300 Switch On Or Under A Desk Or Other Level Surface Or On A Wall
Insert the screws into wall studs wherever possible to provide added support for the chassis. Use the wall-mount kit from Juniper Networks to mount the switch on a wall. The wall-mount kit is not part of the standard package and must be ordered separately.
Page 83: Clearance Requirements For Airflow And Hardware Maintenance For Ex2300
Figure 24 on page 62 shows the clearance requirements for EX2300 switches, except the EX2300-C switch model, with PoE capability. The depth of EX2300 switches, except the EX2300-C switch model, without PoE capability is 10 in. (25.4 cm). Copyright © 2017, Juniper Networks, Inc.
Page 84: Figure 23: Clearance Requirements For Airflow And Hardware Maintenance For
EX2300-C and EX2300 Switches Hardware Guide Figure 23: Clearance Requirements for Airflow and Hardware Maintenance for EX2300-C Switches Figure 24: Clearance Requirements for Airflow and Hardware Maintenance for EX2300 Switches Except EX2200-C Switches The power cord retainer clips extend out of the rear of the chassis by 3 in. (7.6 cm).
Page 85: Figure 25: Airflow Direction In Ex2300 Switches With 24 Ports With Poe
EX2300 switches with 48 ports with PoE capability. Figure 27 on page 64 shows the airflow in EX2300 switches without PoE capability. Figure 25: Airflow Direction in EX2300 Switches with 24 Ports with PoE Capability Copyright © 2017, Juniper Networks, Inc.
Page 86: Figure 26: Airflow Direction In Ex2300 Switches With 48 Ports With Poe
EX2300-C and EX2300 Switches Hardware Guide Figure 26: Airflow Direction in EX2300 Switches with 48 Ports with PoE Capability Figure 27: Airflow Direction in EX2300 Switches without PoE Capability Copyright © 2017, Juniper Networks, Inc.
Page 87 NOTE: You can mount only EX2300-C switches under a desk or other level surface. Leave at least 24 in. (61 cm) in front of the switch and 6 in. (15.2 cm) behind the switch.
Page 89: Power Specifications And Requirements
100 through 240 VAC AC input line frequency 50 Hz/60 Hz nominal AC system current rating EX2300-C-12T: 1 A at 100 VAC EX2300-C-12T: 0.5 A at 240 VAC EX2300-C-12P: 2.5 A at 100 VAC EX2300-C-12P: 1.25 A at 240 VAC EX2300-24T: 2.5 A at 100 VAC...
Page 90: Ac Power Cord Specifications For Ex2300 Switches
EX2300-C and EX2300 Switches Hardware Guide Table 36: DC Power Supply Electrical Specifications for EX2300 Switches (Except EX2300-C Switches) Item Specification DC input voltage –48 through -60 VDC DC input current 2.8 A maximum Power supply output 100 W Output holdup time...
Page 91: Figure 28: Ac Plug Types
Table 37 on page Figure 28: AC Plug Types Related Power Supply in EX2300 Switches on page 27 Documentation General Safety Guidelines and Warnings on page 223 General Electrical Safety Guidelines and Warnings on page 251 Copyright © 2017, Juniper Networks, Inc.
Page 92: Calculating The Ex Series Switch Fiber-Optic Cable Power Budget
EX2300-C and EX2300 Switches Hardware Guide Prevention of Electrostatic Discharge Damage on page 253 Calculating the EX Series Switch Fiber-Optic Cable Power Budget Calculate the link's power budget when planning fiber-optic cable layout and distances to ensure that fiber-optic connections have sufficient power for correct operation. The power budget is the maximum amount of power the link can transmit.
Page 93: Table 38: Estimated Values For Factors Causing Link Loss
For information about the actual amount of signal loss caused by equipment and other factors, see your vendor documentation for that equipment. Calculate the (P ) by subtracting (LL) from (P – LL = P Copyright © 2017, Juniper Networks, Inc.
Page 94 EX2300-C and EX2300 Switches Hardware Guide (13 dBm) – (0.5 dBm [HOL]) – ((5) * (0.5 dBm)) – ((2) * (0.5 dBm)) – ((2 km) * (1.0 dBm/km)) – (1 dB [CRM]) = P 13 dBm – 0.5 dBm – 2.5 dBm – 1 dBm – 2 dBm – 1 dBm = P...
Page 95: Transceiver And Cable Specifications
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 96 EX2300-C and EX2300 Switches Hardware Guide The Gigabit Ethernet SFP and SFP+ transceivers installed in EX2300 switches support digital optical monitoring (DOM): You can view the diagnostic details for these transceivers by issuing the operational mode CLI command show interfaces diagnostics optics...
Page 97: Table 39: Optical Interface Support And Copper Interface Support For Sfp
Fiber type Copper Core/Cladding size – Modal bandwidth – Distance 100 m (328 ft) DOM support Not available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 98 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-SX Model number EX-SFP-1GE-SX Rate 1000 Mbps Connector type Fiber count Dual Transmitter wavelength...
Page 99 Maximum input power –3 dBm Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 10 km (6.2 miles) Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 100 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-U Model number EX-SFP-GE10KT13R14 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 101 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 10 km (6.2 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 102 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-U Model number EX-SFP-GE10KT13R15 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 103 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 10 km (6.2 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 104 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-1GE-LX40K Rate 1000 Mbps Connector type Fiber count Double Transmitter wavelength...
Page 105 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 40 km (24.8 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 106 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-D Model number EX-SFP-GE40KT15R13 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 107 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 70 km (43.5 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 108 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1470 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 109 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 80 km (49.7 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 110 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1510 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 111 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 80 km (49.7 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 112 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1550 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 113 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 80 km (49.7 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 114 EX2300-C and EX2300 Switches Hardware Guide Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1590 Rate 1000 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 115 Fiber type Core/Cladding size 9/125 µm Modal bandwidth – Distance 80 km (49.7 miles) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 116: Table 40: Optical Interface Support For Sfp+ Transceivers In Ex2300
EX2300-C and EX2300 Switches Hardware Guide Table 40: Optical Interface Support for SFP+ Transceivers in EX2300 Switches Ethernet Standard Specification Value 10GBASE-USR Model number EX-SFP-10GE-USR Rate 10 Gbps Connector type Fiber count Dual Transmitter wavelength 850 nm Minimum launch power –7.3 dBm...
Page 117 66 m 82 m 300 m (108 ft) (216 ft) (269 ft) (984 ft) DOM support Available Software required Junos OS for EX Series switches, Release 15.1X53-D50 or later Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 118 EX2300-C and EX2300 Switches Hardware Guide Table 40: Optical Interface Support for SFP+ Transceivers in EX2300 Switches (continued) Ethernet Standard Specification Value 10GBASE-LR Model number EX-SFP-10GE-LR Rate 10 Gbps Connector type Transmitter wavelength 1310 nm Minimum launch power –8.2 dBm Maximum launch power 0.5 dBm...
Page 119: Pluggable Transceivers Supported On Ex Series Switches
Pluggable Transceivers Supported on EX Series Switches The transceivers for EX Series switches are hot-removable and hot-insertable field-replaceable units (FRUs): You can remove and replace them without powering off the switch or disrupting switch functions. Copyright © 2017, Juniper Networks, Inc.
Page 120 6 seconds for the interface to display the operational commands. Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches. For the list and specifications of transceivers supported on EX2200 switches, see Pluggable Transceivers Supported on EX2200 Switches.
Page 121: Sfp+ Direct Attach Copper Cables For Ex Series Switches
3 ft (1 m), 10 ft (3 m), 16 ft (5 m), and 23 ft (7 m) EX4200-24T, Junos OS Release 10.3 3 ft (1 m), 10 ft (3 m), 16 ft (5 m), and 23 ft (7 m) EX4200-24T-DC, EX4200-24P, EX4200-24PX, EX4200-24F, EX4200-24F-DC, EX4200-48T, EX4200-48T-DC, EX4200-48P, and EX4200-48PX switches Copyright © 2017, Juniper Networks, Inc.
Page 122 EX2300-C and EX2300 Switches Hardware Guide Table 41: Software Support for SFP+ Passive Direct Attach Copper Cables for EX Series Switches (continued) Switch Software Support Added Cable Length EX4200-24F-S and Junos OS Release 12.3R4 3 ft (1 m), 10 ft (3 m), 16 ft (5 m), and 23 ft (7 m)
Page 123 (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 124: Table 42: Sfp+ Direct Attach Copper Cable Specifications
EX2300-C and EX2300 Switches Hardware Guide Table 42: SFP+ Direct Attach Copper Cable Specifications Model Number Specification Value EX-SFP-10GE-DAC-1M Rate 10-Gbps full-duplex serial transmission Connector type SFP+ passive Twinax cable assembly Supply voltage 3.3 V Power consumption (per end) 0.57 W Storage temperature –40°...
Page 125 30 AWG Minimum cable bend radius 1 in. (2.54 cm) Cable characteristic impedance 100 ohms Crosstalk between pairs 2% maximum Time delay 1.31 nsec/ft Length 9.9 ft (3 m) Support for Virtual Chassis configuration Copyright © 2017, Juniper Networks, Inc.
Page 126 EX2300-C and EX2300 Switches Hardware Guide Table 42: SFP+ Direct Attach Copper Cable Specifications (continued) Model Number Specification Value EX-SFP-10GE-DAC-5M Rate 10-Gbps full-duplex serial transmission Connector type SFP+ passive Twinax cable assembly Supply voltage 3.3 V Power consumption (per end) 0.57 W...
Page 127: Standards Supported By These Cables
Removing a Transceiver on page 195 Management Cable Specifications Table 43 on page 106 lists the specifications for the cables that connect the console ( and management ( ) ports to management devices. MGMT Copyright © 2017, Juniper Networks, Inc.
Page 128: Understanding Ex Series Switches Fiber-Optic Cable Signal Loss, Attenuation
EX2300-C and EX2300 Switches Hardware Guide Table 43: Specifications of Cables to Connect to Management Devices Ports Cable Specifications Receptacle Additional Information RJ-45 Console ( ) port CAT5e UTP (unshielded RJ-45 “Connecting a Device to a CON2 twisted pair) cable Management Console by Using an RJ-45 Connector”...
Page 129: Attenuation And Dispersion In Fiber-Optic Cable
(including those from dispersion), and a safety margin for unexpected losses. Related Calculating the EX Series Switch Fiber-Optic Cable Power Budget on page 70 Documentation Calculating the EX Series Switch Fiber-Optic Cable Power Margin on page 70 Copyright © 2017, Juniper Networks, Inc.
Page 131: Pinout Specifications
USB to DB-9 male adapter. Table 44: Console Port Connector Pinout Information Signal Description RTS Output Request to send DTR Output Data terminal ready TxD Output Transmit data Signal Ground Signal ground Signal Ground Signal ground Copyright © 2017, Juniper Networks, Inc.
Page 132: Usb Port Specifications For An Ex Series Switch
Documentation Configuring the Console Port Type (CLI Procedure) USB Port Specifications for an EX Series Switch The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port on all EX Series switches: RE-USB-1G-S...
Page 133: Mini-Usb Port Pinout Specifications
Signal Description +5 VDC Data - Data + Could be not connected (N/C), connected to ground (GND), or used as an attached device presence indicator Ground Related Management Cable Specifications on page 105 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 134: Rj-45 Management Port Connector Pinout Information
EX2300-C and EX2300 Switches Hardware Guide RJ-45 Management Port Connector Pinout Information Table 46 on page 112 provides the pinout information for the RJ-45 connector for the management port on Juniper Networks devices. Table 46: RJ-45 Management Port Connector Pinout Information...
Page 135: Table 48: Sfp Network Port Connector Pinout Information
2-wire serial interface data line SCL- 2-wire serial interface clock MOD_ABS Module absent Rate select RX_LOS Receiver loss of signal indication VeeR Module receiver ground VeeR Module receiver ground VeeR Module receiver ground Receiver inverted data output Copyright © 2017, Juniper Networks, Inc.
Page 136: Table 49: Sfp+ Network Port Connector Pinout Information
EX2300-C and EX2300 Switches Hardware Guide Table 48: SFP Network Port Connector Pinout Information (continued) Signal Description Receiver noninverted data output VeeR Module receiver ground VccR Module receiver 3.3 V supply VccT Module transmitter 3.3 V supply VeeT Module transmitter ground...
Page 137: Table 50: Qsfp+ Network Port Connector Pinout Information
VeeT Module transmitter ground Transmitter noninverted data input Transmitter inverted data input VeeT Module transmitter ground Table 50: QSFP+ Network Port Connector Pinout Information Signal TX2n TX2p TX4n TX4p ModSelL LPMode_Reset VccRx RX3p RX3n Copyright © 2017, Juniper Networks, Inc.
Page 138 EX2300-C and EX2300 Switches Hardware Guide Table 50: QSFP+ Network Port Connector Pinout Information (continued) Signal RX1p RX1n RX2n RX2p RX4n RX4p ModPrsL IntL VccTx Vcc1 Reserved TX3p TX3n TX1p TX1n Related Installing a Transceiver on page 193 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 139: Sfp+ Uplink Port Connector Pinout Information For An Ex2300 Switch
Chapter 9: Pinout Specifications SFP+ Uplink Port Connector Pinout Information for an EX2300 Switch EX2300-C switches have two 10-Gigabit Ethernet uplink ports that support 1-gigabit SFP transceivers and 10-gigabit SFP+ transceivers. EX2300 switches except the EX2300-C switch model have four 10-Gigabit Ethernet uplink ports that support SFP and SFP+ transceivers.
Page 140: Rj-45 To Db-9 Serial Port Adapter Pinout Information
EX2300-C and EX2300 Switches Hardware Guide Table 51: Connector Pinout Information for the 10-Gigabit Ethernet Uplink Port (continued) Signal Description VeeT Module transmitter ground Related EX2300 Switches Hardware Overview on page 3 for port location Documentation RJ-45 to DB-9 Serial Port Adapter Pinout Information The console port is an RS-232 serial interface that uses an RJ-45 connector to connect to a management device such as a PC or a laptop.
Page 141: Planning The Virtual Chassis
Software Licenses for EX Series Switches. Related Understanding EX Series Virtual Chassis Components Documentation Understanding EX2300 Virtual Chassis Hardware Configuration on page 120 Clearance Requirements for Airflow and Hardware Maintenance for EX2300 Switches on page 61 Copyright © 2017, Juniper Networks, Inc.
Page 142: Understanding Ex2300 Virtual Chassis Hardware Configuration
EX2300-C and EX2300 Switches Hardware Guide Understanding EX2300 Virtual Chassis Hardware Configuration Virtual Chassis is a feature in Juniper Networks EX2300 Ethernet Switches that allows you to interconnect two or more EX2300 switches, enabling them to operate as a unified, single, high-bandwidth switch.
Page 143: Part 3 Initial Installation And Configuration
Unpacking the Switch on page 123 Installing the Switch on page 127 Connecting the Switch to Power on page 155 Connecting the Switch to the Network on page 167 Performing Initial Configuration on page 173 Copyright © 2017, Juniper Networks, Inc.
Page 145: Unpacking The Switch
Save the shipping carton and packing materials in case you need to move or ship the switch later. Related Mounting an EX2300 Switch on page 128 Documentation Installing and Connecting an EX2300 Switch on page 127 Connecting and Configuring an EX Series Switch (CLI Procedure) on page 179 Copyright © 2017, Juniper Networks, Inc.
Page 146: Parts Inventory (Packing List) For An Ex2300 Switch
If any part on the packing list is missing, contact your customer service representative or contact Juniper customer care from within the U.S. or Canada by telephone at 1-888-314-5822. For international-dial or direct-dial options in countries without toll-free numbers, see http://www.juniper.net/support/requesting-support.html...
Page 147: Registering Products-Mandatory For Validating Slas
Documentation EX2300 Switches Hardware Overview on page 3 Registering Products—Mandatory for Validating SLAs Register all new Juniper Networks hardware products and changes to an existing installed product using the Juniper Networks website to activate your hardware replacement service-level agreements (SLAs).
Page 149: Installing The Switch
Mounting an EX2300 Switch on page 128 Mounting an EX2300 Switch on a Desk or Other Level Surface on page 129 Mounting an EX2300-C Switch Under a Desk or Other Level Surface by Using Screws on page 131 Mounting an EX2300 Switch on Two Posts of a Rack or Cabinet on page 135...
Page 150: Mounting An Ex2300 Switch
Two-post rack or cabinet EX2300-C On two posts in a 19-in. rack or cabinet by using the mounting brackets (separately orderable for EX2300-C switches and provided EX2300 for EX2300 switches) Copyright © 2017, Juniper Networks, Inc.
Page 151: Mounting An Ex2300 Switch On A Desk Or Other Level Surface
Mounting an EX2300 Switch on a Desk or Other Level Surface on page 129 Documentation Mounting an EX2300-C Switch Under a Desk or Other Level Surface by Using Screws on page 131 Mounting an EX2300 Switch on a Wall on page 141...
Page 152: Figure 30: Attaching A Cable Guard To An Ex2300-C Switch
(Optional and separately orderable; applies only to EX2300-C switches) 1 standard cable lock kit to secure the EX2300-C switch from theft by connecting the cable to the security slot on the switch and a desk or a rack to fasten the cable lock. The kit includes the standard cable lock and its key.
Page 153: Screws
Mounting an EX2300-C Switch Under a Desk or Other Level Surface by Using Screws You can mount an EX2300-C switch under a desk or other level surface by using the mounting slots on the bottom of the chassis and desk-mounting screws to secure the switch.
Page 154: Figure 32: Attaching A Cable Guard To An Ex2300-C Switch
EX2300-C and EX2300 Switches Hardware Guide NOTE: Do not block the vents on the top of EX2300-C switches. Blocking the vents can lead to overheating of the switch chassis. Ensure that you have the following parts and tools available: 3 desk-mounting screws (M4 x 30 mm or 8-32 x 1.25 in. Phillips pan-head machine screws—not provided)
Page 155: Figure 33: Measurements For Installing Mounting Screws For Mounting Ex2300-C Switches Under A Desk Or Other Level Surface By Using Screws
Figure 33: Measurements for Installing Mounting Screws for Mounting EX2300-C Switches Under a Desk or Other Level Surface by Using Screws NOTE: Tighten the screws only part way in, leaving about 1/4 in. (6 mm) distance between the head of the screw and the desk or the level surface.
Page 156: Figure 34: Mounting The Ex2300-C Switch Under A Desk Or Other Level Surface
See Figure 34 on page 134. Figure 34: Mounting the EX2300-C Switch Under a Desk or Other Level Surface by Using Screws (Optional) Attach the standard cable lock to the security slot on the switch: Fasten the cable to a desk or a rack and set the lock to unlocked position using the key.
Page 157: Mounting An Ex2300 Switch On Two Posts Of A Rack Or Cabinet
The remainder of this topic uses rack to mean rack or cabinet. NOTE: If you need to mount an EX2300 switch except the EX2300-C switch models in a recessed position on either a two-post rack or a four-post rack, you can use the 2-in.-recess front-mounting brackets provided in the separately orderable four-post rack-mount kit.
Page 158: Figure 36: Attaching The Mounting Bracket Along The Front Of The Switch
EX2300-C and EX2300 Switches Hardware Guide NOTE: One person must be available to lift the switch while another secures the switch to the rack. CAUTION: If you are mounting multiple units on a rack, mount the heaviest unit at the bottom of the rack and mount the other units from the bottom of the rack to the top in decreasing order of the weight of the units.
Page 159: Mounting An Ex2300 Switch On Four Posts Of A Rack Or Cabinet
Mounting an EX2300 Switch on Four Posts of a Rack or Cabinet You can mount an EX2300 switch except the EX2300-C switch model on four posts of a 19-in. rack or cabinet by using the separately orderable four-post rack-mount kit. The remainder of this topic uses rack to mean rack or cabinet.
Page 160 EX2300-C and EX2300 Switches Hardware Guide NOTE: EX2300-C switches cannot be mounted on all four posts of a rack. NOTE: If you need to mount an EX2300 switch except the EX2300-C switch model in a recessed position on either a two-post rack or a four-post rack, you can use the 2-in.-recess front-mounting brackets provided in the...
Page 161: Figure 38: Attaching The Front-Mounting Bracket To The Side Mounting-Rail
Align the bottom hole in both the front-mounting brackets with a hole in each rack rail, making sure that the chassis is level. See Figure 40 on page 140. Copyright © 2017, Juniper Networks, Inc.
Page 162: Figure 40: Mounting The Switch To The Front Posts Of A Rack
EX2300-C and EX2300 Switches Hardware Guide Figure 40: Mounting the Switch to the Front Posts of a Rack 1— Side mounting-rail 2— Front-mounting bracket Have a second person secure the front of the switch to the rack by using the appropriate screws for your rack.
Page 163: Mounting An Ex2300 Switch On A Wall
This topic describes the process of mounting an EX2300 switch on a wall. Mounting an EX2300-C Switch on a Wall on page 141 Mounting an EX2300 Switch Except the EX2300-C Switch on a Wall on page 144 Mounting an EX2300-C Switch on a Wall You can mount an EX2300-C switch—the compact, fanless model—on a wall by using...
Page 164: Figure 42: Attaching A Cable Guard To An Ex2300-C Switch
Use the 3 truss-head screws to attach the cable guard to the bottom of the chassis. Use the thumbscrews to fasten or loosen the cable guard so that you can insert cables. See Figure 42 on page 142. Figure 42: Attaching a Cable Guard to an EX2300-C Switch 1— Cable guard 2— Thumb screws...
Page 165: Figure 43: Measurements For Installing Mounting Screws For Mounting An
Chapter 12: Installing the Switch Figure 43: Measurements for Installing Mounting Screws for Mounting an EX2300-C Switch on a Wall NOTE: Tighten the screws only part way in, leaving about 1/4 in. (6 mm) distance between the head of the screw and the wall.
Page 166: Mounting An Ex2300 Switch Except The Ex2300-C Switch On A Wall
Figure 45 on page 144. Figure 45: Securing the EX2300-C Switch by Using the Security Slot Mounting an EX2300 Switch Except the EX2300-C Switch on a Wall You can mount an EX2300 switch on a wall by using the separately orderable wall-mount kit.
Page 167 Remove the switch from the shipping carton (see “Unpacking an EX2300 Switch” on page 123). Attach the wall-mounting brackets to the sides of the chassis by using four wall-mounting bracket screws, as shown in Figure 46 on page 146. Copyright © 2017, Juniper Networks, Inc.
Page 168: Figure 46: Attaching Wall-Mount Brackets To An Ex2300 Switch Except The
EX2300-C and EX2300 Switches Hardware Guide Figure 46: Attaching Wall-Mount Brackets to an EX2300 Switch Except the EX2300-C Switch Install four mounting screws for the wall-mounting brackets on the wall as shown in Figure 47 on page 148. Copyright © 2017, Juniper Networks, Inc.
Page 169 Drill a hole C at a distance of 18.67 in. (47.43 cm) on a plumb line down from screw A and install a mounting screw. Drill a hole D at a distance of 18.67 in. (47.43 cm) on a plumb line down from screw B and install a mounting screw. Copyright © 2017, Juniper Networks, Inc.
Page 170: Figure 47: Measurements For Installing Mounting Screws To Mount An Ex2300
EX2300-C and EX2300 Switches Hardware Guide Figure 47: Measurements for Installing Mounting Screws to Mount an EX2300 Switch on a Wall Place the switch against the wall such that the front panel of the switch faces to the right side and the holes in the mounting brackets heads align with the mounting screw heads.
Page 171: Material
Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 182 Mounting an EX2300-C Switch on or Under a Surface Made of Ferrous Material You can mount an EX2300-C switch on or under a surface made of ferrous material by using the separately orderable magnet-mount kit.
Page 172: Figure 49: Attaching A Cable Guard To An Ex2300-C Switch
At least 2-mm thick flat surface made of ferrous material (not provided) (Optional and separately orderable) 1 cable guard kit. The kit includes the cable guard and 3 number-8 Phillips truss-head screws to secure the cable guard to the EX2300-C switch.
Page 173: Figure 50: Attaching Rubber Pads To An Ex2300-C Switch
(see Figure 51 on page 151). Figure 51: Attaching the Magnet Mount Sheet to an EX2300-C Switch 1— Magnet mount sheet Mount the switch along with the magnet mount sheet on the ferrous surface on which you want to mount the switch (see Figure 52 on page 152).
Page 174: Figure 52: Mounting An Ex2300-C Switch On Or Under A Surface Made Of Ferrous
EX2300-C and EX2300 Switches Hardware Guide Figure 52: Mounting an EX2300-C Switch on or Under a Surface Made of Ferrous Material 1— Ferrous surface (Optional) Attach the standard cable lock to the security slot on the switch: Fasten the cable to a desk or a rack and set the lock to unlocked position using the key.
Page 175: Mounting An Ex2300 Switch In A Recessed Position In A Rack Or Cabinet
Mounting an EX2300 Switch in a Recessed Position in a Rack or Cabinet You can mount an EX2300 switch except the EX2300-C switch model on two posts or four posts of a rack or cabinet such that the switch is recessed inside the rack from the rack front by 2 inches.
Page 177: Connecting The Switch To Power
Parts and Tools Required for Connecting an EX Series Switch to Earth Ground Table 55 on page 156 lists the earthing terminal location, grounding cable requirements, grounding lug specifications, screws and washers required, and the screwdriver needed Copyright © 2017, Juniper Networks, Inc.
Page 178: Table 55: Parts And Tools Required For Connecting An Ex Series Switch To Earth Ground
EX2300-C and EX2300 Switches Hardware Guide for connecting a switch to earth ground. Before you begin connecting a switch to earth ground, ensure you have the parts and tools required for your switch. Table 55: Parts and Tools Required for Connecting an EX Series Switch to Earth Ground...
Page 179: Special Instructions To Follow Before Connecting Earth Ground To A
Two ¼-20 x 0.5 in. Phillips (+) the chassis mm²), minimum LCD2-14A-Q or screws with #¼” number 2 60°C wire, or as equivalent split-washer permitted by the —provided —provided local code Two #¼” flat washers— provided Copyright © 2017, Juniper Networks, Inc.
Page 180: Switch
Special Instructions EX3200 NOTE: Some early variants of EX3200 switches for which the Juniper Networks model number on the label next to the protective earthing terminal is from 750-021xxx through 750-030xxx require 10-24x.25 in. screws. Copyright © 2017, Juniper Networks, Inc.
Page 181: Figure 54: Connecting The Grounding Lug To A Switch Mounted On Four Posts Of
Special Instructions EX4200 NOTE: Some early variants of EX4200 switches for which the Juniper Networks model number on the label next to the protective earthing terminal is from 750-021xxx through 750-030xxx require 10-24x.25 in. screws. NOTE: The protective earthing terminal on an EX4200 switch mounted on four posts of a rack is accessible through the slot on the left rear bracket only if the rack is 27.5 in.
Page 182: Connecting Earth Ground To An Ex Series Switch
EX2300-C and EX2300 Switches Hardware Guide Connecting Earth Ground to an EX Series Switch To connect earth ground to a switch: Connect one end of the grounding cable to a proper earth ground, such as the rack in which the switch is mounted.
Page 183: Connecting Ac Power To An Ex2300 Switch
AC power outlet by using the AC power cord appropriate for your geographical location (see “AC Power Cord Specifications for EX2300 Switches” on page 68). Copyright © 2017, Juniper Networks, Inc.
Page 184: Figure 56: Connecting An Ac Power Cord Retainer Clip To The Ac Power Cord Inlet On Ex2300-C Switches
Figure 56: Connecting an AC Power Cord Retainer Clip to the AC Power Cord Inlet on EX2300-C Switches Figure 57: Connecting an AC Power Cord Retainer Clip to the AC Power Cord Inlet on EX2300 Switches Except EX2300-C Switches Copyright © 2017, Juniper Networks, Inc.
Page 185: Connecting Dc Power To An Ex2300 Switch
Figure 58: Connecting an AC Power Cord to the AC Power Cord Inlet on EX2300-C Switches Figure 59: Connecting an AC Power Cord to the AC Power Cord Inlet on EX2300 Switches Except EX2300-C Switches Related Connecting and Configuring an EX Series Switch (CLI Procedure) on page 179...
Page 186 EX2300-C and EX2300 Switches Hardware Guide connecting earth ground, see “Connecting Earth Ground to an EX Series Switch” on page 155. NOTE: Grounding is required for DC systems and recommended for AC systems. Ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage”...
Page 187: Figure 60: Securing The Ring Lugs On The Power Cables To The Terminals On The
Close the input circuit breaker. Related Connecting and Configuring an EX Series Switch (CLI Procedure) on page 179 Documentation Power Supply in EX2300 Switches on page 27 Copyright © 2017, Juniper Networks, Inc.
Page 189: Connecting The Switch To The Network
Figure 62 on page 168): Connect one end of the Ethernet cable to the management port (labeled MGMT ) on the device. ETHERNET Connect the other end of the Ethernet cable to the management device. Copyright © 2017, Juniper Networks, Inc.
Page 190: Connector
EX2300-C and EX2300 Switches Hardware Guide Figure 62: Connecting a Device to a Network for Out-of-Band Management Related Connecting a Device to a Management Console by Using an RJ-45 Connector on page 168 Documentation Connecting a Device to a Management Console by Using an RJ-45 Connector You can configure and manage these devices by using a dedicated management channel.
Page 191: Connecting An Ex2300 Switch To A Management Console By Using Mini-Usb Type-B Console Port
Before you begin connecting an EX2300 switch by using the Mini-USB Type-B console port: Ensure that the USB to Serial driver is installed on the host machine. You can download the driver from https://webdownload.juniper.net/swdl/dl/secure/site/1/record/5029.html Copyright © 2017, Juniper Networks, Inc.
Page 192: Connecting A Fiber-Optic Cable
EX2300-C and EX2300 Switches Hardware Guide Ensure that the hyperterminal properties of the console server or laptop are set as follows: Baud rate—9600 Flow control—None Data—8 Parity—None Stop bits—1 DCD state—Disregard Ensure that you have the following parts and tools available: 1 mini-USB cable with Standard-A and Mini-USB Type- B (5-pin) connectors (not provided).
Page 193: Figure 66: Connecting A Fiber-Optic Cable To An Optical Transceiver Installed
Related Disconnecting a Fiber-Optic Cable from a Device on page 200 Documentation Installing a Transceiver on page 193 Maintaining Fiber-Optic Cables on page 201 Copyright © 2017, Juniper Networks, Inc.
Page 195: Performing Initial Configuration
The number of interfaces in the default configuration file depends on the number of ports in the EX2300 switch. statement does not appear for models without PoE. Uplink ports on EX2300 switches except EX2300-C switches are listed as . Uplink ports on EX2300-C ge-0/1/0...
Page 196 EX2300-C and EX2300 Switches Hardware Guide syslog { user * { any emergency; file messages { any notice; authorization info; file interactive-commands { interactive-commands any; commit { factory-settings { reset-virtual-chassis-configuration; reset-chassis-lcd-menu; interfaces { ge-0/0/0 { unit 0 { family ethernet-switching { storm-control default;...
Page 197 { unit 0 { family ethernet-switching { storm-control default; ge-0/0/11 { unit 0 { family ethernet-switching { storm-control default; ge-0/0/12 { unit 0 { family ethernet-switching { storm-control default; ge-0/0/13 { Copyright © 2017, Juniper Networks, Inc.
Page 198 EX2300-C and EX2300 Switches Hardware Guide unit 0 { family ethernet-switching { storm-control default; ge-0/0/14 { unit 0 { family ethernet-switching { storm-control default; ge-0/0/15 { unit 0 { family ethernet-switching { storm-control default; ge-0/0/16 { unit 0 { family ethernet-switching { storm-control default;...
Page 199 { unit 0 { family ethernet-switching { storm-control default; xe-0/1/1 { unit 0 { family ethernet-switching { storm-control default; ge-0/1/2 { unit 0 { family ethernet-switching { storm-control default; xe-0/1/2 { Copyright © 2017, Juniper Networks, Inc.
Page 200 EX2300-C and EX2300 Switches Hardware Guide unit 0 { family ethernet-switching { storm-control default; ge-0/1/3 { unit 0 { family ethernet-switching { storm-control default; xe-0/1/3 { unit 0 { family ethernet-switching { storm-control default; forwarding-options { storm-control-profiles default { all;...
Page 201: Connecting And Configuring An Ex Series Switch (Cli Procedure)
, revert to the factory-default configuration. ezsetup “Reverting to the Default Factory Configuration for the EX Series Switch” on page 186. Using the CLI, set the following parameter values in the console server or PC: Baud rate—9600 Flow control—None Copyright © 2017, Juniper Networks, Inc.
Page 202 See Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch. See Routing Engine (RE) Module in an EX8216 Switch. NOTE: In EX2200-C, EX2300-C, EX2300, EX4300, and EX4550 switches, you can also use the Mini-USB Type-B console port to connect to a laptop or PC.
Page 203 PIC mode to intraconnect. You can now log in with the CLI or the J-Web interface to continue configuring the switch. If you use the J-Web interface to continue configuring the switch, the Web session is Copyright © 2017, Juniper Networks, Inc.
Page 204: Connecting And Configuring An Ex Series Switch (J-Web Procedure)
EX2300-C and EX2300 Switches Hardware Guide redirected to the new management IP address. If the connection cannot be made, the J-Web interface displays instructions for starting a J-Web session. Related Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 182...
Page 205 EX3200, EX3300, EX4200, EX4300, EX4500, EX4550, EX6200, or EX8200 switch—The LCD panel displays a count-down timer when the switch is in initial setup mode. Copyright © 2017, Juniper Networks, Inc.
Page 206: Figure 67: Lcd Panel In An Ex3200, Ex4200, Ex4500, Ex4550, Or Ex8200
EX2300-C and EX2300 Switches Hardware Guide To connect and configure the switch by using the J-Web interface: Transition the switch into initial setup mode: EX2200 and EX2200-C switch—Press the mode button located on the lower right corner of the front panel for 10 seconds.
Page 207 VLAN ID, member interfaces, management IP address, and default gateway for the new VLAN. Out-of-band Management—Configure management port Select this option to configure only the management interface. Click Next . Specify the IP address and default gateway for the management interface. Click Next Copyright © 2017, Juniper Networks, Inc.
Page 208: Reverting To The Default Factory Configuration For The Ex Series Switch
EX2300-C and EX2300 Switches Hardware Guide On the Manage Access page, you can select options to enable Telnet, SSH, and SNMP services. For SNMP, you can configure the read community, location, and contact. Click . The Summary screen displays the configured settings.
Page 209: Reverting To The Factory-Default Configuration By Using The Lcd Panel
Figure 69 on page 188. If the switch model does not have an LCD panel, use one of the procedures described in the following sections. Copyright © 2017, Juniper Networks, Inc.
Page 210: Reverting To The Factory-Default Configuration By Using The Request System Zeroize Command
EX2300-C and EX2300 Switches Hardware Guide Figure 69: EX Series Switch LCD Panel NOTE: To revert a member switch of a Virtual Chassis to the factory-default configuration, first disconnect the cables connected to the Virtual Chassis ports (VCPs) to avoid affecting Virtual Chassis configuration parameters (member ID, mastership priority, and setting of VCP uplinks) on other members.
Page 211: Reverting To The Factory-Default Configuration By Using The Load Factory-Default Command
[edit] user@switch# load factory-default [edit] user@switch# delete system commit factory-settings Copyright © 2017, Juniper Networks, Inc.
Page 212: Reverting To The Factory-Default Configuration By Using The Factory Reset/Mode Button On Ex2300 And Ex3400 Switches
Reverting to the Factory-Default Configuration by Using the Factory Reset/Mode button on EX2300 and EX3400 Switches To set the EX2300, EX2300-C, and EX3400 switches to the factory-default configuration, use the Factory Reset/Mode button located on the far right side of the front panel.
Page 213: Installing, Maintaining, And Replacing Components
PART 4 Installing, Maintaining, and Replacing Components Replacing Transceiver on page 193 Maintaining and Replacing Fiber-Optic Cable on page 199 Contacting Customer Support and Returning the Chassis or Components on page 203 Copyright © 2017, Juniper Networks, Inc.
Page 215: Replacing Transceiver
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 216 EX2300-C and EX2300 Switches Hardware Guide Before you begin installing a transceiver in a device, ensure that you have taken the necessary precautions for safe handling of lasers (see “Laser and LED Safety Guidelines and Warnings” on page 241). Ensure that you have a rubber safety cap available to cover the transceiver.
Page 217: Removing A Transceiver
Documentation Connecting a Fiber-Optic Cable on page 170 Removing a Transceiver The transceivers for Juniper Networks devices are hot-removable and hot-insertable field-replaceable units (FRUs): You can remove and replace them without powering off the device or disrupting device functions. NOTE:...
Page 218 EX2300-C and EX2300 Switches Hardware Guide WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable.
Page 219: Figure 71: Removing An Sfp, Sfp+, Xfp, Or A Qsfp+ Transceiver
Place the transceiver in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Place the dust cover over the empty port. Related Installing a Transceiver on page 193 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 221: Maintaining And Replacing Fiber-Optic Cable
If the fiber-optic cable connector is covered with a rubber safety cap, remove the cap. Save the cap. Remove the rubber safety cap from the optical transceiver. Save the cap. Insert the cable connector into the optical transceiver (see Figure 66 on page 171). Copyright © 2017, Juniper Networks, Inc.
Page 222: Disconnecting A Fiber-Optic Cable From A Device
Maintaining Fiber-Optic Cables on page 201 Disconnecting a Fiber-Optic Cable from a Device Juniper Networks devices have field-replaceable unit (FRU) optical transceivers to which you can connect fiber-optic cables. Before you begin disconnecting a fiber-optic cable from an optical transceiver, ensure that you have taken the necessary precautions for safe handling of lasers.
Page 223: Maintaining Fiber-Optic Cables
Removing a Transceiver on page 195 Maintaining Fiber-Optic Cables on page 201 Maintaining Fiber-Optic Cables Fiber-optic cables connect to optical transceivers that are installed in Juniper Networks devices. To maintain fiber-optic cables: When you unplug a fiber-optic cable from a transceiver, place rubber safety caps over the transceiver and on the end of the cable.
Page 224 EX2300-C and EX2300 Switches Hardware Guide unplugging is then absorbed by the short fiber extension, which is easier and less expensive to replace than the instruments. Keep fiber-optic cable connections clean. Microdeposits of oil and dust in the canal of the transceiver or cable connector can cause loss of light, reduction in signal power, and possibly intermittent problems with the optical connection.
Page 225: Components
Packing an EX2300 Switch or Component for Shipping on page 206 Returning an EX2300 Switch or Component for Repair or Replacement If you need to return an EX2300 switch or hardware component to Juniper Networks for repair or replacement, follow this procedure: Determine the serial number of the component.
Page 226: Listing The Switch And Components Details With The Cli
Listing the Switch and Components Details with the CLI To list the switch and switch components and their serial numbers, enter the following CLI command: user@switch> show chassis hardware The following are sample output of this command on EX2300-C and EX2300 switches: Hardware inventory: Item Version...
Page 227: Locating The Chassis Serial Number Id Label On An Ex2300 Switch
Returning an EX2300 Switch or Component for Repair or Replacement on page 203 Contacting Customer Support to Obtain Return Material Authorization If you are returning a device or hardware component to Juniper Networks for repair or replacement, obtain a Return Material Authorization (RMA) number from Juniper Networks Technical Assistance Center (JTAC).
Page 228: Packing An Ex2300 Switch Or Component For Shipping
Documentation Packing an EX2300 Switch or Component for Shipping If you are returning an EX2300 switch or component to Juniper Networks for repair or replacement, pack the item as described in this topic. Before you begin, ensure that you have retrieved the original shipping carton and packing materials.
Page 229: Packing A Switch For Shipping
Close the top of the cardboard shipping carton and seal it with packing tape. Write the RMA number on the exterior of the carton to ensure proper tracking. Copyright © 2017, Juniper Networks, Inc.
Page 233: Alarms And System Log Messages
This topic applies only to the J-Web Application package. Alarms alert you to conditions that might prevent normal operation of the switch. Before monitoring alarms on a Juniper Networks EX Series Ethernet switch, become familiar with the terms defined in Table 57 on page 211.
Page 234: Chassis Component Alarm Conditions On Ex2300 Switches
EX2300-C and EX2300 Switches Hardware Guide The switch supports these alarms: Chassis alarms indicate a failure on the switch or one of its components. Chassis alarms are preset and cannot be modified. System alarms indicate a missing rescue configuration. System alarms are preset and cannot be modified, although you can configure them to appear automatically in the J-Web interface display or the CLI display.
Page 235: Table 58: Alarm Conditions On Ex2300 Switches
If you are unable to resolve the problem, open a support case using the Case Manager link at http://www.juniper.net/support/ call 1-888-314-5822 (toll-free within the United States and Canada) or 1-408-745-9500 (from outside the United States). Copyright © 2017, Juniper Networks, Inc.
Page 236: Checking Active Alarms With The J-Web Interface
EX2300-C and EX2300 Switches Hardware Guide Table 58: Alarm Conditions on EX2300 Switches (continued) Chassis Alarm Component Alarm Condition Severity Remedy Routing /var partition Minor Clean up the system file storage space on Engine usage is high. (yellow) the switch. For more information, see Cleaning Up the System File Storage Space.
Page 237: Monitoring System Log Messages
Apply a filter or a combination of filters to view messages. You can use filters to display relevant events. Table 60 on page 216 describes the different filters, their functions, and the associated actions. To view events in the CLI, enter the following command: show log Copyright © 2017, Juniper Networks, Inc.
Page 238: Table 60: Filtering System Log Messages
EX2300-C and EX2300 Switches Hardware Guide Table 60: Filtering System Log Messages Field Function Your Action System Log File Specifies the name of a system log file for To specify events recorded in a particular which you want to display the recorded events.
Page 239 25 events, with severity levels highlighted in different colors. After you specify the filters, Event Summary displays the events matching the specified filters. Click the , and links to navigate First Next Prev Last through messages. Copyright © 2017, Juniper Networks, Inc.
Page 240: Table 61: Viewing System Log Messages
EX2300-C and EX2300 Switches Hardware Guide Table 61: Viewing System Log Messages Field Function Additional Information Process Displays the name and ID of the process that generated The information displayed in this field is different for the system log message.
Page 241 Events Detail table. Related Checking Active Alarms with the J-Web Interface on page 214 Documentation Understanding Alarm Types and Severity Levels on EX Series Switches on page 211 Copyright © 2017, Juniper Networks, Inc.
Page 243: Safety And Compliance Information
Radiation and Laser Safety Guidelines and Warnings on page 241 Maintenance and Operational Safety Warnings on page 245 Electrical Safety Guidelines and Warnings on page 251 Agency Approvals and Compliance Statements on page 267 Copyright © 2017, Juniper Networks, Inc.
Page 245: General Safety Guidelines And Warnings
Operate the device only when it is properly grounded. Ensure that the separate protective earthing terminal provided on this device is permanently connected to earth. Replace fuses only with fuses of the same type and rating. Copyright © 2017, Juniper Networks, Inc.
Page 246: Definitions Of Safety Warning Levels
EX2300-C and EX2300 Switches Hardware Guide Do not open or remove chassis covers or sheet-metal parts unless instructions are provided in the hardware documentation for this device. Such an action could cause severe electrical shock. Do not push or force any objects through any opening in the chassis frame. Such an action could result in electrical shock or fire.
Page 247 Varning! Denna varningssymbol signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanligt förfarande för att förebygga skador. Copyright © 2017, Juniper Networks, Inc.
Page 248: Qualified Personnel Warning
EX2300-C and EX2300 Switches Hardware Guide Related General Safety Guidelines and Warnings on page 223 Documentation Installation Instructions Warning on page 231 Maintenance and Operational Safety Guidelines and Warnings on page 245 Grounded Equipment Warning on page 238 Laser and LED Safety Guidelines and Warnings on page 241...
Page 249: Warning Statement For Norway And Sweden
The equipment must be connected to an earthed mains socket-outlet. Advarsel Apparatet skal kobles til en jordet stikkontakt. Varning! Apparaten skall anslutas till jordat nätuttag. Related General Safety Guidelines and Warnings on page 223 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 251: Fire Safety Requirements
In addition, you should establish procedures to protect your equipment in the event of a fire emergency. Juniper Networks products should be installed in an environment suitable for electronic equipment. We recommend that fire suppression equipment be available in the event of a fire in the vicinity of the equipment and that all local fire, safety, and electrical codes and ordinances be observed when you install and operate your equipment.
Page 252 To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks device. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 253: Installation Safety Guidelines And Warnings
Advarsel Les installasjonsinstruksjonene før systemet kobles til strømkilden. Aviso Leia as instruções de instalação antes de ligar o sistema à sua fonte de energia. ¡Atención! Ver las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Copyright © 2017, Juniper Networks, Inc.
Page 254: Chassis Lifting Guidelines
EX2300-C and EX2300 Switches Hardware Guide Varning! Läs installationsanvisningarna innan du kopplar systemet till dess strömförsörjningsenhet. Related General Safety Guidelines and Warnings on page 223 Documentation Laser and LED Safety Guidelines and Warnings on page 241 Grounded Equipment Warning on page 238...
Page 255 Related General Safety Guidelines and Warnings on page 223 Documentation General Electrical Safety Guidelines and Warnings on page 251 Installation Instructions Warning on page 231 Grounded Equipment Warning on page 238 Copyright © 2017, Juniper Networks, Inc.
Page 256: Ramp Warning
EX2300-C and EX2300 Switches Hardware Guide Ramp Warning WARNING: When installing the device, do not use a ramp inclined at more than 10 degrees. Waarschuwing Gebruik een oprijplaat niet onder een hoek van meer dan 10 graden. Varoitus Älä käytä sellaista kaltevaa pintaa, jonka kaltevuus ylittää 10 astetta.
Page 257 Les directives ci-dessous sont destinées à assurer la protection du personnel: Le rack sur lequel est monté le Juniper Networks switch doit être fixé à la structure du bâtiment. Si cette unité constitue la seule unité montée en casier, elle doit être placée dans le bas.
Page 258 Le seguenti direttive vengono fornite per garantire la sicurezza personale: Il Juniper Networks switch deve essere installato in un telaio, il quale deve essere fissato alla struttura dell'edificio. Questa unità deve venire montata sul fondo del supporto, se si tratta dell'unica unità...
Page 259 Para garantizar su seguridad, proceda según las siguientes instrucciones: El Juniper Networks switch debe instalarse en un bastidor fijado a la estructura del edificio. Colocar el equipo en la parte inferior del bastidor, cuando sea la única unidad en el mismo.
Page 260: Wall-Mounting Warnings For Ex2300 Switches
EX2300-C and EX2300 Switches Hardware Guide Juniper Networks switch måste installeras i en ställning som är förankrad i byggnadens struktur. Om denna enhet är den enda enheten på ställningen skall den installeras längst ned på ställningen. Om denna enhet installeras på en delvis fylld ställning skall ställningen fyllas nedifrån och upp, med de tyngsta enheterna längst ned på...
Page 261 Varning! Denna utrustning är avsedd att jordas. Se till att värdenheten är jordad vid normal användning. Related General Safety Guidelines and Warnings on page 223 Documentation AC Power Electrical Safety Guidelines on page 254 DC Power Electrical Safety Guidelines for Switches on page 256 Copyright © 2017, Juniper Networks, Inc.
Page 263: Radiation And Laser Safety Guidelines And Warnings
Radiation from Open Port Apertures Warning on page 243 Laser and LED Safety Guidelines and Warnings Juniper Networks devices are equipped with laser transmitters, which are considered a Class 1 Laser Product by the U.S. Food and Drug Administration and are evaluated as a Class 1 Laser Product per EN 60825-1 requirements.
Page 264: Class 1 Laser Product Warning
EX2300-C and EX2300 Switches Hardware Guide Class 1 Laser Product Warning WARNING: Class 1 laser product. Waarschuwing Klasse-1 laser produkt. Varoitus Luokan 1 lasertuote. Attention Produit laser de classe I. Warnung Laserprodukt der Klasse 1. Avvertenza Prodotto laser di Classe 1.
Page 265: Radiation From Open Port Apertures Warning
Varoitus Koska portin aukosta voi emittoitua näkymätöntä säteilyä, kun kuitukaapelia ei ole kytkettynä, vältä säteilylle altistumista äläkä katso avoimiin aukkoihin. Copyright © 2017, Juniper Networks, Inc.
Page 266 EX2300-C and EX2300 Switches Hardware Guide Attention Des radiations invisibles à l'il nu pouvant traverser l'ouverture du port lorsqu'aucun câble en fibre optique n'y est connecté, il est recommandé de ne pas regarder fixement l'intérieur de ces ouvertures. Warnung Aus der Port-Öffnung können unsichtbare Strahlen emittieren, wenn kein Glasfaserkabel angeschlossen ist.
Page 267: Maintenance And Operational Safety Warnings
Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. Copyright © 2017, Juniper Networks, Inc.
Page 268: Jewelry Removal Warning
EX2300-C and EX2300 Switches Hardware Guide Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Advarsel Det kan være fare for eksplosjon hvis batteriet skiftes på feil måte.
Page 269: Lightning Activity Warning
Waarschuwing Tijdens onweer dat gepaard gaat met bliksem, dient u niet aan het systeem te werken of kabels aan te sluiten of te ontkoppelen. Varoitus Älä työskentele järjestelmän parissa äläkä yhdistä tai irrota kaapeleita ukkosilmalla. Copyright © 2017, Juniper Networks, Inc.
Page 270: Operating Temperature Warning
6 in. (15.2 cm) of clearance around the ventilation openings. Waarschuwing Om te voorkomen dat welke switch van de Juniper Networks router dan ook oververhit raakt, dient u deze niet te bedienen op een plaats waar de maximale aanbevolen omgevingstemperatuur van 40°...
Page 271: Product Disposal Warning
15,2 cm à volta das aberturas de ventilação. ¡Atención! Para impedir que un encaminador de la serie Juniper Networks switch se recaliente, no lo haga funcionar en un área en la que se supere la temperatura ambiente máxima recomendada de 40°...
Page 272 EX2300-C and EX2300 Switches Hardware Guide Advarsel Endelig disponering av dette produktet må skje i henhold til nasjonale lover og forskrifter. Aviso A descartagem final deste produto deverá ser efectuada de acordo com os regulamentos e a legislação nacional. ¡Atención! El desecho final de este producto debe realizarse según todas las leyes y regulaciones nacionales Varning! Slutlig kassering av denna produkt bör skötas i enlighet med landets...
Page 273: Electrical Safety Guidelines And Warnings
(ESD) grounding strap to an ESD point and place the other end of the strap around your bare wrist. Failure to use an ESD grounding strap could result in damage to the device. Copyright © 2017, Juniper Networks, Inc.
Page 274: Action To Take After An Electrical Accident
EX2300-C and EX2300 Switches Hardware Guide Install the device in compliance with the following local, national, and international electrical codes: United States—National Fire Protection Association (NFPA 70), United States National Electrical Code. Other countries—International Electromechanical Commission (IEC) 60364, Part 1 through Part 7.
Page 275: Prevention Of Electrostatic Discharge Damage
(see Figure 75 on page 254). If you are returning a component, place it in an antistatic bag before packing it. Copyright © 2017, Juniper Networks, Inc.
Page 276: Ac Power Electrical Safety Guidelines
EX2300-C and EX2300 Switches Hardware Guide Figure 75: Placing a Component into an Antistatic Bag CAUTION ELECTROSTATIC SENSITIVE DEVICES DO NOT OPEN OR HANDLE EXCEPT AT A STATIC-FREE WORKSTATION CAUTION: ANSI/TIA/EIA-568 cables such as Category 5e and Category 6 can get electrostatically charged. To dissipate this charge, always ground the cables to a suitable and safe earth ground before connecting them to the system.
Page 277: Ac Power Disconnection Warning
Warnung Bevor Sie an einem Chassis oder in der Nähe von Netzgeräten arbeiten, ziehen Sie bei Wechselstromeinheiten das Netzkabel ab bzw. Avvertenza Prima di lavorare su un telaio o intorno ad alimentatori, scollegare il cavo di alimentazione sulle unità CA. Copyright © 2017, Juniper Networks, Inc.
Page 278: Dc Power Electrical Safety Guidelines For Switches
EX2300-C and EX2300 Switches Hardware Guide Advarsel Før det utføres arbeid på kabinettet eller det arbeides i nærheten av strømforsyningsenheter, skal strømledningen trekkes ut på vekselstrømsenheter. Aviso Antes de trabalhar num chassis, ou antes de trabalhar perto de unidades de fornecimento de energia, desligue o cabo de alimentação nas unidades de corrente alternada.
Page 280 EX2300-C and EX2300 Switches Hardware Guide The marked input voltage of –48 VDC for a DC-powered device is the nominal voltage associated with the battery circuit, and any higher voltages are only to be associated with float voltages for the charging function.
Page 281: Dc Power Disconnection Warning
Aviso Antes de executar um dos seguintes procedimentos, certifique-se que desligou a fonte de alimentação de energia do circuito de corrente contínua. Para se assegurar que toda a corrente foi DESLIGADA, localize o disjuntor no Copyright © 2017, Juniper Networks, Inc.
Page 282: Dc Power Grounding Requirements And Warning
EX2300-C and EX2300 Switches Hardware Guide painel que serve o circuito de corrente contínua e coloque-o na posição OFF (Desligado), segurando nessa posição a manivela do interruptor do disjuntor com fita isoladora. ¡Atención! Antes de proceder con los siguientes pasos, comprobar que la alimentación del circuito de corriente continua (CC) esté...
Page 283: Dc Power Wiring Sequence Warning
à l'extrémité de câblage. En reliant la puissance, l'ordre approprié de câblage est rectifié pour rectifier, +RTN à +RTN, puis –48 V à –48 V. En débranchant la puissance, l'ordre approprié de câblage est –48 V Copyright © 2017, Juniper Networks, Inc.
Page 284 EX2300-C and EX2300 Switches Hardware Guide à –48 V, +RTN à +RTN, a alors rectifié pour rectifier. Notez que le fil de masse devrait toujours être relié d'abord et débranché pour la dernière fois. Notez que le fil de masse devrait toujours être relié d'abord et débranché pour la dernière fois.
Page 286: Multiple Power Supplies Disconnection Warning
EX2300-C and EX2300 Switches Hardware Guide respectivos cabos, e deverão prender simultaneamente o isolamento e o fio condutor. ¡Atención! Cuando se necesite hilo trenzado, utilizar terminales para cables homologados, tales como las de tipo "bucle cerrado" o "espada", con las lengüetas de conexión vueltas hacia arriba.
Page 287 TN-typ. Related General Safety Guidelines and Warnings on page 223 Documentation General Electrical Safety Guidelines and Warnings on page 251 Grounded Equipment Warning on page 238 Multiple Power Supplies Disconnection Warning on page 264 Copyright © 2017, Juniper Networks, Inc.
Page 289: Agency Approvals And Compliance Statements
FCC 47CFR Part 15 Class A (USA) EN 55022 Class A Emissions (Europe) ICES-003 Class A VCCI Class A (Japan) AS/NZS CISPR 22 Class A (Australia/New Zealand) CISPR 22 Class A EN 55024 EN 300386 Copyright © 2017, Juniper Networks, Inc.
Page 290: Compliance Statements For Emc Requirements For Ex Series Switches
EX2300-C and EX2300 Switches Hardware Guide EN 61000-3-2 Power Line Harmonics EN 61000-3-3 Voltage Fluctuations and Flicker EN 61000-4-2 ESD EN 61000-4-3 Radiated Immunity EN 61000-4-4 EFT EN 61000-4-5 Surge EN 61000-4-6 Low Frequency Common Immunity EN 61000-4-11 Voltage Dips and Sags...
Page 291: European Community
Japan The preceding translates as follows: This is a Class A device. In a domestic environment this device might cause radio interference, in which case the user needs to take adequate measures. VCCI-A Copyright © 2017, Juniper Networks, Inc.
Page 292: Korea
EX2300-C and EX2300 Switches Hardware Guide Korea Korean Class A Warning The preceding translates as follows: This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except...
Page 293: Nonregulatory Environmental Standards
The battery return connection is to be treated as an Isolated DC return (DC-I), as defined in GR-1089-CORE. Related Agency Approvals for EX Series Switches on page 267 Documentation Compliance Statements for Acoustic Noise for EX Series Switches on page 272 Copyright © 2017, Juniper Networks, Inc.
Page 294: Compliance Statements For Acoustic Noise For Ex Series Switches
EX2300-C and EX2300 Switches Hardware Guide Compliance Statements for Acoustic Noise for EX Series Switches This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine.

This manual is also suitable for:

Ex2300

Juniper EX2300-C Hardware Manual

Chapter 1 System Overview

Chapter 2 Chassis Components and Descriptions

Chapter 3 Cooling System and Airflow

Chapter 4 Power Supplies

Chapter 5 Viewing System Information

Chapter 6 Preparation Overview

Chapter 7 Power Specifications and Requirements

Chapter 8 Transceiver and Cable Specifications

Chapter 9 Pinout Specifications

Chapter 10 Planning the Virtual Chassis

Chapter 11 Unpacking the Switch

Chapter 12 Installing the Switch

Chapter 13 Connecting the Switch to Power

Chapter 14 Switch

Chapter 15 Performing Initial Configuration

Chapter 16 Replacing Transceiver

Chapter 17 Maintaining and Replacing Fiber-Optic Cable

Chapter 18 Contactingcustomersupportandreturningthechassisor

Chapter 19 Alarms and System Log Messages

Chapter 20 General Safety Guidelines and Warnings

Chapter 21 Fire Safety Requirements

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Juniper EX2300-C

Summary of Contents for Juniper EX2300-C
