Quick Start Guide
EX2200
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 4
Step 3: Keep Going | 6
Step 1: Begin
IN THIS SECTION
Mount the EX2200 on Two Posts of a Rack | 2
Connect Power to the EX2200 | 2
To install and perform initial configuration of a Juniper Networks EX2200 Ethernet Switch, you need:
Two mounting brackets and eight mounting screws (provided)
Screws to secure the chassis to the rack or cabinet (not provided)
Phillips (+) screwdriver, number 2 (not provided)
For AC systems—an AC power cord with a plug appropriate for your geographical location and a power cord retainer—both
provided
For DC systems—DC power source cables (12–14 AWG—not provided) with ring lugs (Molex 0190700067 or
equivalent—not provided) attached
For grounding the switch—a grounding cable (minimum 14 AWG (2 mm²), minimum 90°C wire), a grounding lug (Panduit
LCD6-14BH-L or equivalent), a pair of 10-32x.25-in. screws, and a pair of flat washers—none provided
Ethernet cable with an RJ-45 connector attached (provided)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Juniper EX2200
Summary of Contents for Juniper EX2200
- Page 1 Mount the EX2200 on Two Posts of a Rack | 2 Connect Power to the EX2200 | 2 To install and perform initial configuration of a Juniper Networks EX2200 Ethernet Switch, you need: Two mounting brackets and eight mounting screws (provided)
- Page 2 RJ-45 to DB-9 serial port adapter (provided) Management host, such as a PC, with an Ethernet port (not provided) Mount the EX2200 on Two Posts of a Rack Two people are required for this procedure. 1. Place the rack or cabinet in its permanent location, allowing adequate clearance for airflow and maintenance, and secure it to the building structure.
- Page 3 Connecting EX2200 to AC power NOTE: Grounding is required for DC systems and recommended for AC systems. An AC-powered switch gets additional grounding when you plug the power supply in the switch into a grounded AC power outlet using the power cord.
- Page 4 Connecting EX2200 to DC power The DC power supply has four terminals labeled A+, B+, A–, and B– on the rear panel, covered by a clear plastic cover. WARNING: Ensure that the input circuit breaker is open so that the cable leads will not become active while you are connecting DC power.
- Page 5 If you have configured anything on the switch and want to run ezsetup, revert to the factory default configuration. For information about reverting to the factory default configuration, see the EX Series documentation at https://www.juniper.net/documentation/product/en_US/ex2200. Before you begin connecting and configuring the switch through the console using the CLI, set the following parameter values in the console server or PC: Baud Rate—9600...
- Page 6 Power Cable Warning (Japanese) | 7 Contacting Juniper Networks | 7 See the complete EX Series documentation at https://www.juniper.net/documentation/product/en_US/ex2200. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the EX Series documentation at https://www.juniper.net/documentation/product/en_US/ex2200.
- Page 7 Before connecting the switch to a power source, read the installation instructions in the EX Series documentation. Installing an EX2200 switch requires one person to lift the switch and a second person to install the mounting screws. If the rack has stabilizing devices, install them in the rack before mounting or servicing the switch in the rack.
