Altronix eBridge100STR Installation Manual page 3

Fig. 1 eBridge100RM
Coax out to
eBridge100ST
Fig. 2
eBridge100RM
eBridge100RM
EoC Receiver
passes PoE/PoE+
RJ45 LEDs Yellow - Speed
Green - Activity
Yellow LED Power and PoE
Z1409
I.T.E. 43KC
www.altronix.com
RJ45 PoE
Coax OUT LED Input
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Camera
Power/PoE Class
13W/0
4W/1
6.5W/2
13W/3
19W
25W
eBridge100STR
N/A
Yellow LED
indicates
PoE being
transmitted
to eBridge100ST
Single PoE Camera Connection:
Mounting Hole
PoE PoE
LED
100m
max.
Midspan or
PoE Switch
PoE/PoE+ over Coax up to 300m max.
RG59/U -
23AWG
260.64
500
500
260.64
152.4
118.9
Yellow LED
indicates
PoE Present
from Midspan/
Endspan
Structured Cable
from Midspan/
Endspan
RG59/U - RG59/U -
22AWG 20AWG
Max. Length (meters)
335.28
500
500
335.28
198.12 315.5
150.6 239.3
eBridge100ST
Green LED
indicates
PoE Out
to Device
Fig. 2a
eBridge100ST
Coax
Link
eBridge100ST - Transceiver
Supports PoE/PoE+
RJ45 LEDs Yellow - Speed
Green - Activity
Yellow LED Power and PoE
www.altronix.com
RG59/U -
18AWG
500 500
500 500
500 500
500 500
500
365.8
Flying BNC
Connector
Structured
Cable from
Camera/Device
PoE Camera
RJ45
Link
PoE compliant
100m max.
Legend:
Structured Cable
Coax
RG6/U -
18AWG
500
500
500
500
500
365.8
- 3 -
