iSocket 3G User Manual page 5

iSocket ® 3G
For more information about the technical characteristics of iSocket 3G see Chapter 15 and
also visit www.isocket3g.com
Main power socket
Socket for connecting
external electrical
equipment, which can
be controlled remotely.
(Figure shows
plug/socket type NEMA
5-15, North America,
model IS3GUS).
Hidden button
Used to switch the
main socket manual
(Chapter 4.3) or reset
device (Chapter 13).
OUT
Indicator of output
power for main
socket.
Socket for
TEMPERATURE sensor
3.5mm jack, RED (See
Chapter 7)
Pictures below describe the plugs and sockets of other models.
Socket/Plug: Socket/Plug:
BS 1363 CEE 7/4,
(British) German
"Schuko"
© Copyright iSocket Systems 2017
All rights reserved. Version 1.0.2-EN
Socket for SIM- card (micro SIM)
Socket/Plug: Socket/Plug:
CEE 7/5 AS/NZS 3112
(French) (Australian)
- 4 -
www.isocket3g.com
Plug to connect
iSocket to the wall
socket to provide
power for device and
for connected
appliance.
POWER
Indicator of input
power from power
network.
ONLINE
Status indicator for
mobile network.
Additional information
about the indicators is
given in Chapter 14
Socket/Plug: Socket/Plug:
SEV 1011 CEI 23-50
(Swiss) S17/P17
(Italian)
.
Socket/Plug:
SI32 (Israeli)
