14. LED Indicators
The LED positions were described in Chapter 1. Below we list possible LED modes.
POWER (green)
Lights constantly
Blinks 4 times per second then lights
2 seconds
ONLINE (blue)
Lights constantly
Blinks every second
Blinks fast
OUT (red)
No light
Lights constantly
Blinks very fast (4 times per second) A possible hardware error – see the behavior of other indicators
POWER and OUT blink 3 times
together only once
POWER and OUT blink together 4
times per second then light 2
seconds
POWER and OUT blinks alternately
15. Technical Data
Product
iSocket 3G
Available
Socket/Plug: NEMA 5-15 (North America) - Model Number: IS3GUS
Socket/Plug
Socket/Plug: AS/NZS 3112 (Australian) - Model Number: IS3GAU
Socket/Plug: BS 1363 (British) - Model Number: IS3GUK
Socket/Plug: CEE 7/4 ("Schuko") - Model Number: IS3GEU
Socket/Plug: CEE 7/5 (French) - Model Number: IS3GFR
Socket/Plug: CEI 23-50 S17/P17 (Italian) - Model Number: IS3GIT
Socket/Plug: SEV 1011 (Swiss) - Model Number: IS3GCH
Socket/Plug: SI32 (Israeli) - Model Number: IS3GIL
Power Input
100-240VAC, 50-60Hz
Consumption
Stand-by power <1W, Green Power
Output Relay
Max. switching 16A/250VAC, protected by 15A fuse. Turn on/off or restart of
120VAC/240VAC appliances by sms or call.
Hidden button For manual switching of main relay and for reset to factory defaults.
Input for
Mini-jack 3.5mm connector on the rear of the device, RED color. Only sensors from the
Temperature
original manufacturer are supported. Sensors are weather-proof or water-proof,
Sensor
measurement limits from -67F (-55C) to 248F (120C). ±0.5°C accuracy from -10°C to
+85°C.
Temperature
Thermometer and thermostat features, temperature measurement provided by SMS,
control
turn on/off equipment by thermostat's settings. iSocket
send temperature rise/fall notifications.
Indicators
POWER green, ONLINE blue, OUT red
Built-in
Li-ion or Li-po high quality batteries with excess capacity cater for signal delays in the
rechargeable
event of a break in the cellular network before sending the power failure alert. Charging
battery
from internal charger about 20 hours if totally discharged. iSocket
power failure/restore alerts.
SIM socket
Micro SIM, push-push type, plug-in SIM card 1.8/3V, contract or prepaid (PAYG) SIM
cards
© Copyright iSocket Systems 2017
All rights reserved. Version 1.0.2-EN
Input power to device is OK
SIM card is missed or incorrect placed
Not logged to the network yet – either searching, or poor signal,
or SIM card problem
Logged to the cellular network
Data exchange (e.g. during firmware update or working via API
with a remote server)
Main power socket is turned off
Main power socket is turned on
This blinking indicates that the firmware has started and usually
you will see it only once after powering up the device or after a
remote firmware update
SIM card problem (PIN protection is enabled, no communication
with SIM card, wrong or bad SIM card)
iSocket is upgrading firmware after you have sent FWUPDATE to
it. Do not switch off the power! Just wait
- 26 -
