Automatic Population
The Virtual Gauges are populated by adding gauges if the related vehicle
information is available. The Virtual Gauges app adds available gauges
following the priority established.
The actual Virtual Gauges page from the Virtual Gauges app page is
highlighted, allowing the user to differentiate it from the disabled pages and
from the active pages that are not selected as the actual page.
The Standard Priority list of gauges have a higher priority than the Optional
Gauges, even if a given gauge from the Optional gauges shares a priority
level with a gauge from the Standard Priority gauges.
If not Available information for a specific Gauge is received from the vehicle
information bus is received the related Gauge will be hidden upon the next
key cycle. Some virtual gauges show a specific icon in the case of a not
available gauge.
The Virtual Gauges app pages for gauges population are disabled if there
are no gauges in the page. The disabled Virtual Gauges app pages are
displayed in an opaque manner.
The active Virtual Gauges app pages are displayed in clear way which
allows the user to differentiate between the actual page and disabled pages.
As the optional virtual gauges become available, they starts to be
accommodated from the last active gauge displayed filling the available slots
in all the pages in an incremental order and following the preset priority.
The Virtual Gauges app does not allow the user to select the disabled gauge
pages until they become available.
Each time a Virtual Gauges app page is filled with gauges, the Virtual
Gauges app activates the subsequent page, in incremental order, to
continue placing the active virtual gauges.
Priority presets
Priority Preset 1
Gauge
Engine Oil Temperature
Main Trans Oil Temperature
Manifold Pressure (Boost)
DPF Status
Fuel Economy
Percent Torque
Percent Horsepower
Owner´s Manual DEA600 Radio
Priority Preset 2
Preset Gauges Interaction
The positions of the active gauges can be adjusted in the General Settings
screen of the Virtual Gauges app by selecting a gauge and dragging it to a
new desired position.
Individual gauges can be moved by selecting and then dragging to a new
Priority
position. As the gauge is dragged it will snap into the closest gauge slot
Page One
even if the slot is already occupied by another gauge. The gauge will be
Page One
moved to the location shown when the user deselects the gauge.
Page One
While a gauge is being moved and starts snapping in other gauge slots in
Page One
the General Settings screen of the Virtual Gauges app, the other gauges re-
Page One
position to give space to the dragged gauge.
Page One
NA
Gauge
Idle Time
Idle Fuel
Fuel Usage Rate
Drive Axle #1 (front) Oil Temperature
Drive Axle #2 (rear) Oil Temperature
Drive Axle #3 (center) Oil Temperature
Air Filter Restriction Pressure
Fuel Filter Restriction/Fuel Pressure Gauge
Ammeter
Air Suspension Pressure 1
Tractor Brake Application
Pusher Axle #1 Pressure
PTO Hour Meter
Gauge
Engine Oil Temperature
Main Trans Oil Temperature
Manifold Pressure (Boost)
DPF Status
Fuel Economy
Percent Torque
Percent Horsepower
Idle Time
Idle Fuel
Priority
NA
NA
NA
2
3
4
6
7
1
5
N/A – In Cluster
8
9
Priority
Page One
Page One
Page One
Page One
Page One
Page One
N/A
N/A
N/A
