Delphi Roady 2 SA10109-11P1 User Manual

Delphi Roady 2 SA10109-11P1 User Manual

Personal audio system
Hide thumbs Also See for Roady 2 SA10109-11P1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
white logo
Personal Audio System
white logo
User Guide
For Use With Roady2
white logo
™
Satellite Radio Receiver
Warning: This manual contains important safety
and operating information. Please read and follow
the instructions in this manual. Failure to do so could
result in personal injury, death, and/or damage to
your Roady 2
™
Personal Audio System, your home,
and/or to your vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Roady 2 SA10109-11P1 and is the answer not in the manual?

Questions and answers

Related Manuals for Delphi Roady 2 SA10109-11P1

Summary of Contents for Delphi Roady 2 SA10109-11P1

  • Page 1 Please read and follow the instructions in this manual. Failure to do so could result in personal injury, death, and/or damage to your Roady 2 and/or to your vehicle. ™ Satellite Radio Receiver ™ Personal Audio System, your home,...
  • Page 2 IMPORTANT: The FCC and FAA have not certified the Delphi XM ® Roady2 Personal Audio System for use ™ in any aircraft (neither portable nor permanent installation). Therefore, Delphi cannot support this type of application or installation.
  • Page 3 Welcome Thank you for purchasing a Delphi Roady2 Personal Audio System. The Delphi Roady2 Personal Audio System allows the Roady2 Satellite Radio Receiver to become a completely portable and personal satellite radio system. With the Roady2 Personal Audio System, you have even more ways to access over 130 XM Satellite Radio channels of music, news, and information from coast to coast.
  • Page 4 About Roady2 Roady2 is the latest in the acclaimed line of portable devices from Delphi and XM Satellite Radio and represents the best in audio technology. The smallest and lightest satellite radio receiver currently available, Roady2 is always ready to go with you. Just plug it in and go! ™...

  • Page 5: About Delphi

    About Delphi Delphi is a worldwide leader in mobile electronics, vehicle components, and audio technology. Delphi created the first in-dash car radio in 1936 and continues its strong tradition of innovation in the audio industry. Now Delphi technology has helped make satellite radio a reality, and Delphi continues to expand its in-vehicle and consumer electronics technologies.

  • Page 6: Table Of Contents

    Contents Section 1: Components ........1 Section 2: Getting Started Setup .
  • Page 7 Section 4: Basic Operations XM Tuning ..........11 FM Tuning .

  • Page 9: Section 1: Components

    Section 1: Components Your Roady2 Personal Audio System contains the following components: Headset with built-in XM antenna AC power adaptor Docking station...

  • Page 10: Section 2: Getting Started

    Section 2: Getting Started Setup To quickly begin enjoying your Roady2 Personal Audio System, follow the steps in this section and also refer to your Roady2 User Guide as noted. To obtain a copy of the Roady2 User Guide, go to www.shopdelphi.com. Inserting Roady2: 1.
  • Page 11 3. Place the Roady2 inside the Roady2 docking station (see figure 2). 4. Gently push both ends of the Roady2 docking station together so that both ends click back together. Note: The Roady2 will fit snugly inside. Do not use unnecessary force. Figure 2.
  • Page 12 5. Plug in the headset as shown in figure 3. 6. Turn the Roady2 Personal Audio System on by sliding the mode switch to FM or XM as shown in figure 4. If the display is not on, see “Troubleshooting” on page 15. Note: The display on the Roady2 only appears if you are in XM mode.
  • Page 13 7. Refer to your Roady2 User Guide and do the following: • Turn on the Auto-On feature (see Menu, Auto-On) • Set the Roady2 audio level setting at 9 (see Menu, Audio Level) • Select a screen color of red for optimal battery performance (see Menu, Screen Color) 8.

  • Page 14: Removing Roady2

    Removing Roady2: 1. Push down the latches on both sides of the Roady2 docking station and, while holding the Roady2 docking station firmly, gently slide the tray outward as shown in figure 5. Note: Connectors are tight by design to help ensure optimal performance. When removing Roady2, press latches and slide tray firmly.

  • Page 15: Section 3: Displays And Features

    The Roady2 Personal Audio System display shows the mode (FM or XM), FM station, battery charge indicator, and volume. To view the XM channel, use your Roady2 display. Mode Display There are three modes: FM radio, XM satellite radio, and OFF. This mode… Indicates… FM radio...

  • Page 16: Volume Display

    Volume Display When you change the volume, the volume display appears. This display… V O L V O L Backlight Any time you adjust the controls or change modes the blue LED backlight turns on for a short time so you can easily read the display information. Battery Indicator See “Battery Operation and Charging”...

  • Page 17: Headset

    Headset The unique headset has been specially designed for the Roady2 Personal Audio System to receive satellite radio signals and produce excellent sound quality. The headset contains a built-in antenna that has the same ability to receive satellite signals as the antenna that is included in the Roady2 package.

  • Page 18: Ac Power Adaptor

    If you want your battery to last the longest, select a screen color of red on your Roady2. Refer to your Roady2 User Guide for more information. To obtain a copy of the User Guide, visit www.shopdelphi.com. This product should not be operated if the air temperature is lower than 0˚C (32˚F) or higher than 40˚C (104˚F).

  • Page 19: Section 4: Basic Operations

    Section 4: Basic Operations XM Tuning To tune XM channels: 1. Switch to XM. Note: If you are in a location where you cannot receive satellite sig- nals, you can still use the FM radio. 2. Follow the XM channel selection procedure in the Roady2 User Guide. To obtain a copy of the Roady2 User Guide, go to www.shopdelphi.com.

  • Page 20: Volume Control

    Volume Control You can change the volume in three different ways. While the preferred method is the Roady2 docking station joystick, you can also use the volume dial on the headset or the volume control on the Roady2 unit itself. Caution: Before putting on the headset, always adjust the volume setting at the lowest level to avoid possible hearing damage.

  • Page 21: Removing The Battery

    Removing the battery: The battery is removed from the back of the Roady2 Personal Audio System. 1. Turn off the Roady2 Personal Audio System by switching the mode to OFF. 2. Press the latch at the top of the battery. 3.

  • Page 22: Battery Indicators

    You know the battery is charging when the battery indicators flash sequentially. Battery indicators: The battery indicators (at the upper left part of the display) indicate the state of the battery: This indicator… Means the battery is… Fully charged. Charging is complete. 100% charged.

  • Page 23: Section 5: Reference

    Section 5: Reference Taking Care of Your Roady2 Personal Audio System Important: • Use only a soft, dry cloth to clean the outside of your Roady2 Personal Audio System and any peripherals. • Do not use any solvents, chemicals, or cleaning solutions containing alcohol, ammonia, or abrasives.

  • Page 24: Troubleshooting

    • Check to see if you can receive FM signals. If so, then there is a problem with the XM receiver. Contact Delphi Product Technical Support (see page 17). • Ensure you are in an open area with no obstructions such as large trees or buildings.

  • Page 25: Contacting Product Technical Support

    Contacting Product Technical Support For additional information or assistance with your Roady2 Personal Audio System, contact Delphi Technical support at 1.877.GO DELPHI (1.877.463.3574) Monday—Friday, 8:00 a.m.—8 p.m. Eastern Time. Technical Support is also available at www.delphi.com. Technical Information • Overall dimensions of Roady2 docking station: 5.03 in. long x 2.99 in.

  • Page 26: Section 6: Warranty

    Product. Delphi will, as its sole obligation under this warranty, replace or repair, at its option, any Product that does not conform to this warranty. Products may be repaired or replaced with new or with refurbished items.
  • Page 27 This warranty gives you specific legal rights. You may also have other rights that may vary from state to state. NO PERSON IS AUTHORIZED BY DELPHI TO MODIFY OR ADD TO THIS LIMITED WARRANTY.
  • Page 28 1441 West Long Lake Road • Troy, Michigan 48098-5090 U.S.A. Customer Service: [1] 877.GO DELPHI www.delphi.com www.shopdelphi.com The Roady2 name, XM name, and related logos are trademarks of XM Satellite Radio Inc. © 2004 Delphi Corporation. All rights reserved. DPSS-04-E-068 color logo color logo...
