- Page 1 M-Series HMI 12”/15”/17”/19”/ 21.5” P-CAP touchscreen Intel® Core ™ i5-6200U 2.3 GHz, up to 2.8 GHz Multifunctional Design Model No.: R12IKWS-MHM2 R15IKWS-MHC3 R17IKWS-MHM1 R19IKWS-MHA1 W22IKWS-MHA3 User Manual Version 1.0 Document part Number: 9152111I102E...
-
Page 2: Preface
USER MANUAL PREFACE PREFACE Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 3 USER MANUAL PREFACE Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 4 USER MANUAL PREFACE Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
- Page 5 USER MANUAL PREFACE Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.
- Page 6 USER MANUAL PREFACE Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ...
- Page 7 USER MANUAL PREFACE CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer.
- Page 8 USER MANUAL PREFACE Important Information Countries/ Area Symbol This equipment complies with essential requirements of: European Union Electromagnetic Compatibility Directive (2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
- Page 9 USER MANUAL PREFACE European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014...
-
Page 10: About This User Manual
ABOUT THIS USER MANUAL ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® M-Series HMI with Intel® Core ™ i5-6200U processor. The documentation set for the M -Series HMI provides information for specific user needs, and includes: ... -
Page 11: Table Of Contents
USER MANUAL CONTENTS CONTENTS PREFACE ..............................ii ABOUT THIS USER MANUAL ........................x CHAPTER 1: INTRODUCTION ........................2 1.1 Product Features ..........................2 1.2 Package Contents ..........................3 1.3 I/O Layout ............................4 1.4 Power Button ............................. 4 1.5 Reset Button ............................5 1.6 LED Indicator ............................. - Page 12 USER MANUAL CONTENTS 3.2 Multi-Touch ............................. 22 3.3 Adjusting Display Brightness ......................23 CHAPTER 4: AMI UEFI BIOS SETUP ......................25 4.1 When and How to Use BIOS Setup ....................25 4.2 BIOS Functions ..........................26 4.2.1 Main Menu ........................... 27 4.2.2 Advanced Menu ........................
- Page 13 USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. M-SERIES HMI...
-
Page 14: Chapter 1: Introduction
CHAPTER 1 INTRODUCTION CHAPTER 1: INTRODUCTION Thank you for purchasing Winmate® M-Series HMI. M-Series HMI is designed to provide versatile and cost-effective solution for your industrial needs. P-CAP multi-touch screen equipped with industrial motherboard offers various input/ output connectors. Intel®... -
Page 15: Package Contents
USER MANUAL CHAPTER 1 INTRODUCTION 1.2 Package Contents Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. -
Page 16: I/O Layout
USER MANUAL CHAPTER 1 INTRODUCTION 1.3 I/O Layout Description Description ① PCIe Slot Cover for one half-length ⑩ Mic in PCIe x4 card ② 9-29V isolation DC-in ⑪ 2.5” HDD x 1 ③ Giga LAN ⑫ Expansion module* ④ Giga LAN ⑬... -
Page 17: Reset Button
USER MANUAL CHAPTER 1 INTRODUCTION 1.5 Reset Button M-Series HMI has a Reset Button located on the front side. Press reset button to reboot the computer forcibly. 1.6 LED Indicator M-Series HMI provides one HDD LED indicator for status monitoring. LED Indicator: LED Indicator Color... -
Page 18: Dimensions
USER MANUAL CHAPTER 1 INTRODUCTION 1.7 Dimensions This section contains mechanical drawing of the HMI devices. Notice that this is a simplified drawing and some components are not marked in detail. 1.7.1 Dimensions 12” Unit: mm M-SERIES HMI... -
Page 19: Dimensions 15
USER MANUAL CHAPTER 1 INTRODUCTION 1.7.2 Dimensions 15” Unit: mm M-SERIES HMI... -
Page 20: Dimensions 17
USER MANUAL CHAPTER 1 INTRODUCTION 1.7.3 Dimensions 17” Unit: mm M-SERIES HMI... -
Page 21: Dimensions 19
USER MANUAL CHAPTER 1 INTRODUCTION 1.7.4 Dimensions 19” Unit: mm M-SERIES HMI... -
Page 22: Dimensions 21.5
USER MANUAL CHAPTER 1 INTRODUCTION 1.7.5 Dimensions 21.5” Unit: mm M-SERIES HMI... -
Page 23: Getting Started
USER MANUAL CHAPTER 2 GETTING STARTED GETTING STARTED This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. M-SERIES HMI... -
Page 24: Chapter 2: Getting Started
USER MANUAL CHAPTER 2 GETTING STARTED CHAPTER 2: GETTING STARTED This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On This section explains how to power on the HMI device. -
Page 25: Power Considerations
USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2 Power Considerations HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package (Rating: Output 12V/6.6A). Using other AC adapters may damage the device. Utiliser seulement le convertisseur AC inclu avec votre appareil (Puissance: Sortie 12V/6.6A). - Page 26 USER MANUAL CHAPTER 2 GETTING STARTED 2.1.3.2 Connecting to DC Power Source To connect the HMI to DC power source: 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2. Plug the terminal block plug firmly to the DC IN Jack. 3.
-
Page 27: Connector Description
USER MANUAL CHAPTER 2 GETTING STARTED 2.2 Connector Description This section includes I/O side connectors and its pinouts. 2.2.1 Isolated DC in Connector M-Series HMI has a 3pin terminal block that accepts 9~29V DC input. Minimum Voltage 9V Maximum Voltage 29V Voltage 2.2.2 Mic In, Line In and Line Out Color... -
Page 28: Usb 3.0 Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.4 USB 3.0 Connector The I M-Series HMI has four USB 3.0 connectors. Use USB3.0 connectors to connect external devices such as mouse or keyboard to the device. Pin № Signal Name Pin № Signal Name USB_D- USB_D+... -
Page 29: Hdmi Output Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.6 HDMI Output Connector Use HDMI A Type19-pin female output connector to connect the HMI device to an external display. Pin № Signal Name Pin № Signal Name TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK- DDC_CLOCK... -
Page 30: Turning On And Off
USER MANUAL CHAPTER 2 GETTING STARTED 2.3 Turning On and Off The unit is configured to Power ON when the HMI device is connected to the power source. Press the Power button to restart the machine when the unit has been shut down. If the system hangs, press the Reset button (beside the power button) to restart the device. -
Page 31: Configuring Serial Port Settings
USER MANUAL CHAPTER 2 GETTING STARTED 2.4 Configuring Serial Port Settings Serial Port can be configured for RS-232, RS-422 or RS-485. Jumpers are located on the motherboard. You need to open the housing in order to access the jumpers. CAUTION/ ATTENTION It is recommended to use factory jumper settings. - Page 32 USER MANUAL CHAPTER 3 OPERATING THE DEVICE OPERATING THE DEVICE This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. M-SERIES HMI...
-
Page 33: Chapter 3: Operating The Device
USER MANUAL CHAPTER 3 OPERATING THE DEVICE CHAPTER 3: OPERATING THE DEVICE In this chapter you will find instructions on how to use multi-touch on the Windows- based HMI device. 3.1 Operating System M-series HMI support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8 Standard, and Windows Embedded Standard 7 –... -
Page 34: Multi-Touch
USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.2 Multi-Touch The touchpad supports the core gestures for Windows. Gesture Windows Usage Gesture Action Action Tap/ Click / Double- Click or double-click Double-tap click Panning with Scrolling Drag one or two Inertia fingers up and down Selection/Drag Mouse-drag/... -
Page 35: Adjusting Display Brightness
USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.3 Adjusting Display Brightness Tap Start > Control Panel > Hardware and Sound > Power Options. Drag the brightness bar to adjust the brightness level according to your preference. M-SERIES HMI... - Page 36 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP AMI UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.
-
Page 37: Chapter 4: Ami Uefi Bios Setup
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP CHAPTER 4: AMI UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. -
Page 38: Bios Functions
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2 BIOS Functions BIOS Navigation Keys BIOS navigation keys for keyboard control are listed below. The following keys are enabled during POST: Function Enters the BIOS setup menu. Display the boot menu. Lists all bootable devices that are connected to the system. -
Page 39: Main Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears. -
Page 40: Advanced Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. - Page 41 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Intel ® I211 Gigabit Configure Gigabit Network Enter Opens submenu device parameters Connection Configures Trusted Trusted Computing Enter Opens submenu Computing settings Configures ACPI ACPI Settings Enter Opens submenu Settings...
- Page 42 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.1 CPU Configuration CPU Configuration allows you to change CPU settings. Use key arrows to navigate through the menu. Setting BIOS Setting Description Effect Option Hyper-threading is a function in processors Enable/ Enables or Disables Hyper-threading that speeds up...
- Page 43 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Enables a CPU to act as if you have several independent Intel Virtualization computers, in order Enable/ Enable or disable this Technology to enable several Disable function operating systems to run at the same time on the same machine.
- Page 44 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.2 Trusted Computing BIOS Setting Description Setting Option Effect Enable or disable BIOS support for security device. O.S. will not show Security Device Enable or disable Security Device. Enabled/ Disabled Support this function. TCG EFI protocol and INT1A interface will not...
- Page 45 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.3 ACPI Settings BIOS Setting Description Setting Option Effect Enable or disable Enable ACPI Auto Enable or disable BIOS ACPI Auto Enabled/ Disabled Configuration this function Configuration To enable or Enable Enable or disable disable Enabled/ Disabled Hibernation...
- Page 46 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.4 F81866 Super IO Configuration BIOS Setting Description Setting Option Effect Set Parameters of Serial Ports. User can Enable/Disable Enabled/ Disabled Serial Port 1,2 Enable or disable the serial port and Configuration Serial Port (COM) select optimal Default: Enable...
- Page 47 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.5 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. M-SERIES HMI...
- Page 48 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.6 RTC Wake Settings BIOS Setting Description Setting Option Effect Enable or disable Configure wake this function. from full When enabled, Wake system from Enabled/ shutdown and the system will Disabled boot mode (S5) wake on full system setting shutdown and...
- Page 49 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.7 SATA Configuration BIOS Setting Description Setting Option Effect Allows users to enable or disable Enable or disable SATA Controller(s) Enabled/ Disabled the SATA this function controller(s). Allows users to Work in AHCI SATA Mode select mode of AHCI...
- Page 50 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.8 CSM Configuration Compatability Support Module Configuration. BIOS Setting Description Setting Effect Option CSM Support The Compatibility Support Enabled/ Enable or disable Module (CSM) is a component Disabled the Compatibility of the UEFI firmware that Support Module provides legacy BIOS compatibility by emulating a...
- Page 51 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 3.2.2.9 USB Configuration BIOS Setting Description Setting Option Effect Auto Disable legacy support if no USB devices are connected Legacy USB User can enable or Disable Will keep USB Support disable USB port. devices available only for EFI applications.
- Page 52 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP hand‐ off support. function The EHCI ownership change should be claimed by EHCI driver. USB Mass Storage User can Enable or Disable Disables this Driver Support disable USB mass function storage driver Enable Enables this support.
-
Page 53: Chipset Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3 Chipset Menu BIOS Setting Description Setting Option Effect System Agent (SA) System Agent (SA) Enter Opens submenu Configuration Parameters PCH-IO PCH Parameters Enter Opens submenu Configuration M-SERIES HMI... - Page 54 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3.1 System Agent (SA) Configuration BIOS Setting Description Setting Option Effect VT-d can help end users improve security and reliability of the Enables or systems and also VT-d Enable/Disable disables this improve function performance of I/O devices in...
- Page 55 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3.1.1 Graphics Configuration BIOS Setting Description Setting Effect Option Graphics turbo Set up the value of Graphics Turbo IMON current 14~31 Graphics turbo IMON IMON Current values supported current 14~31 Configures Internal Set up internal graphics Internal Graphics Graphics...
- Page 56 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3.2 PCI Configuration BIOS Setting Description Setting Option Effect Configures PCI PCI Express Express Enter Opens submenu Configuration parameters Configures USB USB Configuration Enter Opens submenu parameters Configures PCH Enables or PCH LAN LAN Controller Enable/Disable disables this...
- Page 57 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3.2.1 PCI Express Configuration BIOS Setting Description Setting Option Effect The control of Active State Power DMI Link ASPM Management on Enable/ Enables or disables Control both NB side and Disable this function SB side of the DMI Link.
- Page 58 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP PCI Express Root BIOS Setting Description Setting Option Effect PCI Express Root The control of PCI Enable/ Enables or disables Port 1 Express Root Port Disable this function Configures ASPM Enable/ Enables or disables ASPM Support Support Disable...
- Page 59 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Configures Setting up the Reserved Memory Reserved Memory Set the value value parameters Configures Prefetchable Prefetchable Setting up the Set the value Memory Memory value parameters USB Configuration BIOS Setting Description Setting Option Effect Allows user to Enable/...
-
Page 60: Security Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.4 Security Menu This section allows you to configure and improve your system and allows you to set up some system features according to your preference. BIOS Setting Description Setting Effect Option Administrator Displays whether or not Enter... - Page 61 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.4.1 Security Boot Menu BIOS Setting Description Setting Option Effect Secure Boot Secure Boot is a Enable/ Enables or disables feature designed to Disable this function prevent malicious software and unauthorized media from loading during the boot process.
- Page 62 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Key Management M-SERIES HMI...
-
Page 63: Boot Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.5 Boot Menu BIOS Setting Description Setting Option Effect Setup Prompt Allows user to Enter Set the prompt Timeout configure the timeout number of seconds to stay in BIOS setup prompt screen. Boot NumLock Enables or disables Remains On... - Page 64 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Boot Option Specifies the Ex: Boot Ex.: Set Network Priorities overall boot order Option#1 as the first priority from the available (network); devices Options: #1~#7 Hard Drive 2 BBS Specifies the boot Enter Enter the submenu Priorities...
-
Page 65: Save&Exit
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.6 Save&Exit BIOS Setting Description Setting Option Effect Save Changes and This saves the <YES> Save changes Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS <YES>... - Page 66 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP changes <NO> Return to the BIOS Setup Main Menu Save Changes Save changes done <YES> Saves the so far to any of the changes setup options. <NO> Return to the BIOS Setup Main Menu Discard Changes Discard changes...
-
Page 67: Using Recovery Wizard To Restore Computer
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 68 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP A warning message about data loss will show up. Make sure the data is backed up before recovery, and click Yes to continue. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete.
-
Page 69: How To Enable Watchdog
To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details. To enable watchdog in Watchdog AP follow the instructions below: 1. - Page 70 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Setting Description The system automaticity restarts when this countdown time reaches zero. Watchdog Countdown Time Default: 10 min To set a cycle time to automatically reset watchdog timer. Periodically Feed Time Default: 9 min Enable or disable watchdog.
-
Page 71: Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION DRIVER INSTALLATION This chapter provides driver installation instructions. M-SERIES HMI... -
Page 72: Chapter 5: Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION CHAPTER 5: DRIVER INSTALLATION This chapter provides instructions on how to install drivers on the IKHM100 M-Series Box PC. 5.1 Chipset Driver Installation Follow instructions below to install Chipset driver. 1. Open the Driver CD (included in the package) and select Chipset driver. 2. - Page 73 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Select Accept to agree with the terms of license agreement. 4. Check the ReadMe file information, select Install to continue. M-SERIES HMI...
- Page 74 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. Wait for the driver to be installed. 6. When installation completed, select Restart Now to restart your computer. M-SERIES HMI...
-
Page 75: Graphic Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.2 Graphic Driver Installation Follow instructions below to install Graphic driver. 1. Open the Driver CD (included in the package) and select Graphic driver. 2. Installation window will pop up, select Next. 3. Select Yes to agree with the terms of license agreement. M-SERIES HMI... - Page 76 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4. Check the ReadMe file information, select Next to continue. M-SERIES HMI...
- Page 77 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. Wait for the driver to be installed. 6. Select Next to continue. M-SERIES HMI...
- Page 78 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 7. After installation is completed, select “Yes, I want to restart this computer now”, and click Finish. M-SERIES HMI...
-
Page 79: Me And Net Framework 1.1 Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.3 ME and NET Framework 1.1 Driver Installation Follow instructions below to install Management Engine (ME) and .NET Framework 1.1 driver. 1. Open the Driver CD (included in the package) and select ME driver. 2. - Page 80 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Select .NET Framework 1.1. 4. Select Yes to start the installation. M-SERIES HMI...
- Page 81 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. Wait for the driver to be installed. 6. When installation completed, select Restart Now to restart your computer. 7. Again select the ME to continue installation. Select Next. M-SERIES HMI...
- Page 82 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 8. Please check the license agreement, and then select Next. 9. Select Next to start the installation. 10. Wait for the driver to be installed. M-SERIES HMI...
- Page 83 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 11. When installation completed, select Finish complete installation. M-SERIES HMI...
-
Page 84: Audio Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.4 Audio Driver Installation Follow instructions below to install Audio driver. 1. Open the Driver CD (included in the package) and select Audio driver. 2. Select Next to continue. M-SERIES HMI... - Page 85 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Wait for the driver to be installed. 4. When installation completed, select Finish complete installation. M-SERIES HMI...
-
Page 86: Lan Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.5 LAN Driver Installation Follow instructions below to install LAN driver. 1. Open the Driver CD (included in the package) and select LAN driver. 2. Compression has started. M-SERIES HMI... - Page 87 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. When compression is complete, select Next. 4. Read the license agreement, and then select Next. 5. System displays the installed packages, select Next. 6. Confirm the installation, select Install to start the installation. M-SERIES HMI...
- Page 88 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 7. Wait for installation to complete. 8. When installation is completed, select Finish to close the window. M-SERIES HMI...
-
Page 89: Rst Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.6 RST Driver Installation Follow instructions below to install RTS driver. 1. Open the Driver CD (included in the package) and select RTS driver. 2. Select Next to continue. M-SERIES HMI... - Page 90 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Read the license agreement, and then select Next. 4. Confirm the installation, select Install to start the installation. 5. Select Next to continue. M-SERIES HMI...
- Page 91 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 6. Select Next to start the installation. 7. Wait for installation to complete. 8. Warning message will pop up, select Install. M-SERIES HMI...
- Page 92 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 9. Installation continues. 10. When installation is completed, select Finish to close the window. M-SERIES HMI...
-
Page 93: Microsoft .Net Framework Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.7 Microsoft .NET Framework Driver Installation Follow instructions below to install Microsoft .NET Framework. 1. Open the Driver CD (included in the package) and select .NET Framework. 2. Wait for system to Import the file. M-SERIES HMI... - Page 94 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Read the license agreement, and then select “I agree”. 4. Wait for installation to complete. 5. When installation is completed, select Finish to close the window. M-SERIES HMI...
-
Page 95: Watchdog Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.8 WatchDog Driver Installation For more details about Winmate Watchdog, please download Watchdog Guide from Winmate Downloads Center: http://dc.winmate.com.tw/_downloadCenter/2017/Embedded%20Computing/Watchdo g%20Guide_IB_IH_IV_IK.pdf Follow instructions below to install Watchdog driver. 1. Open the Driver CD (included in the package) and select Watchdog driver. - Page 96 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Wait for installation to complete. 4. When installation is complete, press any key to close. 5. Open the Driver CD (included in the package) and select Watchdog AP. M-SERIES HMI...
- Page 97 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 6. Select Next. 7. The installed storage location is displayed, select Next to continue. 8. Select Next to start the installation. M-SERIES HMI...
- Page 98 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 9. Wait for installation to complete. 10. When installation is completed, select Close to close the window. M-SERIES HMI...
- Page 99 USER MANUAL CHAPTER 6 MOUNTING MOUNTING This chapter provides step-by-step mounting guide for all available mounting options. M-SERIES HMI...
-
Page 100: Chapter 6 Mounting
USER MANUAL CHAPTER 6 MOUNTING CHAPTER 6: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé... -
Page 101: Safety Precautions
USER MANUAL CHAPTER 6 MOUNTING 6.2 Safety Precautions Observe the following common safety precautions before installing the HMI device: • Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. -
Page 102: Panel Mounting
USER MANUAL CHAPTER 6 MOUNTING 6.3.1 Panel Mounting Panel mounting solution allows installing the HMI device onto the wall. Cutout dimension ( W x D in mm) 12” 15” 17” 19” 21.5” 301 x 237 342 x 261 373 x 311 412 x 338 504 x 304 Mounting Clips... -
Page 103: Vesa Mounting
CHAPTER 6 MOUNTING 6.3.2 VESA Mounting M-Series HMI comes with VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). VESA Plate Dimensions Screw Hole Diameter Compatibility 100 x 100 mm... -
Page 104: Technical Support
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT TECHNICAL SUPPORT This chapter includes directory to technical support. M-SERIES HMI... -
Page 105: Chapter 7: Technical Support
This chapter includes directory to technical support and Software Developing Kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us. 7.1 Software Developer Support Winmate provides the following development kits (SDK) for M-Series HMI with Intel® Core i5-5200U Broadwell processor: Item File Type Description Watchdog SDK &... -
Page 106: Problem Report Form
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.2 Problem Report Form M-Series HMI (Multifunctional Design) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ___________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. -
Page 107: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS This section includes product specifications. Appendix M-SERIES HMI... -
Page 108: Appendix A: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS APPENDIX A: PRODUCT SPECIFICATIONS Model Name R12IKWS- R15IKWS- R17IKWS- R19IKWS- W22IKWS- MHM2 MHC3 MHM1 MHA1 MHA3 Display 12” Size 15” 17” 19” 21.5” Active Display 245.76 x 376.32 x 476.64 x 304.1 x 228.1 337.9 x 270.3 Area (H x V) 184.32... - Page 109 USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS Mechanical Specification Cooling Fanless design System Mounting Wall mount/ VESA mount Environmental Consideration Operating 0 to +50°C Temperature Operating 30%~95% at 40°C (non-condensing, RH) Humidity Front: IP65 IP Rating Full: IP20 Power Specifications Power Input 9-29V isolation DC in with protection Fuse Power 110-240 AC to 12V DC out 80W...
- Page 110 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
