Page 1 M Series Box PC Intel® Tiger Lake Core™ i5-1135G7, 2.4 GHz (turbo up to 4.2GHz) Model No.: ITMH100 ITMH100-6L ITMH200 User Manual Version 1.0 Document Part No: 915211101100 Please read these instructions carefully before using this product, and save this manual for future use.
Page 2: Table Of Contents
ITWS M Series Box PC User Manual CONTENTS Preface ............................3 Chapter 1: Introduction ......................6 1.1 Features ..........................6 1.2 Package Contents ....................... 7 1.3 Product Overview ........................ 8 1.3.1 I/O Connectors – ITMH100 ....................8 1.3.2 I/O Connectors – ITMH100-6L ..................8 1.3.3 I/O Connectors –...
Page 3 ITWS M Series Box PC User Manual Appendix A: System Dimensions .................... 46 Appendix B: Software Developer Support ................47...
Page 4: Preface
Preface Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
Page 5 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
Page 6 Preface Safety Information Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Avertissement! Toujours débrancher le cordon d’alimentation du chassis lorsque vous travaillez sur celui-ci.
Page 7: Chapter 1: Introduction
ITWS M Series Box PC User Manual Chapter 1: Introduction Congratulations on purchasing Winmate® M Series BOX PC. ITMH100/ ITMH200 with 11th Generation Intel® i5-1135G7 offers high performance computing power and outstanding video processing. ITMH100/ ITMH200 are suitable for Factory Automation, Machine Vision, Surveillance and other high-performance applications.
Page 8: Package Contents
Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide 3 Pin M Series Box PC Driver CD (Hardcopy) Terminal Block Cable P/N:...
Page 9: Product Overview
ITWS M Series Box PC User Manual 1.3 Product Overview 1.3.1 I/O Connectors – ITMH100 1.3.2 I/O Connectors – ITMH100-6L...
Page 10: I/O Connectors - Itmh200
Chapter 1: Introduction 1.3.3 I/O Connectors – ITMH200...
Page 11: Dimensions
ITWS M Series Box PC User Manual 1.4 Dimensions 1.4.1 ITMH100 1.4.2 ITMH100-6L...
Page 12: Itmh200
Chapter 1: Introduction 1.4.3 ITMH200...
Page 13: Chapter 2: Installation
ITWS M Series Box PC User Manual Chapter 2: Installation 2.1 Mounting 2.1.1 VESA Mount Mounting Instruction: 1. Fasten screws to secure L-shape mounting brackets to the M SERIES BOX PC. 2.1.2 Desk Mount (ITMH200 only)
Page 14: Service Access (Itmh100 Only)
Chapter 2: Installation 2.2 Service Access (ITMH100 only) ITMH100 Box PC provides Service Access. To access the RAM, internal SSD and PCI Card Slot, do the following steps to perform this task: 1. Turn the box pc over and face the back side 2.
Page 15 ITWS M Series Box PC User Manual 4. User will be able to access the RAM, internal SSD, Fuse, and PCI Card Slot as follows...
Page 16: Connecting The Power
2.3 Connecting the Power Connecting to AC Power Source To connect the M Series Box PC to AC power source: 1. Plug one end of the terminal block cable firmly to the DC IN Jack. 2. Plug the other end of the terminal block plug to the AC adapter.
Page 17: Connector Pin Define
TX4+ TX4- 2.4.3 USB 3.2 Gen 1 Connector The M SERIES BOX PC has four USB 3.2 Gen 1 connectors. Use USB3.2 Gen 1 connectors to connect external devices such as mouse or keyboard to the device. Pin № Pin №...
Page 18: Dp Output Connector
RS- 422 RS- 485 (Default) TxD- TxD+ RxD+ RxD- 2.4.7 Giga LAN Connector The M Series Box PC equipped with two RJ45 10/100/1000 Mbps Ethernet interface for connecting to the internet. Pin No Signal Name Pin No Signal Name TX1+ TX1-...
Page 19: Chapter 3: Getting Started
Chapter 3: Getting Started 3.1 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog_AP follow the instructions below: 1.
Page 20 Chapter 3: Getting Started 3.2 S4 Wake on LAN In Windows 10 OS shutdown settings will not have Hibernate mode if your storage capacity is below 32 GB. Caution Check if the system has the storage capacity of minimum 32 GB before entering Hibernation mode.
Page 21 ITWS M Series Box PC User Manual 3.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: Important: Before starting the recovery process, remove the PCIe card.
Page 22 This chapter contains driver installation guide. Follow the instructions below to complete the installation. You will quickly complete the installation. This chapter provides instructions on how to install drivers on the M SERIES BOX PC. 3.4.1 Chipset Driver 1. Follow instructions below to install Chipset driver.
Page 23 ITWS M Series Box PC User Manual 3. Select Accept to agree with the terms of license agreement. 4. Check the ReadMe file information, select Install to continue. 5. Wait for the driver to be installed. When installation completed, select Restart Now to restart...
Page 24 Chapter 3: Getting Started 3.4.2 Graphic Driver Follow instructions below to install Graphic driver. 1. Open the Driver CD (included in the package) and select Graphic driver. 2. Installation window will pop up, select Next.
Page 25 ITWS M Series Box PC User Manual 3. Select Accept to agree with the terms of license agreement. 4. Check the ReadMe file information, select Next to continue.
Page 26 Chapter 3: Getting Started 5. Wait for the driver to be installed. 6. Select Next to continue. 7. After installation is completed, select “Yes, I want to restart this computer now”, and click Finish.
Page 27 ITWS M Series Box PC User Manual 3.4.3 Management Engine (ME) Follow instructions below to install Management Engine (ME). 1. Open the Driver CD (included in the package) and select ME driver. 2. Select Next to start the installation.
Page 28 Chapter 3: Getting Started 3. Select Next to agree with the terms of license agreement. 4. Wait for the driver to be installed. 5. When installation completed, select Finish complete installation.
Page 29 ITWS M Series Box PC User Manual 3.4.4 Intel GNA Driver For Intel 11th Gen Intel CPU which are required to install the Intel Gaussian and Neural Accelerator (GNA) driver, please refer to the instructions below to complete the process.
Page 30 Chapter 3: Getting Started 3.4.5 Intel Serial IO Driver This utility installs the originally shipped version of the Intel Serial IO GPIO Host Controller driver. Open the Driver CD (included in the package) and select Serial IO driver Locate the SetupSerialIO.exe file. Right click on the executable and select ‘Run as administrator’...
Page 31 ITWS M Series Box PC User Manual After successful installation, you should see setup completion screen. Click on ‘Finish’ button to complete the installation.
Page 32 Chapter 3: Getting Started 3.4.6 Audio Driver Follow instructions below to install Audio driver. 1. Open the Driver CD (included in the package) and select Audio driver. 2. Select Next to continue.
Page 33 ITWS M Series Box PC User Manual 3. When installation completed, select Finish complete installation.
Page 34 Chapter 3: Getting Started 3.4.7 Ethernet Driver Follow instructions below to install LAN driver. 1. Open the Driver CD (included in the package) and select LAN driver. 2. When compression is complete, select Next.
Page 35 ITWS M Series Box PC User Manual 3. Read the license agreement, and then select Next. 4. System displays the installed packages, select Next.
Page 36 Chapter 3: Getting Started 5. Confirm the installation, select Install to start the installation. 6. When installation is completed, select Finish to close the window.
Page 37 ITWS M Series Box PC User Manual 3.4.8 Watchdog Driver Installation Follow instructions below to install Watchdog driver. 1. Type “cmd” in the run box then the cmd.exe will appear in programs. 2. Right click on the cmd.exe and click on “Run as administrator” to start...
Page 38 Chapter 3: Getting Started 4. When Windows Security dialog appear, select install to continue the Installation. 5. Wait for installation to complete. When installation is complete, press any key to close. 6. Open the Driver CD (included in the package) and select Watchdog AP. 7.
Page 39 ITWS M Series Box PC User Manual 8. The installed storage location is displayed, select Next to continue. 9. Select Next to start the installation. 10. When installation is completed, select Finish to close the window.
Page 40: Chapter 4: Bios Setting
Chapter 4: BIOS Setting Chapter 4: BIOS Setting This chapter provides information on how to use BIOS setup, its functions and menu. 4.1 How and When to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, external monitor and press Del key when the prompt appears on the screen during start up.
Page 41: Bios Functions
ITWS M Series Box PC User Manual 4.2 BIOS Functions 4.2.1 Main Menu The Main menu displays the basic information about yoursystem including BIOS version, processor RC version, system language, time, and date. When you enter BIOS setup, the first menu that appears on the screen is the main menu. It contains the system information including BIOS version, processor RC version, system language, time, and date.
Page 42: Boot
Chapter 4: BIOS Setting 4.2.2 Boot BIOS Setting Description Setting Option Effect Boot Type Boot Type UEFI Boot Select boot type to Dual configuration Type type, Legacy type or UEFI type Quick Boot Quick Boot Enabled Allows InsydeH20 to skip configuration Disabled certain tests while booting.
Page 43: Serial Port Mode Settings: Rs232, Rs485, Rs422
ITWS M Series Box PC User Manual 4.2.3 Serial Port Mode Settings: RS232, RS485, RS422...
Page 44 Chapter 4: BIOS Setting...
Page 45: Chapter 5: Specifications
ITWS M Series Box PC User Manual Chapter 5: Specifications Model name ITMH100 ITMH100-6L ITMH200 Processor Intel® Tiger Lake Core™ i5-1135G7, 2.4 GHz(turbo up to 4.2GHz) 2 x SODIMM, DDR4 3200 MHz, 4GB 8GB (Optional) Memory 16GB (Optional) 32GB (Optional) 1 x M.2 2280 NVMe SSD, 128GB up to 512GB...
Page 46 1. Accessories and Integrated Options may vary depending on your configuration. The product shown in this document is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information. All specifications are subject to change without prior notice.
Page 47: Appendix
ITWS M Series Box PC User Manual Appendix Appendix A: System Dimensions ITMH100 ITMH100-6L...
Page 48 Appendix ITMH200 Appendix B: Software Developer Support You can download drivers and Software Development Kit (SDK) and Drivers from Winmate Download Center...
Page 49 ITWS M Series Box PC User Manual NOTE...
Page 51 ITWS M Series Box PC User Manual...
