- Page 1 M-Series HMI 10.4” P-cap touchscreen ® Intel Celeron™ Bay Trail-M N2930 1.83 GHz processor Multifunctional Design R10IBWS-MHT2 User Manual Version 1.2 Document Part Number: 9152111I100Q...
- Page 2 Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
- Page 3 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 4 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
- Page 5 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Toujours débrancher le cordon d’alimentation du chassis lorsque vous travaillez sur celui-ci.
- Page 6 CAUTION/ATTENTION Do not cover the openings! Ne pas couvrir les ouvertures! Before connecting the equipment to the power outlet make sure the voltage of the power source is correct. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
- Page 7 WARNING!/ AVERTISSEMENT! Always ground yourself against electrostatic damage to the device. Toujours vérifier votre mise à la terre afin que l’équipement ne se décharge pas sur vous. Cover workstations with approved anti-static material. Use a wrist strap connected to a work surface and properly grounded tools and equipment. ...
- Page 8 Important Information Countries/ Area Symbol This equipment complies with essential requirements of: Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances European Union (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
- Page 9 European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010 EN 55022: 2010 Class B o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014...
-
Page 10: About This User Manual
About This User Manual This User Manual provides information about using the Winmate® 10.4” M-Series HMI. The documentation set for the M -Series HMI provides information for specific user needs, and includes: M-Series HMI User Manual – contains detailed description on how to use the HMI, its components and features. -
Page 11: Table Of Contents
Contents Preface ............................ii About This User Manual ....................... x 1 Introduction ..........................14 1.1 Product Features ........................ 14 1.2 Hardware Specifications ....................15 1.3 Software Support ....................... 16 1.4 Packing List ......................... 17 1.5 I/O Layout .......................... 18 1.6 OSD Panel ........................... 19 1.6 Dimensions ......................... - Page 12 6.3.1 VESA Mount ......................72 6.3.2 Panel/ Flush Mount ....................73 7 Technical Support ........................75 7.1 Software Developer Support ..................... 75 7.1.1 Winmate Download Center ..................75 7.1.2 Winmate File Share ....................75 7.2 Problem Report Form ......................76 M-Series HMI...
- Page 13 Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. M-Series HMI...
-
Page 14: Introduction
Chapter 1 Introduction 1 Introduction Thank you for purchasing Winmate® M-Series HMI. M-Series HMI is designed to provide versatile and cost-effective solution for your industrial needs. P-cap multi-touch screen equipped with industrial motherboard offers various input/ output connectors. Intel ®... -
Page 15: Hardware Specifications
User Manual Chapter 1 Introduction 1.2 Hardware Specifications Model Name R10IBWS-MHT2 Display Size 10.4” Active Display Area 201.4(H) x 157.8(V) Pixel Pitch (mm) 0.0685(H) x 0.2055(V) Display Colors 16.2M Resolution 1024 x 768 Brightness 350 nits Contrast Ratio 1200:1 (typ.) -
Page 16: Software Support
Power Input 9-36V isolation DC in Power Adapter 110-240 AC to 12V DC out 80W 1.3 Software Support Winmate provides the following drivers for M-Series HMI with Intel ® Celeron Bay Trail- M N2930 processor: Item Driver Windows 7 Windows 8... -
Page 17: Packing List
User Manual Chapter 1 Introduction 1.4 Packing List Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. -
Page 18: I/O Layout
User Manual Chapter 1 Introduction 1.5 I/O Layout Description Description ① COM 3 (Optional) ⑦ HDMI output ② COM2 ⑧ LAN ③ 9-36V isolation DC in ⑨ LAN ④ COM1 ⑩ Reset Button ⑤ USB3.0 ⑪ Power Button ⑥ USB2.0 M-Series HMI... -
Page 19: Osd Panel
User Manual Chapter 1 Introduction 1.6 OSD Panel Physical Buttons Icon Button Description Reset Press to reset the system Power On/ Press to power on or power off the device LED Indicators LED Type Status Description Power is on Power is off Blinking Storage activity (Data is being read or written) System is idle... -
Page 20: Dimensions
User Manual Chapter 1 Introduction 1.6 Dimensions This section contains mechanical drawing of the HMI devices. Notice that this is a simplified drawing and some components are not marked in detail. Dimensions 10.4” Unit: mm M-Series HMI... -
Page 21: Getting Started
Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. M-Series HMI... -
Page 22: Getting Started
User Manual Chapter 2 Getting Started 2 Getting Started This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On 2.1.1 AC Adapter Components AC Adapter Power Cord Terminal Block to DC Jack... -
Page 23: Power Considerations
User Manual Chapter 2 Getting Started 2.1.2 Power Considerations HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package (Rating: Output 12V/6.6 A). Using other AC adapters may damage the device. - Page 24 User Manual Chapter 2 Getting Started Connecting to DC Power Source 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2. Plug the terminal block plug firmly to the DC IN Jack. 3.
-
Page 25: Connector Pinouts
User Manual Chapter 2 Getting Started 2.2 Connector Pinouts 2.2.1 DC-in Isolated Connector A 3pin terminal block accepts DC in 9-36V. Minimum Voltage 9V Maximum Voltage 36V Maximum Current 6.6A Voltage 2.2.2 COM Serial Port Connector The M-Series HMI uses D-SUB 9pin connector to connect serial interfaces. Pin №... -
Page 26: Usb 3.0 Connector
User Manual Chapter 2 Getting Started 2.2.4 USB 3.0 Connector M-Series HMI has two USB3.0 connectors. Use USB3.0 connector to connect external devices such as mouse or keyboard to the HMI device. Pin № Signal Name Pin № Signal Name USB_D- USB_D+ STDA_SSRX-... -
Page 27: Turning On And Off
User Manual Chapter 2 Getting Started 2.3 Turning On and Off The unit is configured to Power ON when the HMI device is connected to the power source. Press the Power button to restart the machine when the unit has been shut down. -
Page 28: Configuring Serial Port Settings
User Manual Chapter 2 Getting Started 2.4 Configuring Serial Port Settings Serial port COM1 can be configured for RS-232, RS-422 or RS-485. Jumpers are located on the motherboard. You need to open the housing in order to access the jumpers. CAUTION/ ATTENTION It is recommended to use factory jumper settings. - Page 29 Operating the Device This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. M-Series HMI...
-
Page 30: Operating The Device
M-Series HMI Chapter 3 Operating the Device 3 Operating the Device In this chapter you will find instructions on how to use multi-touch on the Windows- based HMI device. 3.1 Operating System M-series HMI support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8 Standard, and Windows Embedded Standard 7 –... -
Page 31: Adjusting The Display Brightness
M-Series HMI Chapter 3 Operating the Device Two-Finger N/A - Exposed Tap two fingers at through Gesture the same time API, used by (where the target is Application the midpoint discretion between fingers) Press and Right-click Press, wait for blue- Hold ring animation to complete, then... - Page 32 Driver Installation This chapter describes how to install all necessary drivers. M-Series HMI...
-
Page 33: Driver Installation
User Manual Chapter 4 Driver Installation 4 Driver Installation This chapter provides guideline to driver installations. 4.1 Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. M-Series HMI... - Page 34 User Manual Chapter 4 Driver Installation Step 2 Click Next to continue. Step 3 Click Yes to agree the license terms. M-Series HMI...
- Page 35 User Manual Chapter 4 Driver Installation Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation. M-Series HMI...
-
Page 36: Graphics Driver
User Manual Chapter 4 Driver Installation 4.2 Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree. -
Page 37: Audio Driver
User Manual Chapter 4 Driver Installation 4.3 Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 38: Intel Network Connections
User Manual Chapter 4 Driver Installation 4.4 Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver. -
Page 39: Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
User Manual Chapter 4 Driver Installation 4.5 Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 40: Intel Trusted Engine Interface (Intel Txe) Driver
User Manual Chapter 4 Driver Installation 4.6 Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 41: Usb 3.0 Driver (Windows 7)
User Manual Chapter 4 Driver Installation 4.7 USB 3.0 Driver (Windows 7) This HMI features Intel Celeron Bay Trail-M N2930 CPU with the Intel® USB 3.0 extensible Host Controller. You need to install the Intel® USB 3.0 extensible Host Controller driver to enable the function. NOTE: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. - Page 42 BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. M-Series HMI...
-
Page 43: Bios Setup
User Manual Chapter 5 BIOS Setup 5 BIOS Setup This chapter provides information on how to use BIOS setup, its functions and menu. 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. - Page 44 User Manual Chapter 5 BIOS Setup The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓...
-
Page 45: Main Menu
User Manual Chapter 5 BIOS Setup 5.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS... -
Page 46: Advanced Menu
User Manual Chapter 5 BIOS Setup 5.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. - Page 47 User Manual Chapter 5 BIOS Setup BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI settings Enter Opens submenu F81866 Super IO Configures IO settings Enter Opens Configuration submenu Hardware Monitor Configures Hardware Monitor Enter Opens settings submenu S5 RTC Wake Settings Configures RTC Wake Enter Opens...
- Page 48 User Manual Chapter 5 BIOS Setup 5.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
- Page 49 User Manual Chapter 5 BIOS Setup 5.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
- Page 50 User Manual Chapter 5 BIOS Setup GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 5.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. M-Series HMI...
- Page 51 User Manual Chapter 5 BIOS Setup 5.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time. Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time.
- Page 52 User Manual Chapter 5 BIOS Setup Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). M-Series HMI...
- Page 53 User Manual Chapter 5 BIOS Setup 5.2.2.5 CPU Configuration BIOS Setting Description Setting Effect Option Socket CPU This item contains socket Enter Open sub-menu Information specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Maximum Disabled/E Enable/Disable Maximum...
- Page 54 User Manual Chapter 5 BIOS Setup 5.2.2.6 PPM Configuration BIOS Setting Description Setting Effect Option CPU C State Shows CPU C State Report Enabled/ Enable or Disable CPU Report Disabled C state report to OS Max CPU C- Allows to enter power- C1E, C3, Enable or Disable CPU State...
- Page 55 User Manual Chapter 5 BIOS Setup 5.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Description Setting Option Effect Setting Critical Trip...
- Page 56 User Manual Chapter 5 BIOS Setup 5.2.2.8 IDE Configuration BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this (SATA) supporting chipset Disabled function drives with SATA interface. SATA Speed Allows forcing the speed Gen1 The maximum speed will be Support limit SATA II ports...
- Page 57 User Manual Chapter 5 BIOS Setup [RAID] Allows combining hard drives in RAID-arrays in order to improve the reliability of data storage, or to increase the speed. Serial- ATA The option turns on or Enabled/ Turn on (Enabled) or turn off Port 0 off Port 0 of SATA Disabled...
- Page 58 User Manual Chapter 5 BIOS Setup BIOS Setting Description Setting Effect Option Windows 8.X Allows user to choose the Enter Use Windows 8.X proper OS. Windows 7 Allows user to choose the Enter Use Windows 7 proper OS. IMPORTANT: The device will be shipped with OS according to your order. BIOS OS Selection menu varies accordingly.
- Page 59 User Manual Chapter 5 BIOS Setup BIOS Description Setting Effect Setting Option The Compatibility Support Module Enabled/ Enable or disable Support (CSM) is a component of the UEFI Disabled the Compatibility firmware that provides legacy BIOS Support Module compatibility by emulating a BIOS environment, allowing legacy operating systems and some option ROMs that do not support UEFI to still be used.
- Page 60 User Manual Chapter 5 BIOS Setup 5.2.2.11 USB Configuration BIOS Setting Description Setting Effect Option Legacy USB User can enable or disable Disable Will keep USB devices Support USB port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 User can enable or disable Enable...
- Page 61 User Manual Chapter 5 BIOS Setup Device Reset USB mass storage device start 10 Sec Depends on the time‐out time‐ out unit command time‐ out. 20 Sec value 30 Sec 40 Sec Device power‐ Maximum time the device Auto Uses default value: for a up delay will take before it properly root port it is 100 ms, for...
- Page 62 User Manual Chapter 5 BIOS Setup 5.2.2.13 Security Configuration BIOS Setting Description Setting Effect Option Trusted Execution Technology Enabled/D Enables or disables this parameters isabled function TXE HMRFPO TXE HMRFPO parameters Enabled/D Enables or disables this isabled function TXE Firmware TXE Firmware Update Enabled/D Enables or disables this...
-
Page 63: Chipset Menu
User Manual Chapter 5 BIOS Setup 5.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Timer Enabled/ Enables/Disable Precious settings Disabled s this function Timer Restore AC This function allows to set up... -
Page 64: Security Menu
User Manual Chapter 5 BIOS Setup 5.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has been password set. -
Page 65: Boot Configuration
User Manual Chapter 5 BIOS Setup 5.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system. - Page 66 User Manual Chapter 5 BIOS Setup BIOS Setting Description Setting Effect Option Setup Prompt Allows user to configure the Enter Set the prompt Timeout number of seconds to stay in BIOS timeout setup prompt screen. Boot NumLock Enables or disables NumLock Remains On State feature on the numeric keypad of...
-
Page 67: Save & Exit
User Manual Chapter 5 BIOS Setup 5.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied. BIOS Setting Description Setting Effect Option Save... - Page 68 User Manual Chapter 5 BIOS Setup Save Save changes done so far to any Enter Saves the changes Changes of the setup options. <YES> Enter <NO> Return to the BIOS Setup Main Menu Discard Discard changes done so far to Enter Saves the changes Changes...
-
Page 69: Using Recovery Wizard To Restore Computer
User Manual Chapter 5 BIOS Setup 5.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 70 Mounting Solutions This chapter provides step-by-step mounting guide for all available mounting options. M-Series HMI...
-
Page 71: Mounting Solutions
M-Series HMI Chapter 6 Mounting Solutions 6 Mounting Solutions This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. -
Page 72: Safety Precautions
Refer to sub-sections below for more details. 6.3.1 VESA Mount M-Series HMI comes with VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). VESA Plate Dimensions Screw Hole Diameter... -
Page 73: Panel/ Flush Mount
M-Series HMI Chapter 6 Mounting Solutions Mounting Steps: Screw VESA Bracket to the fixture (ex. wall) with M4x5 flat-head screws. Place the device on VESA bracket. NOTE: Notice that both hooks on bracket should lock the notches on the back cover of the device. - Page 74 Technical Support This chapter includes Technical Support and Software Development Kit. M-Series HMI...
-
Page 75: Technical Support
This chapter includes technical support pathway and software developing kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us. 7.1 Software Developer Support Winmate provides the following development kits (SDK) for M-Series HMI with Intel ® Celeron Bay Trail-M N2930 processor: Item File Type Description Watchdog SDK &... -
Page 76: Problem Report Form
User Manual Chapter 7 Technical Support 7.2 Problem Report Form M-Series HMI (Multifunctional design) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. - Page 77 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
