  • Page 1 CE900ENT ELLIPTICAL TRAINER OWNER’S MANUAL...
  • Page 2 Spirit Fitness...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS IMPORTANT ELECTRICAL INSTRUCTIONS PRODUCT REGISTRATION CE900ENT ASSEMBLY INSTRUCTIONS CONSOLE OPERATION TOUCH SCREEN OPERATION PROGRAMMING THE CONSOLE GENERAL MAINTENANCE MANUFACTURER’S LIMITED WARRANTY Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any customizing, adjustments, repair or maintenance that is not described in this manual.
  • Page 4 Congratulations on your new elliptical trainer and welcome to the Spirit Fitness family! Thank you for your purchase of this quality elliptical trainer from Spirit Fitness. Your new elliptical trainer was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY The hand pulse sensors are not medical devices. • Their purpose is to provide you with an approximate INSTRUCTIONS measurement in relation to your target heart rate. Use of a chest transmitter strap is a much more accurate method WARNING of heart rate analysis .
  • Page 6: Important Operation Instructions

    These distractions may cause you to lose balance which may result in serious injury. Do not use excessive pressure on console control keys. They are precision set to function properly with little • finger pressure. Spirit Fitness...
  • Page 7: Product Registration

    SERIAL NUMBER: REGISTER YOUR PURCHASE The self-addressed product registration card must be completed in full and returned to Spirit Fitness. You can also go to www.spiritfitness.com/commercialwarrantyregistration.html under the Support tab to register online. www.spiritfitness.com...
  • Page 8 CE900ENT PRE-ASSEMBLY UNPACKING TOOLS INCLUDED: 1. Cut the straps, then along the dotted line on the bottom of the box; lift the box over ‰ 17mm Wrench (2) ‰ Phillips Screwdriver the unit and unpack. ‰ 5mm Allen Wrench 2. Locate the hardware package. The hardware is separated into four steps. Remove ‰...
  • Page 9 CE900ENT STEP ONE HARDWARE FOR STEP 1 PART TYPE DESCRIPTION SELF-TAPPING SCREW 3.5x12 BOLT M10x1.5x20 10x16.5x2 LOCK WASHER WASHER 4x14x1.0 WASHER 10.2x19x1.5 1. Unwind wiring harness and run wires up through CONSOLE MAST (9). Bolt CONSOLE MAST (9) to MAIN FRAME (1) using 4 BOLTS (54), 4 LOCK WASHERS (57), and 4 WASHERS (65).
  • Page 10 CE900ENT STEP TWO HARDWARE FOR STEP 2 123 124 122 117 125 PART TYPE DESCRIPTION 5x16 SELF-TAPPING SCREW SCREW M5x12 U-NUT 1. Install 2 U-NUTS (78) to LEFT CONSOLE MAST COVER (100). 2. Attach CONSOLE MAST COVERS (100 & 101) to MAIN FRAME (1) using 2 SELF-TAPPING SCREWS (47).
  • Page 11 CE900ENT STEP THREE HARDWARE FOR STEP 3 PART TYPE DESCRIPTION M10x5.5x BOLT BOLT M10x6.0 WASHER 10x25x1.5 CURVED WASHER 10x23x1.5 M10x8 1. Install LEFT SIDE HANDLEBAR (2) to SWING ARM (12). a) First install 2 longer BOLTS (44) with a WASHER (63) on both sides of SWING ARM (12) and a NUT (71).
  • Page 12 CE900ENT STEP FOUR HARDWARE FOR STEP 4 PART TYPE DESCRIPTION SELF-TAPPING SCREW 3.5x12 SCREW M5x12 1. Attach CONSOLE BRACKET COVERS (91 & 92) to CONSOLE MAST (9) using 2 SCREWS (49). Connect covers together using 2 SELF-TAPPING SCREWS (46). 2. Attach left SWING ARM HINGE COVER (93) to SWING ARM (12) using 2 SCREWS (49).
  • Page 13: Console Operation

    CE900ENT CONSOLE OPERATION www.spiritfitness.com...
  • Page 14 Spirit Fitness...
  • Page 15 STARTING OPERATION Plug in the power cord located at the front base of the unit. When the power is turned on, the screen will show the initial image and then enter the Home screen. Home screen: Begin operation by touching the icons. Quick operating buttons are convenient for basic bike functions.
  • Page 16 The two most commonly used menus for setting up the exercise machine are described below; the TV Setup and Maintenance menus. For information on other sections of the Maintenance suite refer to the technical service manual or call Spirit service. Spirit Fitness...
  • Page 17 TV SETUP 1. Begin by selecting either TV or HDMI as the tuner source. 2. Press OSD Menu. The first highlighted item on the menu is Air/Cable and then Cable or Air afterward. Press the OSD Enter to change the selection between Cable and Air Signal source, usually Cable).
  • Page 18 Machine Setup allows you to select whether the Csafe port is • used for Csafe or CAB TV Tuner. This menu also allows you to set the screen brightness. • FTP Settings is the Spirit FTP site address where Error logs and remote troubleshooting can be managed. Spirit Fitness...
  • Page 19 INTERNET MANAGER 1. Remove a link by pressing the icon of the site you want to remove for two seconds. A pop-up window will ask you to confirm the removal. 2. To add a website press the dotted outline box. A pop-up window will ask you to enter the web address and upload a picture for the final button if you wish.
  • Page 20 Turn Wifi on and press scan for available Wifi connections. Press desired connection and follow the on-screen directions. ETHERNET SETUP Press Ethernet Configuration to set Select DHCP to search for connection up a new connection. or Static IP to enter manually Spirit Fitness...
  • Page 21 BLUETOOTH PAIRING PROCEDURE 1. Press the Blue Tooth (BT) icon on the bottom left of the screen. 2. The BT pop-up screen will appear. Turn on Phone/tablet BT and then press Pair Mode on ENT Menu. 3. The menu with show Entering Pairing mode and the phone will show A2DP as an available device.
  • Page 22: Touch Screen Operation

    When you press the Language button on Home screen, it enters the menu with all language options. There are 12 languages to choose from. Touch the desired language and the system will return to the Home screen which will now be in the chosen language. Spirit Fitness...
  • Page 23 When the TV button on the Home screen is pressed, it directly enters TV interface. Now you can enjoy TV programs. If you want to enjoy TV while exercising, press Start button at front of the treadmill to initiate Quick Start or press Programs to select a workout. You can change the TV channels by pressing the channel up/ down buttons on the right side of the screen.
  • Page 24 There are 12 programs to choose from. Press the desired program button and follow the on-screen directions. For Manual Program as an example, just touch Manual button on the screen to enter the programming for Manual. Spirit Fitness...
  • Page 25: Quick Start

    FUNCTIONS OF THIS ELLIPTICAL TRAINER The Touch-control screen is used for operating all functions of the elliptical trainer. You can directly touch any button on the screen or through quick button on the bottom to control functions. On the lower portion of the console there is the Start button to begin the workout, Stop button to pause/stop programs, Level button to change workload and a Fan button to turn the fan on or off.
  • Page 26 A muscle profile displays active muscle groups as workloads change. TRACK gives a graphical representation of your Track display position on a virtual track. The image shows the track with a lap counter and other values. Spirit Fitness...
  • Page 27 DASHBOARD The Dashboard display shows a larger display area of button information. STOP BUTTON When using the Stop button to end the program, it enters the summary screen. On the summary screen, all accumulated values concerning the workout are displayed. You can touch the Home button at left top or press Stop button to return to the home screen.
  • Page 28: Heart Rate Feature

    There is only a tiny amount of current used in sleep mode (about the same as your TV when it is turned off) and it is perfectly fine to leave the main power switch on in sleep mode. Spirit Fitness...
  • Page 29: Programming The Console

    PROGRAMMING THE CONSOLE Each of the programs can be customized with your personal information and changed to suit your needs. Some of the information asked for is necessary to ensure the readouts are correct. You will be asked for your Age and Weight. Entering your Age ensures that the Heart Rate bar graph shows the correct number. Your Age is also necessary during the Heart Rate control program to ensure the correct settings are in the program for your Age.
  • Page 30 Message Window. If you start a program without changing the settings, the default, or pre-saved settings will be used. The Spirit Fitness CE900ENT offers ten preset programs: Manual, Hills, Fat Burn, Cardio, Strength, Interval, HR, Custom, Fitness Test, and Constant Power.
  • Page 31: Fat Burn

    MANUAL The level of resistance is controlled by the user. Increase or decrease levels at any time during your workout. HILL This program follows a triangle or pyramid type of gradual progression from approximately 10% of maximum effort (the level that you chose before starting this program) up to a maximum effort which lasts for 10% of the total workout time, then a gradual regression of resistance back to approximately 10% of maximum effort.
  • Page 32 Your cardiovascular system gets programmed to use oxygen more efficiently. The default value is 65% of your projected rate maximum. You have the option of changing your target heart rate. The machine will attempt to keep you within five beats of your target heart rate. Spirit Fitness...
  • Page 33 CUSTOM You will create the desired resistance for each of the 20 segments of the program using the pop-out keyboard on this screen After the program has started, you still have the ability of changing the resistance levels whenever you desire. 1.
  • Page 34 4. Time is the total elapsed time of the test. After The Test: Cool down for about one to three minutes. ƒ Take note of your score because the console will automatically return to the start-up mode after a few minutes. ƒ Spirit Fitness...
  • Page 35 What Your Score Means: VO2MAX CHART FOR MALES AND VERY FIT FEMALES VO2MAX CHART FOR FEMALES AND DECONDITIONED MALES www.spiritfitness.com...
  • Page 36: General Maintenance

    2. The crank arm nut needs to be retightened. If squeaks or other noises persist, check that the unit is properly leveled. There are 2 leveling pads on the bottom of the rear stabilizer, use a 14mm wrench (or adjustable wrench) to adjust the levelers. Spirit Fitness...
  • Page 37: Manufacturer's Limited Warranty

    EFFECTIVE JANUARY 1, 2017 Spirit Fitness warrants this elliptical trainer for a period of time listed below from the date of sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’ responsibilities include providing new or remanufactured parts, at Spirit Fitness’...
  • Page 38 5. Products that have been: sold, transferred, bartered, or given to a third party. 6. Products that do not have a warranty registration card on file at Spirit Fitness. Spirit Fitness reserves the right to request proof of purchase if no warranty record exists for the product.
  • Page 39 Jonesboro, AR 72402-2037 Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by Spirit Manufacturing, Inc. This warranty applies only in the 48 contiguous United States. NOTE: This does not apply to Alaska or Hawaii.
  • Page 40 800.258.4555 Spirit Fitness spiritservice@spiritfitness.com 3000 Nestle Road www.spiritfitness.com Jonesboro, AR 72401 CE900ENT Owners Manual © 2017 All Rights Reserved Revision: 03.07.2017...
