Mini PCI Express USB 3.0 adapter card, RoHs
Mini PCI Express USB 3.0 adapter card, RoHs
Quick Installation Guide
Quick Installation Guide
Package Contents:
MPCIE-USB3 package includes the following items:
1 x MPCIE-USB3 mini PCI Express USB 3.0 adapter card
1 x Dual USB 3.0 type A ports cable with bracket
1 x power cable
1 x QIG (Quick Installation Guide)
MPCIE-USB3
Version 1.1
Oct. 01, 2014
USB3 mini PCI Express USB 3.0 adapter card
©2006 Copyright by IEI Integration corp.
All rights reserved.
corp.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology MPCIE-USB3
Summary of Contents for IEI Technology MPCIE-USB3
- Page 1 Oct. 01, 2014 Package Contents: MPCIE-USB3 package includes the following items: 1 x MPCIE-USB3 mini PCI Express USB 3.0 adapter card USB3 mini PCI Express USB 3.0 adapter card 1 x Dual USB 3.0 type A ports cable with bracket...
-
Page 2: Ordering Information
Operating Temperature: -10° C ~ 60° C Operating Humidity: 5% ~95%, non-condensing Diemension (LxW): 50mm x 30mm Weight: 70g Ordering Information: MPCIE-USB3-R11: Mini PCI Express USB 3.0 adapter card, RoHs 19800-010500-100-RS: Dual USB 3.0 type A ports cable with bracket... - Page 3 Jumpers setting and Connectors: LABEL FUNCTION USB 3.0 Connector Power Connector CN1 : USB3.0 Connector PIN NO. DESCRIPTION VCC1 SBD1+ USB3_RX1_DN SBD1- USB3_RX1_DP USB3_TX2_DP USB3_TX1_DN USB3_TX2_DN USB3_TX1_DP USB3_RX2_DP SBD0- USB3_RX2_DN SBD0+ VCC2 CN2 : Power Connector PIN NO. DESCRIPTION +V5S +V5S...
- Page 4 Board Layout: Jumper and Connector Locations (Unit:mm)
