Quick Start Guide

Before you start to set up the panel PC, take a moment to become familiar with the
locations and purposes of the controls, drives, connectors and ports, which are illus-
trated in the figures below.
When you place the panel PC upright on the desktop, its front panel appears as
shown in Figure 2.1.
1. I Key
2. Home Key
3. Power status indicator, off (S5): orange, on (S0): blue
PPC-4150W User Manual
Figure 2.1 Front panel
1
2
4
Figure 2.2 Side view
8
1 2 3
3
5
