Table of Contents
loading

Related Manuals for Barco MDSC-2232 DDI

Summary of Contents for Barco MDSC-2232 DDI

  • Page 1: User Guide

    MDSC-2232 User Guide 32-inch FHD surgical color display MDSC-2232 DDI MDSC-2232 MNA K5902105 (451920611791)/00 25/08/2015...
  • Page 2 Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com Printed in Italy...

  • Page 3: Table Of Contents

    2.3.1 MDSC-2232 DDI version ................
  • Page 4 Table of contents 5.1.4 Saturation ....................34 5.1.5 Color temperature ..

  • Page 5: Welcome

    1. WELCOME! About the product Overview Barco’s MDSC-2232 is a 32-inch full HD surgical display. Purpose-built for the operating room, the MDSC- 2232 offers an easy-clean design, smart mechanics and the most detailed images in the operating room today. Ease of mind Perfect hand-eye coordination: The display’s high brightness, high contrast and full HD resolution provide...

  • Page 6: About This User Guide

    1. Welcome! • MDSC-2232 user guide • User guide translations on cd-rom • DVI cable • AC power cords • external power supply • 4 screws, 4 dented washers and an Allen key Keep your original packaging. It is designed for this display and is the ideal protection during transport.

  • Page 7: Parts, Controls And Connectors

    2. Parts, controls and connectors 2. PARTS, CONTROLS AND CONNECTORS Front view Overview Image 2-1 1. Input Selection key 2. Multi-image selection key / Down key 3. Image zoom key / Up key 4. OSD Menu key / Enter key 5.

  • Page 8: Rear View

    1. VESA mount screw holes (100 x 100 mm, 200 x 100 mm) 2. Cable routing channel 3. Cable routing channel expansion clip 4. Connector compartment cover Connector view 2.3.1 MDSC-2232 DDI version Overview 18 19 Image 2-3 1. DVI-2 in 2. Potential Equalization pin (POAG) 3.

  • Page 9: Mdsc-2232 Mna Version

    2. Parts, controls and connectors 12. Input power 13. DVI out 14. DVI-1 in 15. DisplayPort (VESA std 1.1a) 16. R/Pr 17. G/Y 18. B/Pb 19. S-Video in 20. Service 2.3.2 MDSC-2232 MNA version Overview 14 15 21 22 Image 2-4 1.

  • Page 10: Protective Earth Pin

    2. Parts, controls and connectors 23. Service (*) Nexxis OR functionality: for more detailed information on Barco’s Nexxis integrated OR solution please refer to the dedicated user guides. Please visit my.barco.com to obtain these user guides. (**) SDI is not always present in combination with Nexxis input.

  • Page 11: Dvi-1 Connector (Dvi-I)

    2. Parts, controls and connectors 2.5.2 DVI-1 connector (DVI-I) Overview Image 2-7 1. D2_Rx- (T.M.D.S.) 2. D2_Rx+ (T.M.D.S.) 3. GND (data 2 shield) 4. Not connected 5. Not connected 6. SCL (for DDC) 7. SDA (for DDC) 8. Analog vertical sync 9.

  • Page 12: Dvi-2 Connector (Dvi-D)

    2. Parts, controls and connectors 2.5.3 DVI-2 connector (DVI-D) Overview Image 2-8 1. D2_Rx- (T.M.D.S.) 2. D2_Rx+ (T.M.D.S.) 3. GND (data 2 shield) 4. Not connected 5. Not connected 6. SCL (for DDC) 7. SDA (for DDC) 8. Not connected 9.

  • Page 13: Rs232 Connector

    2. Parts, controls and connectors 1. D2_Rx- (T.M.D.S.) 2. D2_Rx+ (T.M.D.S.) 3. GND (data 2 shield) 4. Not connected 5. Not connected 6. SCL (for DDC) 7. SDA (for DDC) 8. Not connected 9. D1_Rx- (T.M.D.S.) 10. D1_Rx+ (T.M.D.S.) 11. GND (data 1 shield) 12.

  • Page 14: Mini Usb Connector

    2. Parts, controls and connectors 1. +5 VDC 2. Data - 3. Data + 4. GND 2.5.7 Mini USB connector Overview Image 2-12 1. +5 VDC 2. Data - 3. Data + 4. Not connected 5. GND 2.5.8 DisplayPort connector Overview 19 17 15 13 11 9 20 18 16 14 12 10 8...

  • Page 15: S-Video And S-Video-Out Connector

    2. Parts, controls and connectors 2.5.9 S-Video and S-Video-out connector Overview Image 2-14 1. Ground (Y) 2. Ground (C) 3. Luminance (Y) 4. Chroma (C) 5. SG: Shielded Ground K5902105 (451920611791) MDSC-2232 25/08/2015...
  • Page 16 2. Parts, controls and connectors K5902105 (451920611791) MDSC-2232 25/08/2015...

  • Page 17: Display Installation

    ... This chapter describes how to connect the different video interface types to the MDSC-2232. 3.2.1 MDSC-2232 DDI version To connect the interfaces 1. Connect one or more video source(s) to the corresponding video inputs of the display. K5902105 (451920611791) MDSC-2232 25/08/2015...
  • Page 18 3. Display installation - DVI or VGA: and/or PC analog (VGA) input source can be connected to the DVI-I input connector using a DVI-I to VGA adapter. The use of an adapter cable of at least 0.15 m long will allow an easy placement inside the cable cover.

  • Page 19: Mdsc-2232 Mna Version

    3. Display installation To maintain compliance with EMC regulation, use only shielded interface ARNING cables for the connection to peripheral devices. 3.2.2 MDSC-2232 MNA version To connect the interfaces 1. Connect one or more video source(s) to the corresponding video inputs of the display. - Nexxis: - DVI or VGA: PC analog (VGA) input source can be connected to the DVI-I input connector using a DVI-I to VGA...

  • Page 20: Nexxis Or

    IP network, in raw uncompressed format, inside the operating room and even between surgical suites. To connect your MDSC-2232 to Barco’s Nexxis OR system, connect the 10Gb Ethernet interface to your Nexxis switch. More info about Nexxis OR and how to configure the MDSC-2232 in your network is avail- able in the dedicated user guides.

  • Page 21: Cable Routing

    3. Display installation Image 3-6 Potential equalization When potential equalization between the display and other devices is required then connect the potential equalization pin (POAG) to the potential equalization terminal of the equipment. Image 3-7 Protective earth Earth the MDSC-2232 by connecting the protective earth pin to a grounded outlet by means of an AWG18 wire (maximum admitted cable length according to national regulation requirements).

  • Page 22: Vesa Mount Installation

    3. Display installation Image 3-9 For displays to be mounted on a VESA arm or stand without internal cable routing provisions, first remove the expansion clip from the connector compartment cover, then route all cables through it while reinstalling the cover. Image 3-10 ARNING When the display is assembled in the medical system, take care of the fixa-...
  • Page 23 3. Display installation Image 3-11 The 4 screws included (M4 x 20 mm) can be used for a VESA arm interface AUTION with a thickness of up to 10 mm. If, due to the thickness of the VESA arm interface (=V), the length of the provided screws (=L) is not suitable, consider the following rule: L = V + 15 mm Use an arm that is in compliance with VESA requirements.
  • Page 24 3. Display installation K5902105 (451920611791) MDSC-2232 25/08/2015...

  • Page 25: Daily Operation

    4. Daily operation 4. DAILY OPERATION On/Off switching To switch on your display: 1. Activate the power supply through the switch located on the external power supply. 2. While your display is off, press and hold (approximately 3-4 seconds) the stand-by key until the key- board backlight starts blinking.

  • Page 26: Power Mode Led

    4. Daily operation As a result, the keys will light up and are now available for further actions. However, if no further actions are taken within the following 10 seconds, the keys will dim and the keyboard will be locked again. 2.

  • Page 27: Osd Menu Navigation

    4. Daily operation OSD menu navigation OSD menu structure explained Below is an example of the OSD menu structure: Picture Profile Factory Brightness Contrast Saturation Color temperature 6500K Gamma Native Sharpness DVI 1280x800@60Hz Image 4-2 Menu Sub-menu Status bar Legend (shows the functionality associated to each keyboard key) Selector/Slider Item To navigate through the OSD menu...

  • Page 28: Main Source Selection

    4. Daily operation The different available shortkey functions are: • Main source selection • Multi-image configuration • Zoom factor selection • Brightness adjustment Unlike the extended keyboard functions (described in next chapter), the shortkey func- tionality is immediately available without the need to first enable this in the OSD menu. When the extended keyboard functionality is enabled, all the shortkey functions de- scribed below (except for the brightness adjustment), will no longer be available and will be replaced by the corresponding extended keyboard functions described in the...

  • Page 29: Zoom Factor Selection

    4. Daily operation Only a subset of multi-image configuration settings is available via this shortkey func- tion. More multi-image configuration settings can be selected in the OSD menus. When the extended keyboard functionality is enabled, this shortkey functions will no longer be available and will be replaced by the corresponding extended keyboard func- tions described in the next chapter.

  • Page 30: Main Source Selection

    4. Daily operation • Main source selection • Second source selection • Multi-image configuration • Color temperature selection • Image size selection • Zoom factor selection Unlike the shortkey functions (described before), the extended keyboard functionality must be first enabled in the OSD menu before you can make use of it. Please refer to the dedicated section in this manual for more details on how to enable/disable the extended keyboard functions.

  • Page 31: Second Source Selection

    4. Daily operation Main source R G B S-Video Y Pb Pr CVBS Nexxis 2nd Source Image 4-7 4.7.2 Second source selection To quickly select the second source 1. While no OSD Menu is on the screen, press the Input selection key ( ) to bring up the main source quick selection menu.

  • Page 32: Common Functions: Transfer Function Selection

    4. Daily operation 4.7.4 Common Functions: Transfer function selection To quickly select the transfer function 1. While no OSD Menu is on the screen, press the Image zoom key ( ) to bring up the common functions quick selection menu. 2.

  • Page 33: Menu Locking/Unlocking

    4. Daily operation Common Functions ITU 709 6500°K DICOM Native Aspect Zoom Image 4-12 Menu locking/unlocking To lock/unlock the menu The keyboard can be locked from the Menu to avoid unwanted access to OSD functions. When the key- board is LOCKED only the OSD Menu key ( ) and the Stand-by key ( ) are active. When the Menu OSD key is pressed the Menu Locked window appears.
  • Page 34 4. Daily operation K5902105 (451920611791) MDSC-2232 25/08/2015...

  • Page 35: Advanced Operation

    5. Advanced operation 5. ADVANCED OPERATION OSD picture menu Overview • Profile • Brightness • Contrast • Saturation • Color temperature • Gamma • Sharpness 5.1.1 Profile About profiles To select a profile means to load a set of predefined video parameters like Brightness, Contrast, Satura- tion, Input selection (Primary &...

  • Page 36: Contrast

    5. Advanced operation The selected brightness is maintained at a constant level by the automatic backlight stabilization function. The brightness level can also be adjusted through a shortkey function. Brightness level is adjusted by controlling the backlight illumination only. 5.1.3 Contrast To adjust the contrast level 1.

  • Page 37: Gamma

    5. Advanced operation Factory calibration – White point: The White Color points associated with the Color Temperature: 5600K, 6500K, 7600K or 9300K are factory calibrated with a consequent reduction of the maximum luminance compared to Native Color Temperature. Factory calibration – Color space: When ITU 709 is selected, the White Color point and the RGB color primaries are ad- justed according to the target HDTV / sRGB color space defined in the ITU-709 recom- mendation.

  • Page 38: Picture Advanced Menu

    5. Advanced operation 3. Enter the Sharpness submenu. The command bar Sharpness is highlighted. 4. Set the sharpness level as desired and confirm. Picture Advanced menu Overview • Black Level • Smart Video • Image Position • Auto Adjustment • Phase •...

  • Page 39: Image Position

    5. Advanced operation 3. Enter the Smart Video submenu. 4. Select one of the available Smart Video presets and confirm. 5.2.3 Image Position This menu item is only available when VGA input is connected. To adjust the image position 1. Bring up the OSD main menu. 2.

  • Page 40: Clock/Line

    5. Advanced operation 3. Enter the Phase submenu. The command bar Phase is highlighted. 4. Set the phase as desired and confirm. 5.2.6 Clock/Line This menu item is only available when VGA input is connected. About clock/line If the result of the Auto Adjustment procedure described above isn’t satisfactory, the Clock/Line can be manually adjusted by following this procedure.

  • Page 41: Component Mode

    5. Advanced operation • Auto Search • Composite • S-Video • Component • PC Analog • DVI 1 • DVI 2 • SDI 1 • SDI 2 • Nexxis • DisplayPort Available main sources dependent on display model. The main source can also be selected through a shortkey function or via the extended keyboard functionality.

  • Page 42: Image Size

    5. Advanced operation • None • • • • • The zoom factor can also be selected through a shortkey function or via the extended keyboard functionality. To select a zoom factor 1. Bring up the OSD main menu. 2. Navigate to the Display Format menu. 3.

  • Page 43: Nd Picture Source

    5. Advanced operation • • Small PiP: 30% of Primary height in top-right corner • Large PiP: 50% of Primary height in top-right corner • Side-by-Side: Primary and Secondary input of equal height • S.b.S. Native: The 2 images are displayed with input pixel to LCD pixel mapping, with image crop if necessary •...

  • Page 44: Nd Picture Position

    5. Advanced operation Independent Transfer Function: Gamma and Color temperature for the 2nd Picture Souce are always set to Native and 6500K independently from the Transfer Function applied to the Main Picture Source. For a perfect visualization of a DICOM image please select the DICOM input signal as Main picture and, if needed, the Video image as 2nd picture.

  • Page 45: Configuration Menu

    5. Advanced operation Configuration menu Overview • Information • Language • Failover mode • Extended keyboard • OSD setting • Recall Profile • Save Profile 5.4.1 Information About information The available information items for your display are: • Model (commercial type identification) •...

  • Page 46: Failover Mode

    5. Advanced operation 5.4.3 Failover mode About failover mode This function allows the automatic switch to a defined Backup source when the Main input signal is miss- ing. The display will automatically restore the Main input as soon as the signal is back. The Backup source is the input selected as “2nd Picture Source”...

  • Page 47: Osd Setting

    5. Advanced operation 2. Navigate to the Configuration menu. 3. Enter the Extended keyboard submenu. 4. Enable/Disable the extended keyboard as desired and confirm. 5.4.5 OSD setting 5.4.5.1 OSD Horizontal Position To adjust the OSD horizontal position 1. Bring up the OSD main menu. 2.

  • Page 48: Recall Profile

    5. Advanced operation 5.4.6 Recall Profile About recalling profiles To recall a profile means to restore the default factory settings (Factory and X Ray profiles) or recall the user defined profiles. The available profiles to recall from your display are: •...

  • Page 49: Power On Dvi 1

    5. Advanced operation 5.5.1 Power on DVI 1 About power on DVI 1 This setting allows you to select the pin of DVI port 1 connector on which the +5V DC supply is applied. The available options are: • Disabled •...
  • Page 50 5. Advanced operation MDSC-2232 DDI version Main picture 2nd picture DVI Output option “DVI 1” “DVI 2” “None” DVI 1 DVI 1 DVI 2 SDI 1 SDI 2 Other DVI 2 DVI 1 DVI 2 SDI 1 SDI 2 Other...

  • Page 51: Keyboard Lock

    5. Advanced operation 3. Enter the DVI output submenu. 4. Select one of the available options and confirm. 5.5.4 Keyboard lock About keyboard locking This setting allows you to disable the keyboard functionality and avoid unwanted access to the OSD func- tions.
  • Page 52 5. Advanced operation K5902105 (451920611791) MDSC-2232 25/08/2015...

  • Page 53: Important Information

    6. Important information 6. IMPORTANT INFORMATION Safety information General recommendations Read the safety and operating instructions before operating the device. Retain safety and operating instructions for future reference. Adhere to all warnings on the device and in the operating instructions manual. Follow all instructions for operation and use.
  • Page 54 6. Important information Power connection – Equipment with external 24 VDC power supply • Power requirements: The equipment must be powered using the delivered medical approved 24 VDC ) SELV power supply. • The medical approved DC ( ) power supply must be powered by the AC mains voltage. •...

  • Page 55: Technical Data

    EMC: • IEC / EN 60601-1-2: 2007 • EN 55011 / CISPR11 (MDSC-2232 MNA: Class A, MDSC-2232 DDI: Class B) National Scandinavian Deviations for CL. 1.7.2: Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan" Norway: "Apparatet må tilkoples jordet stikkontakt" Sweden: "Apparaten skall anslutas till jordat uttag"...

  • Page 56: Environmental Information

    (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section "Limit Requirements of toxic substances in Electronic Information Products".

  • Page 57: Biological Hazard And Returns

    “Electronic Information Products Pollution Control Labeling Standard” of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period”...

  • Page 58: Regulatory Compliance Information

    PACS, anesthesiology and patient information. It is not in- tended for diagnosis. FCC Class B (valid for MDSC-2232 DDI version) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference re- ceived, including interference that may cause undesired operation.

  • Page 59: Cleaning And Disinfection

    6. Important information Cleaning and disinfection Instructions • Be sure to unplug the power cord from the mains when cleaning your LCD monitor. • Take care not to scratch the front surface with any hard or abrasive material. • Dust, finger marks, grease etc. can be removed with a soft damp cloth (a small amount of mild deter- gent can be used on the damp cloth).
  • Page 60 6. Important information Indicates the device is approved according to the VCCI regulations Indicates the device is approved according to the KC regulations Indicates the device is approved according to the BSMI regulations Indicates the device is approved according to the PSE regulations Indicates the USB connectors on the device Indicates the DisplayPort connectors on the device Indicates the legal manufacturer...

  • Page 61: Legal Disclaimer

    Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
  • Page 62 Anti-reflective tempered glass Keyboard Capacitive 7-key touch keyboard (with enable/disable switch) Video input signals DVI-I Single Link (Digital & Analog – HDMI video support with HDCP) (MDSC-2232 DDI) DVI-D Component Video RGBS / YPbPr (4xBNC) S-video (4-pin Mini DIN) Composite video (1xBNC) 3G-SDI (2xBNC) DisplayPort (VESA std 1.1a)
  • Page 63 100-240VAC, 50/60Hz (Medical Power supply, Class I, 2MOPP between for external power supply primary and secondary) Power source requirements +24 VDC ±10% / 2.2 A (MDSC-2232 DDI) for display power input +24 VDC ±10% / 3 A (MDSC-2232 MNA) Power supply DC output cable 2.0 m (6.6 ft)
  • Page 64 Note PSE is available on PSU • Electromagnetic Compatibility: EMC Medical EMC Standards: IEC60601-1-2, EN55011/CISPR 11 (MDSC-2232 MNA: Class A, MDSC-2232 DDI: Class B), FCC CFR47 part 15 & 18 (MDSC-2232 MNA: Class A, MDSC-2232 DDI: Class B) • RoHS-2, REACH, WEEE compliant •...
  • Page 65 6. Important information Item Name Pixel x Line Format Hor. Fr. Vert. Fr. Hor. Vert. (kHz) (Hz) Total Total DMT0872 800 x 600 48,08 72,19 SVGA DMT0875 800 x 600 SVGA 46,875 DMT0885 800 x 600 SVGA 53,74 85,061 DMT1060 1027 x 768 48,4 DMT1070...
  • Page 66 6. Important information Item Name Pixel x Line Format Hor. Fr. Vert. Fr. Hor. Vert. RGBS / (kHz) (Hz) Total Total YPbPr 1080p30 1920 x 1080 1080p 33,75 1080p50 1920 x 1080 1080p 56,25 1080p59 1920 x 1080 1080p 67,433 59,94 1080p60 1920 x 1080 1080p...

  • Page 67: Open Source License Information

    A list of the Open Source Software components used is available in the applicable EULA, through the “My Barco” section of the Barco website or through other (online) means. Copyright on each Open Source Software component belongs to the respective initial copyright holder, each additional contributor and/or their respective assignee(s), as may be identified in the respective Open...
  • Page 68 Barco whatsoever. You further acknowledge that any such additions, changes or modifications may impair the ability of Barco – at Barco’s sole discretion - to continue to provide ser- vice, warranties, software updates, fixes, maintenance, access or such similar abilities, without any recourse or claim towards Barco whatsoever.

This manual is also suitable for:

Mdsc-2232 mna
