- Page 1 MDSC-2242 User Guide ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
-
Page 3: Table Of Contents
About this user guide ..................................8 2 Parts, controls and connectors................................9 Front view......................................10 Rear view....................................... 11 Remote control....................................11 Connector view ....................................12 2.4.1 MDSC-2242 LED version............................12 2.4.2 MDSC-2242 MNA version............................13 Connector pin assignments ................................14 2.5.1 DVI-1 connector (DVI-I)..............................14 2.5.2 DVI out connector (DVI-D)............................15 2.5.3... - Page 4 Power on DVI 1 ................................45 5.5.2 DVI Output ..................................45 5.5.3 Keyboard lock ..................................45 5.5.4 Power Saving ...................................46 6 Important information....................................47 Safety information.....................................48 Environmental information................................50 Biological hazard and returns ..............................52 Regulatory compliance information ............................53 Cleaning and disinfection ................................53 Explanation of symbols..................................54 K5903030 (451920611336) /05 MDSC-2242...
- Page 5 Legal disclaimer....................................56 Technical specifications.................................57 Open source license information .............................61 K5903030 (451920611336) /05 MDSC-2242...
- Page 6 K5903030 (451920611336) /05 MDSC-2242...
-
Page 7: Welcome
Welcome! K5903030 (451920611336) /05 MDSC-2242... -
Page 8: About The Product
1.3 About this user guide Overview This manual provides support to the user during the installation, set up and utilization of the MDSC-2242 display. Depending on the specific version that has been purchased, some of the features and options described in this document may not apply to the display in user’s hands. -
Page 9: Parts, Controls And Connectors
Parts, controls and connectors K5903030 (451920611336) /05 MDSC-2242... -
Page 10: Front View
A 7-key keypad is located on the right side of the display. Input Selection key Multi-image selection key / Down key Image zoom key / Up key OSD Menu key / Enter key Brightness decrease / Left key Brightness increase / Right key Stand-by key K5903030 (451920611336) /05 MDSC-2242... -
Page 11: Rear View
Parts, controls and connectors 2.2 Rear view Overview Image 2-2 VESA mount screw holes Connector location 2.3 Remote control Overview Image 2-3 Standby (On/Off) K5903030 (451920611336) /05 MDSC-2242... -
Page 12: Connector View
Left Down Right Ok (Select) Input Selection Brightness + Back PiP Swap Brightness - 2.4 Connector view 2.4.1 MDSC-2242 LED version Overview Image 2-4 Mains input Earth SDI-1 out SDI-1 in DVI out DVI-1 in Display Port in Potential Equalization pin (POAG: DIN 42801) -
Page 13: Mdsc-2242 Mna Version
Parts, controls and connectors 2.4.2 MDSC-2242 MNA version Overview Image 2-5 Mains Input Earth Optical 10Gb Ethernet SFP+ interface* LED2* • Orange blinking: Activity = (Tx) or (Rx) • Off: No network activity LED1* • Green: Link is active •... -
Page 14: Connector Pin Assignments
PC analog (VGA) input source can be connected to the DVI-I input connector using a DVI-I to VGA adapter. The use of an adapter cable of at least 0.15 m long will allow an easy placement inside the cable cover. K5903030 (451920611336) /05 MDSC-2242... -
Page 15: Dvi Out Connector (Dvi-D)
(*) +5 VDC output always available. (+5V ± 10% @ 500mA (max)) 2.5.3 RS232 connector Overview Image 2-8 Not connected Rx (driven by host) Tx (driven by display) Not connected Ground Not connected Not connected Not connected Not connected K5903030 (451920611336) /05 MDSC-2242... -
Page 16: Usb Type A Connector
ML_Lane 1 (p) ML_Lane 0 (n) ML_Lane 0 (p) CONFIG1 CONFIG2 AUX CH (p) AUX CH (n) Hot Plug Return DP_PWR (+3.3 VDC @ 500 mA max) 2.5.6 S-Video and S-Video-out connector Overview Image 2-11 Ground (Y) K5903030 (451920611336) /05 MDSC-2242... - Page 17 Parts, controls and connectors Ground (C) Luminance (Y) Chroma (C) SG: Shielded Ground K5903030 (451920611336) /05 MDSC-2242...
- Page 18 Parts, controls and connectors K5903030 (451920611336) /05 MDSC-2242...
-
Page 19: Display Installation
Display installation K5903030 (451920611336) /05 MDSC-2242... -
Page 20: Vesa Mount Installation
WARNING: The IP protection rating of the display is guaranteed only if the 12 VESA holes are closed (e.g. using the screws provided with the display). 3.2 Video input connection WARNING: When the display is assembled in the medical system, take care of the fixation of all cables, to avoid unwanted detachment. K5903030 (451920611336) /05 MDSC-2242... -
Page 21: Mdsc-2242 Led Version
Please refer to the dedicated chapter for more info on how to activate and use the PiP and SbS features on your MDSC-2242. This chapter describes how to connect the different video input types for each version of the MDSC-2242. -
Page 22: Video Output Connection
About video output connections Beside the video input connections, the MDSC-2242 also has video output capabilities allowing you to loop- through certain video inputs connected with the MDSC-2242 to another display, projector, video recorder, ... -
Page 23: Mdsc-2242 Mna Version
S-Video 3.4 Nexxis OR Overview Connecting your MDSC-2242 to Barco's Nexxis OR system allows you to distribute video, graphics, audio and computer data over the IP network, in raw uncompressed format, inside the operating room and even between surgical suites. -
Page 24: Power Supply Connection
To connect your MDSC-2242 to Barco's Nexxis OR system, connect the 10Gb Ethernet interface to your Nexxis switch. More info about Nexxis OR and how to configure the MDSC-2242 in your network is available in the dedicated user guides. Please visit www.barco.com... -
Page 25: Mdsc-2242 Mna Version
Display installation 3.6.2 MDSC-2242 MNA version To connect the potential equalization pin Connect the potential equalization pin (POAG: DIN 42801) to the potential equalization terminal of the equipment. Image 3-8 K5903030 (451920611336) /05 MDSC-2242... - Page 26 Display installation K5903030 (451920611336) /05 MDSC-2242...
-
Page 27: Daily Operation
Daily operation K5903030 (451920611336) /05 MDSC-2242... -
Page 28: On/Off Switching
The OSD menu position can be adjusted in the OSD menu (OSD Hor. Pos. and OSD Vert. Pos.). 4.4 OSD menu navigation OSD menu structure explained Below is on example of how the OSD menu structure looks like: K5903030 (451920611336) /05 MDSC-2242... -
Page 29: Shortkey Functions
The concept of shortkey functions is to present a selection of commonly used functions immediately available without the need to navigate through the OSD Menu. The different available shortkey functions are: • Main source selection • Multi-image configuration • Zoom factor selection • Brightness adjustment K5903030 (451920611336) /05 MDSC-2242... -
Page 30: Main Source Selection
Use the Image zoom key ( ) to select one of the available zoom factors. 4.5.4 Brightness adjustment To quickly adjust the brightness While no OSD Menu is on the screen, press the Brightness decrease ( ) or Brightness increase ( ) keys to adjust the brightness as desired. K5903030 (451920611336) /05 MDSC-2242... -
Page 31: Keyboard Locking/Unlocking
The Barco remote control operates on an infrared (IR)-based transmitter. If it has an unobstructed line-of-sight to the receiver, the Barco remote control can function at distances of up to 30 feet (about 9 meters). The remote control duplicates the functions of the keyboard. - Page 32 Battery replacement should be done as depicted on the back side of the remote control. Use a Lithium Battery CR2032 3V type. CAUTION: Replace with the correct battery type, there is risk of explosion if the battery is replaced with an incorrect type. K5903030 (451920611336) /05 MDSC-2242...
-
Page 33: Advanced Operation
Advanced operation K5903030 (451920611336) /05 MDSC-2242... -
Page 34: Osd Picture Menu
Enter the Brightness submenu. The command bar Brightness is highlighted. Set the brightness level as desired and confirm. The brightness level can also be adjusted through a shortkey function. Brightness level is adjusted by controlling the backlight illumination only. K5903030 (451920611336) /05 MDSC-2242... -
Page 35: Contrast
Only in case the User preset has been selected it is possible to get access to the color regulation commands described hereafter. To select a color temperature preset Bring up the OSD main menu. Navigate to the Picture menu. Enter the Color Temperature submenu. Select one of the available color temperature presets and confirm. K5903030 (451920611336) /05 MDSC-2242... -
Page 36: Gamma
This command allows to add or subtract an offset to the input video signal (available only on video formats). To adjust the black level Bring up the OSD main menu. Navigate to the Picture advanced menu. K5903030 (451920611336) /05 MDSC-2242... -
Page 37: Smart Video
OSD menu. 5.2.4 Auto Adjustment This menu item is only available when VGA input is connected. About auto adjustment When auto adjustment is activated, the phase and clock per line parameters are automatically adjusted. K5903030 (451920611336) /05 MDSC-2242... -
Page 38: Phase
Enter the Clock/Line submenu. The command bar Clock/Line is highlighted. Set the clock/line as desired and confirm. 5.3 Display Format menu Overview • Main Source (Primary Source) • Component Mode • Zoom • Image Size • Picture Mode K5903030 (451920611336) /05 MDSC-2242... -
Page 39: Main Source (Primary Source)
The available component modes for your display are: • YPbPr • To select the component mode Bring up the OSD main menu. Navigate to the Display Format menu. Enter the Component Mode submenu. Select one of the available component modes and confirm. K5903030 (451920611336) /05 MDSC-2242... -
Page 40: Zoom
S.b.S. Native: The 2 images are displayed with input pixel to LCD pixel mapping, with image crop if necessary • S.b.S. Fill: Both images scaled to fill half of the screen, with image crop if necessary K5903030 (451920611336) /05 MDSC-2242... -
Page 41: Nd Picture Source
Bottom Left To select the 2 picture position Bring up the OSD main menu. Navigate to the Display Format menu. Enter the 2 Picture Position submenu. Select one of the available 2 picture positions and confirm. K5903030 (451920611336) /05 MDSC-2242... -
Page 42: Configuration Menu
Navigate to the Configuration menu. Enter the Information submenu. The different information items are shown. 5.4.2 Language About languages The available languages for your display OSD menu are: • English • Français • Deutsch • Español • Italiano K5903030 (451920611336) /05 MDSC-2242... -
Page 43: Failover Mode
Bring up the OSD main menu. Navigate to the Configuration menu. Enter the OSD setting submenu. Select OSD Ver. Pos. The command bar OSD Ver. Pos. is highlighted. Set the OSD vertical position as desired and confirm. K5903030 (451920611336) /05 MDSC-2242... -
Page 44: Osd Time-Out
The available profiles to save in your display are: • User 1 • User 2 • User 3 To save a profile Bring up the OSD main menu. Navigate to the Configuration menu. K5903030 (451920611336) /05 MDSC-2242... -
Page 45: System Menu
Enter the DVI output submenu. Select one of the available options and confirm. 5.5.3 Keyboard lock About keyboard locking This setting allows you to disable the keyboard functionality and avoid unwanted access to the OSD functions. K5903030 (451920611336) /05 MDSC-2242... -
Page 46: Power Saving
2. By activating the OSD menu, see “OSD menu activation”, page 28. To enable/disable power saving Bring up the OSD main menu. Navigate to the System menu. Enter the Power Saving submenu. Enable/Disable power saving as desired and confirm. K5903030 (451920611336) /05 MDSC-2242... -
Page 47: Important Information
Important information K5903030 (451920611336) /05 MDSC-2242... -
Page 48: Safety Information
• Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. K5903030 (451920611336) /05 MDSC-2242... - Page 49 Sufficient expertise is required for installing this equipment, especially to determine the strength of the wall for withstanding the display's weight. Be sure to entrust the attachment of this equipment to the wall to licensed contractors of Barco and pay adequate attention to safety during the installation and usage. •...
-
Page 50: Environmental Information
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/AboutBarco/weee K5903030 (451920611336) /05... - Page 51 (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco's product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section "Limit Requirements of toxic substances in Electronic Information Products".
-
Page 52: Biological Hazard And Returns
“Electronic Information Products Pollution Control Labeling Standard” of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period”... -
Page 53: Regulatory Compliance Information
The manufacturing country of the product is indicated on the product label (“Made in …”). Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC Class B This device complies with Part 15 of the FCC Rules. -
Page 54: Explanation Of Symbols
Caution: Federal law (United Stated of America) restricts this device to sale by or on the order of a licensed healthcare practitioner. IS 13252 (Part 1) Indicates the device is approved according to the BIS regulations IEC 60950-1 R-xxxxxxxx www.bis.gov.in Indicates the USB connectors on the device K5903030 (451920611336) /05 MDSC-2242... - Page 55 Stand-by Equipotentiality Protective earth (ground) Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): Values for xx and yy can be found in the technical specifications paragraph. K5903030 (451920611336) /05 MDSC-2242...
- Page 56 Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
- Page 57 DVI-I Single Link (digital & analog – HDMI video support with HDCP) version) DisplayPort (VESA std 1.1a) S-video (4-pin Mini DIN) Composite video (1x BNC) Component video RGBS / YPbPr (4x BNC) Barco NEXXIS network adapter integrated Video output signals (MNA DVI-D version) Composite video (1x BNC) S-video (4-pin Mini DIN)
- Page 58 -20 - +60°C Operating humidity 10 - 90% (non-condensing) Storage humidity 5 - 90% (non-condensing) Operating altitude 3000m max. Storage altitude 12000m max. Green requirements ROHS-2, REACH, WEEE compliant Protection level IP21 / Front face: IPx5 K5903030 (451920611336) /05 MDSC-2242...
- Page 59 SXGA+ 65,32 59,98 (VESA) CVR1660D 1680 x 1050 WSXGA+1 64,67 59,88 CVT1660D 1680 x 1050 WSXGA+2 65,29 59,95 1920 x 1200 WUXGA1 74,038 59,95 640 x 350 31,5 (Diag. mode) OSD Smart Video set to “Diagnostic” K5903030 (451920611336) /05 MDSC-2242...
- Page 60 1920 x 1080 1080p 67,433 59,94 1080p60 1920 x 1080 1080p 67,5 SDI Standard Compliance: SMPTE 425M (level A), SMPTE 424M, SMPTE 292M, SMPTE 296M, ITU-R BT.656, ITU-R BT.601 SDI Video Sampling: Y Cb Cr 4:2:2 K5903030 (451920611336) /05 MDSC-2242...
- Page 61 A list of the Open Source Software components used is available in the applicable EULA, through the “My Barco” section of the Barco website or through other (online) means. Copyright on each Open Source Software component belongs to the respective initial copyright holder, each additional contributor and/or their respective assignee(s), as may be identified in the respective Open Source Software documentation, source code, README file, or otherwise.
- Page 62 Barco whatsoever. You further acknowledge that any such additions, changes or modifications may impair the ability of Barco – at Barco’s sole discretion - to continue to provide service, warranties, software updates, fixes, maintenance, access or such similar abilities, without any recourse or claim towards Barco whatsoever.
- Page 63 Important information K5903030 (451920611336) /05 MDSC-2242...
- Page 64 Barco NV President Kennedypark 35 8500 Kortrijk Belgium K5903030 (451920611336) /05 | 2019-06-07 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...
