REPLACEMENT GUIDE

Switch off the unit fi rst before removing the cap.
1
2
3
4
5
IG-CM1A.EN.indd 12 IG-CM1A.EN.indd 12
Remove the cap cover
Be sure to remove.
The cap cover may be damaged.
Remove the cap
Squeeze from side (1), then pull away
to direction (2) to remove the cap.
It may be a little hard at fi rst.
Remove the front panel
Push downwards as indicated by arraw
and lift the front panel.
It may be a little hard at fi rst.
Replace with a new
P l a s m a c l u s t e r I o n
Generating Unit or
rechargeable battery
Attach the cap and front panel
Ensure the direction of the cap is correct.
Cap Cover
Cap
Front Panel
Remove Plasmacluster Ion Generating Unit
Rechargeable
Battery
E-10
Squeeze
Attach
