7. 7. 7. 7. D5 pump motor with USB and aquabus interface

D5 pump motor with USB and aquabus interface D5 pump motor with USB and aquabus interface D5 pump motor with USB and aquabus interface

7.1. Description

7.1. Description
7.1. Description 7.1. Description
The D5 pump motor is a efficient pump motor and has to be combined with a
suitable body to form a pump. The electronically commutated motor with a spheri-
cal ceramic bearing features smooth rotation and high mechanical endurance.
The pump is equipped with overheat protection that will will first reduce the pump
speed if the temperature rises to a critical level. If the temperature still rises further,
the pump will be shut down completely. After cooling down, the pump will resume
operation automatically.

7.2. Installation to Aqua Computer products

7.2. Installation to Aqua Computer products 7.2. Installation to Aqua Computer products 7.2. Installation to Aqua Computer products
Suitable products manufactured by Aqua Computer for the D5 pump motor in-
clude a gasket as well as a mounting ring with compatible screws. If the manual
supplied with that product does not state otherwise, install the pump motor as fol-
lows:
1. Place the gasket into the pump receptacle. When properly inserted, the gas-
ket is properly aligned to the pump receptacle on the outer diameter.
2. Insert the D5 pump motor into the pump receptacle.
3. Slide the mounting ring into the rear side of the pump motor (where the
electrical connections are) and take care not to jam any cables. Secure the
ring with the appropriate counter-sunk M4 screws. Gently tighten the screws
by hand and do not use excessive force in order not to damage the threads!

7.3. Allowed mounting orientations:

7.3. Allowed mounting orientations: 7.3. Allowed mounting orientations: 7.3. Allowed mounting orientations:
During operation, the pump's rotor must be positioned to the top or to the side in
relation to the control knob. The rotor must not face down during operation!

7.4. Power connection and initial operation

7.4. Power connection and initial operation
7.4. Power connection and initial operation 7.4. Power connection and initial operation
Prior to operation, the cooling system has to be filled with suitable coolant.
As a centrifugal pump, the D5 pump motor is not self-priming, so the pump
will not work unless the pump chamber is filled with coolant. Therefore, in-
stalling the pump in close proximity to a reservoir using a short hose connec-
tion with a preferably big inner diameter to connect the suction side of the
pump to the reservoir is recommended.
The electronic components of the pump must not get in contact with coolant The electronic components of the pump must not get in contact with coolant
The electronic components of the pump must not get in contact with coolant The electronic components of the pump must not get in contact with coolant
or water! Immersed operation is not allowed! or water! or water! or water!
Shut down your PC and connect the power connector of the pump to a com-
patible connector of the PC's power supply unit. Do not use excessive force
but double check the polarity of the plug if you are having trouble to connect
