This function can be used to add annotations to the chart. While this
function is activated, simply click into the chart to add an annotation at
the current cursor position. By clicking into the text box, you may edit the
text. You may also drag the little circle beside the text box to move the connecting
line to the desired position. Use drag and drop to move existing annotations.
This function can be used to remove lines or annotations from the chart.
While this function is activated, simply click the element to be removed.
This function can be used to move the visible portion of the chart. Press
and hold the mouse button while moving the cursor in the chart to select
the position to be displayed, then release the button.
This function can be used to zoom in and out. Use the mouse wheel or
select the area to be displayed. You can reset the zoom settings by dou-
ble-clicking in the chart area.
This function will completely remove the chart.

11.3. Manual data export

11.3. Manual data export 11.3. Manual data export 11.3. Manual data export
Saved data can be exported from the data log into a XML file. To do so, select
"Analyze data" below the "Data log" headline in the listing. Select the "Data
sources" tab in the chart configuration and select a data set to be exported. If no
data sources are available, you will have to configure the log settings as described
in the corresponding chapter of this manual. Select the time period to be exported
on the right side of the window and start the export process by clicking the "Export
data" button. Enter a file name and path in the following dialog window.

11.4. Automatic data export

11.4. Automatic data export 11.4. Automatic data export 11.4. Automatic data export
The automatic data export feature can be used to save data from the aquasuite
into an XML file on the hard disk or in the RAM („memory mapped file") in a regu-
lar time interval. The automatic data export will always overwrite the previously
saved data, so the file always contains only the most recent data set. Select "Auto-
matic data export" below the "Data log" headline in the listing to access the set-
tings screen. Create a new export data set by clicking the plus symbol in the upper
right corner of the screen. Enter name, path and time interval to meet your re-
quirements. You may then add the data sources to log by clicking the plus symbol
in the "Data sources" window section. You may add an unlimited number of data
sources to each export data set, the total number of export data sets is also unlim-
ited.

12. Configuration of the mps device (aquasuite)

12. Configuration of the mps device (aquasuite)
12. Configuration of the mps device (aquasuite) 12. Configuration of the mps device (aquasuite)
Select "Configuration" from the device list for the device to be configured.
