11. Data log (aquasuite)

11. Data log (aquasuite) 11. Data log (aquasuite) 11. Data log (aquasuite)
Data from all connected Aqua Computer devices can be logged by the aquasuite.
Logged data can then be analyzed by creating charts or be exported to files.

11.1. Log settings

11.1. Log settings 11.1. Log settings 11.1. Log settings
The log settings can be accessed by clicking the "Log settings" element below the
"Data log" headline in the listing. To log data, create a new log data set by click-
ing the plus symbol in the upper right corner of the settings window. Enter name,
time interval and configure automatic deletion of old data to meet your require-
ments. You may then add the data sources to log by clicking the plus symbol in
the "Data sources" window section. You may add an unlimited number of data
sources to each log data set, the total number of log data sets is also unlimited.

11.2. Analyze data

11.2. Analyze data
11.2. Analyze data 11.2. Analyze data
Logged data can be visually evaluated as charts. To do so, select "Analyze data"
below the "Data log" headline in the listing. The chart will initially be empty, di-
rectly below the chart are eight buttons to modify the chart. In the lower section of
the window, the chart data can be configured.
To add data to the chart, first select the "Data sources" tab in the chart configura-
tion and select a data set to be displayed. If no data sources are available, you
will have to configure the log settings as described in the corresponding chapter of
this manual. Select the time period to be displayed on the right side of the window
and add the data to the chart by clicking the "Add data to chart" button. Repeat
this procedure if you want to display more than one data set in the chart.
You may modify the chart using the "Chart setup" and "Data series setup" tabs.
Finally, you can use the "Chart manager" tab to save the current chart configura-
tion and to load or delete previously saved configurations. All saved chart configu-
rations will be available on overview pages for the "Log data chart" element.
The currently displayed chart can be edited by using the buttons directly below the
chart and may also be saved as an image file. The button corresponding to the
currently selected function is highlighted by an orange frame. Please refer to the
following list for details on each function:
To save the currently displayed chart as an image file, click the floppy
disk symbol and select a name and location in the following dialog.
This function can be used to add horizontal lines to the chart. While this
function is activated, simply click into the chart to add a line at the cur-
rent cursor position.
This function can be used to add vertical lines to the chart. While this
function is activated, simply click into the chart to add a line at the cur-
rent cursor position.
