the drop down menu and confirm your selection by clicking the "Load preset" but-
ton. Depending on the type of element, an additional dialog may appear before
the code (XAML, Extensible Application Markup Language) of the new element is
displayed in the lower part of the dialog window. You may want to customize the
code. By clocking the "Ok" Button, the new control is saved to the overview page.
Example process to add an image: Select "Image" from the drop down menu and
click the "Load preset" button. Select an image file using the following file selec-
tion dialog. The code is then displayed in the lower part of the dialog window an
can be modified. Save the new control by clicking the "Ok" button. The picture
will be displayed on the overview page.
More complex controls such as data bindings and animations are also available
but will require some programming experience for configuration.

10.8. Log data chart

10.8. Log data chart
10.8. Log data chart 10.8. Log data chart
This element can be used to display charts on overview pages. The charts have to
be created using the data log functionality of the aquasuite before they become
available for overview pages. Please refer to the next chapter for details. Once a
chart has been configured, it can be selected from the "Chart selection" list on the
"Display" tab of the settings dialog.
10.9. Export and import of overview pages 10.9. Export and import of overview pages 10.9. Export and import of overview pages 10.9. Export and import of overview pages
Elements and complete overview pages can exported from the aquasuite and can
then be imported either on the same PC or on other PCs. For export as well as im-
port, the overview page must be in edit mode.
To export a complete page, right click a free spot of the page and select "Export
page" from the context menu. To export individual elements, select the element or
elements, perform a right click and select "Export selected" from the context menu.
For import, right click a free spot of the page and select "Import page" or "Import
items"from the context menu. Using "Import page", the current page will be delet-
ed and only the imported page items will be displayed, using "Import items" will
add the items from file to the current page without altering the existing items. Dur-
ing import, the elements will be assigned to devices using the following scheme:
If a device with identical serial number is found on the computer, no changes are
made.
If no device with identical serial number is found on the computer, the element will
be assigned to the first device found of identical type.
When importing complex pages with elements referring to more than one device, it
is recommended to edit the device assignment in the file using a text editor prior to
importing.
