13. Alarm configuration of mps device (aquasuite)

13. Alarm configuration of mps device (aquasuite) 13. Alarm configuration of mps device (aquasuite) 13. Alarm configuration of mps device (aquasuite)
Select "Alarm configuration" from the device list for the device to be configured.

13.1. Speed signal/Output

13.1. Speed signal/Output 13.1. Speed signal/Output 13.1. Speed signal/Output
The alarm header can be configured as a speed signal output or as a switching
output.
Option "Power switch (53217)": This mode can be used for emergency shutdown
of the PC, if the "alarm" header is connected to the power switch header of the
motherboard using a suitable cable (art. 53217). Before connecting the cable,
make sure the mps device is configured correctly! After connecting the cable, test
the setup by deliberately creating an alarm condition. If the PC is not shut down,
the cable header connected to the motherboard must be rotated by 180 degrees
and the test has to be repeated. Emergency shutdown may result in data loss as
operating system and running programs are not shut down properly!

13.2. Alarm timeout

13.2. Alarm timeout
13.2. Alarm timeout 13.2. Alarm timeout
Alarm detection will be delayed by the time interval specified here. This feature will
prevent short-time deviations beyond alarm limits from raising an alarm, for exam-
ple to prevent flow alarms when using the automatic speed feature or deaeration
feature of an aquastream XT pump.

13.3. Alarm reporting and alarm limits

13.3. Alarm reporting and alarm limits 13.3. Alarm reporting and alarm limits 13.3. Alarm reporting and alarm limits
Select the data sources to be monitored and set appropriate alarm limits. If the
current reading is below the lower limit or higher than the upper limit, an alarm
will be raised if the check box "Activate alarm" is set for this value. All sources that
currently raise an alarm are highlighted with a red background color in the soft-
ware.
Make sure only to use readings for alarm evaluation that are functional with your
specific sensor.

14. System settings for mps device (aquasuite)

14. System settings for mps device (aquasuite)
14. System settings for mps device (aquasuite) 14. System settings for mps device (aquasuite)
Select "System" from the device list for the device to be configured.

14.1. Device information

14.1. Device information 14.1. Device information 14.1. Device information
The details displayed here might be required when you contact our service for sup-
port.

14.2. Firmware update

14.2. Firmware update
14.2. Firmware update 14.2. Firmware update
The aquasuite software contains the current firmware files for all supported Aqua
Computer devices. The button "Update firmware to version xxxx" will only be dis-
